- General
- Brand: PAC
- Model Number: C2R-FRD1
- Product Name: In-Dash Deck Replacement Interface for Select Ford, Lincoln and Mercury Vehicles
- Color: Black
- Compatibility
- Vehicle Compatibility: Designed for use with select 2007 - 2008 Ford, Lincoln and Mercury vehicles
- Product Compatibility: Navigation
- Product Type: Interface
- Dimensions
- Product Height: 3.75 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Length: 8.5 inches (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Width: 4 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Weight: 0.5 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: Not available
- Other
- UPC: 606523107266
This replacement interface provides navigation trigger wires and timed accessory output for replacing the factory radio. It retains the factory installed amplified audio system and rear seat entertainment (if equipped). Use with a steering wheel interface module to retain function of all factory controls. For Select 2006-2014 Ford, Lincoln, Mercury Vehicles.
- Designed for use with select 2006-2014 Ford, Lincoln, Mercury Vehicles: Allows you to upgrade your in-dash deck in both amplified and nonamplified systems.
- Data-controlled outputs: RAP accessory, reverse trigger wire, illumination output wire, parking brake wire, and vehicle speed sense wire.
- Retains OEM features: 3.5mm jack, rear seat entertainment and dual zone audio, factory-installed amplified audio system, steering wheel control module.
- 8.5" cable length: Provides plenty of length to aid in setup.
