Specifications
- GPU Base Clock Frequency2.61 gigahertzGPU Boost Clock Frequency2.64 gigahertzDisplayPort Ports3 x DisplayPort 2.1HDMI Ports2 x HDMI 2.1Maximum Resolution8K (4320p)Maximum Number of Displays Supported4
- Key Specs
- GPU Base Clock Frequency: 2.61 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.64 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 2 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- GPU Video Memory (RAM): 12 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- Slot Size: 3-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 5.0
- Product Height: 62.5 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 140 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 329 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5070 (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- General
- Brand: ASUS
- Model Number: TUF-RTX5070-O12G-GAMING
- Product Name: TUF Gaming NVIDIA GeForce RTX 5070 OC Edition 12GB GDDR7 PCI Express 5.0 Graphics Card
- Color: Black
- GPU Chipset Manufacturer: NVIDIA
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5070 (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- Year of Release: 2025
- Performance
- GPU Base Clock Frequency: 2.61 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.64 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- Cooling System: Fan (A computer's CPU generates heat while operating and requires a cooling system to keep internal components functioning properly. Air cooling uses fans to draw in cool air and exhaust hot air, while liquid cooling uses coolant-filled tubes and water blocks to regulate internal temperature more efficiently.)
- Connectivity
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 2 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Display
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- Memory
- GPU Video Memory (RAM): 12 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- GPU Video Memory Base Clock Frequency (RAM): 14 gigahertz
- Compatibility
- Slot Size: 3-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- System Requirements: Windows 11 / Windows 10 (The software that a product must have for it to be able to integrate with another product.)
- PCI Express Version: PCI Express 5.0
- Operating System Compatibility: Windows
- Power
- Total Graphics Power: 250 watts
- Recommended Power Supply: 750 watts
- Dimensions
- Product Height: 62.5 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 140 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 329 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 3.38 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 3 Years
- Warranty - Labor: 3 Years
- Other
- UPC: 197105870352
NVIDIA Blackwell architecture is elevated by enhanced cooling and power delivery, fortified with rugged reinforcements for exceptional durability. Lock, load, and dominate with the ASUS TUF Gaming GeForce RTX™ 5070 OC, designed to withstand the harshest conditions, and deliver unparalleled performance.
- Powered by: NVIDIA Blackwell architecture and DLSS 4
- Military-grade components: Deliver rock-solid power and longer lifespan for ultimate durability
- Protective PCB coating: Helps protect against short circuits caused by moisture, dust, or debris
- 3.125-slot design: With massive fin array optimized for airflow from three Axial-tech fans
- Phase-change GPU thermal pad: Helps ensure optimal thermal performance and longevity, outlasting traditional thermal paste for graphics cards under heavy loads
- ASUS GPU Guard and bracket: Secure the GPU, reducing the risk of cracks and ensuring stable mounting
- Auto-Extreme: Precision automated manufacturing helps ensure higher reliability
- GPU Tweak III: Software provides intuitive performance tweaking, advanced thermal controls, and system monitoring
Whats Included
- Speedsetup Manual
- ASUS Velcro Hook & Loop
- Thank you Card
- Adapter Cable
Q: What type of cooling system does this graphics card use?
A: This graphics card uses a fan cooling system.
Q: What is the recommended power supply for this graphics card?
A: The recommended power supply for this graphics card is 750 watts.
Q: Does this graphics card have a protective PCB coating?
A: Yes, it has a protective PCB coating that helps protect against short circuits.
Q: What is the total graphics power of this graphics card?
A: The total graphics power of this graphics card is 250 watts.
Q: How many slots does this graphics card occupy?
A: This graphics card has a 3-slot design.
Q: will this run off of 600watt power supply
A: The ASUS TUF Gaming GeForce RTX 5070 OC Edition Graphics Card recommends a 750W power supply for optimal stability. While a 600W PSU might work, a higher wattage unit is advised, especially for high-performance systems.
Q: Can I use 800w or anything above 750w without issues?
A: Yes I use a 750watt supply
Q: Can I use this with a 650 watt power supply for the time before I get a 750 watt Power supply
A: The ASUS TUF-RTX5070-O12G-GAMING Graphics Card is designed to work with a 750W power supply for optimal stability and performance. Using a 650W power supply temporarily might work under certain conditions, but it could lead to system instability or insufficient power during demanding tasks. Upgrading to a 750W PSU is strongly recommended.
