Whirlpool - - Stainless steel
- Key Specs
- Product Height: 7.5 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 35.07 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 24 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Top
- Vent Type: Convertible
- Color Finish: Stainless steel
- General
- Product Name: 36" Convertible Range Hood
- Brand: Whirlpool
- Model Number: GXW6536DXS
- Color Finish: Stainless steel
- Dimensions
- Product Height: 7.5 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 35.07 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 24 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 135 pounds (The out of box weight of the item.)
- Duct Shape: Round
- Duct Length: 420 inches
- Features
- Exhaust Vent Location: Top
- Vent Type: Convertible
- Number of Fan Speeds: 3
- Control Type: Button
- Integrated Light(s): true
- Bulb Type Required: Incandescent
- Bulb(s) Included: true
- Performance
- Maximum Air Flow Capacity: 400 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Minimum Air Flow Capacity: 100 cubic feet per minute (Minimum amount of air that the appliance will ventilate at its lowest setting.)
- Filter Info
- Dishwasher-Safe Filter: true
- Removable Grease Filter: true
- Electrical Specification
- Amperage: 15 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Other
- UPC: 883049195452
This wall-mountable range hood features a 400 cfm exhaust and an aluminum mesh filter that remove smoke and cooking odors from the air so your kitchen is free of lingering odors.
- 400 cfm blower and 3-speed fan: Quickly pull smoke and cooking odors out of the air.
- Push-button controls: Provide simple operation.
- Incandescent lights: Provide enhanced visibility while you're cooking.
- Removable, dishwasher-safe aluminum mesh filter: Makes cleanup quick and easy.
- Glass canopy design: For a stylish look.
- Convertible to recirculating option: With optional kit (not included).
- Wall-mountable design: Allows flexible placement.
Whats Included
- Affresh Dishwasher and Disposal Cleaner (6-Pack)
Q: can this model hang over an island cooktop or is it just a wall mount unit
A: Model GXW6536DXS can only be wall mounted. If you need a similar model that can be installed in an island situation then look into model GXI6536DX.
Q: I need to order the optional conversion kit
A: Dear Valued Consumer: Recirculation Kit Part Number W10294733 for non-vented (recirculating) installations for model GXW6530DX or GXW6536DX only. You may purchase this through your dealer or call our parts department to order at 1-800-442-9991. Thank you for your interest in our Whirlpool vent hood.
Q: I have a 9 foot ceiling, will this work?
A: For vented installation, you can adjust the chimneys for ceilings between 7ft 4 inches and 9 ft 5 inches with vented slots not showing. For vent slots showing, the ceiling can be between 7 ft 4 inches and 9 ft 9 inches.
Q: What is the depth from center forward to room, Island mount. I have 9"
A: Hello. You can see the dimension guide for this range hood on our website at http://bit.ly/1THeM9S . We hope this information is beneficial to you. Thank you for your inquiry regarding our Whirlpool appliances!
A: Dear Valued Customer: Thank you for your inquiry regarding Whirlpool vent model GXW6536DSX. The sones for this model is 7.20. Thank you again for your inquiry. We appreciate and value your business!
Q: What is the length of this item
A: The product dimensions of our 36 inch range hood model GXW6536DXS are listed below: 36 wide 20 deep Height can extend from 27 1/8 minimum to 45 ½ maximum if non-vented and 27 1/8 to 41 1/8 for vented. For vented installations, the chimneys can be adjusted for ceilings between 7ft 4 inches and 9 ft 5 inches with vent slots not showing and between 7 ft 4 inches and 9 ft 9 inches with the vent slots showing.
