Miele - KFMC 3836 L 30" 16.5 Cubic Feet Bottom Mount MasterCool Refrigerator Freezer - Custom Panel Ready
Specifications
- Product Height83.75 inchesProduct Width29.88 inchesHeight To Top Of Door Hinge83.75 inchesTotal Capacity16.53 cubic feetRefrigerator StyleBottom FreezerLighting TypeLED
- Key Specs
- Product Height: 83.75 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29.88 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Height To Top Of Door Hinge: 83.75 inches (Height from bottom of refrigerator to top of the door, including the top hinge.)
- Total Capacity: 16.53 cubic feet
- Refrigerator Style: Bottom Freezer
- Lighting Type: LED
- Ice Maker: Yes
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Works With: Amazon Alexa, Google Home (Compatible with or able to be connected to other smart devices or applications.)
- General
- Brand: Miele
- Model Number: KFMC3836L
- Product Name: KFMC 3836 L 30" 16.5 Cubic Feet Bottom Mount MasterCool Refrigerator Freezer
- Color: Custom Panel Ready
- Dimensions
- Product Height: 83.75 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29.88 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 25 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Height To Top Of Door Hinge: 83.75 inches (Height from bottom of refrigerator to top of the door, including the top hinge.)
- Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Counter Depth: true (The product case installs flush with the depth of standard kitchen counters to provide a built-in appearance.)
- Product Weight: 441 pounds (The out of box weight of the item.)
- Cut-Out Dimensions
- Cut-Out Height: 84.13 inches (Minimum required height of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Width: 30 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Depth: 25 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Capacity
- Total Capacity: 16.53 cubic feet
- Refrigerator Capacity: 11.03 cubic feet (Total amount of space within the refrigerator compartment. Usable space may be reduced by shelves, cabinets, or other storage features.)
- Freezer Capacity: 5.5 cubic feet (Total amount of space within the freezer compartment. Usable space may be reduced by shelves, cabinets, or other storage features.)
- Features
- Configuration: Built-in (The size, arrangement, and physical configuration of the product.)
- Panel Ready: true (Product is ready to be fit with a customized front panel that integrates with existing cabinetry and décor.)
- Refrigerator Style: Bottom Freezer
- Panel(s) Included: false
- Garage Ready: false (Garage Ready appliances have been tested by the manufacturer to operate within a wider range of external temperatures than the average home environment, such as a garage which can fall below freezing or heat above 100 degrees Fahrenheit. Please refer to the manufacturer's documentation for detailed external operating temperature requirements.)
- Door-Open Alarm: true
- Sabbath Mode: true (This mode complies with the rules of Halakha and allows Shabbat-observant people to use the appliance on the Shabbat and other Jewish holidays.)
- Temperature Control Type: Touchscreen
- Defrost Type: Frost free (Ice build-up can reduce the appliance’s cooling capacity, making it work harder and consume more energy. Defrosting is necessary to maintain its efficiency and each type has its own advantages depending on user needs and preferences. Manual defrost appliances require unplugging to melt ice naturally, but offer more space, lower energy consumption, and lower cost without the internal heating element. Frost-free appliances regulate temperature to prevent ice build-up automatically. Automatic defrost systems use a timer to circulate heat and prevent ice accumulation, while adaptive defrost systems use sensors to determine the optimal times for heat circulation.)
- Reversible Door Hinge: false
- Hinge Setting: Fixed left
- Lighting Type: LED
- Wireless Connectivity: Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Ice & Water
- Ice Maker: Yes
- Ice Maker Location(s): Freezer
- Ice Dispenser Ice Form: Cubed
- Daily Ice Production: 3 pounds (Maximum quantity of ice that can be produced within 24 hours.)
- Ice and Water Dispenser: Ice and water
- Ice and Water Dispenser Location: Internal
- Dispensed Water Type: Cold Water
- Storage
- Number of External Doors/Drawers: 2
- Number of Refrigerator Shelves: 2
- Refrigerator Shelf Style: Adjustable, Spill proof
- Gallon Door Storage: true (Designated storage space for gallon-sized containers, such as milk, juice, and water.)
- Humidity-Controlled Crisper: true
- Deli Meat Drawer: true (Designated storage for deli and other meats helps keep these items accessible and may reduce the risk of cross-contamination.)
- Refrigerator Shelf Material: Tempered Glass Shelves
- Freezer Info
- Freezer Compartment: true
- Freezer Location: Bottom
- Freezer Door Type: Pull Out Drawer
- Freezer Shelf Material: No shelves
- Filter Info
- Water Filtration: true
- Water Filter Model Number: KFW 2000 (The water filter model(s) recommended for use with the product.)
- Air Filter: true (A filter that works to remove odors and contaminants from the air within the appliance.)
- Air Filter Model Number: Longlife Air Clean Fiilter (The air filter model(s) recommended for use with the product.)
- Electrical
- Amperage: 10 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Estimated Annual Electricity Use: 560 kilowatt hours (Predicted amount of electricity needed to operate the product under average conditions for one year.)
- Estimated Annual Operating Cost: 79 United States dollars (Predicted cost of operating the product under average conditions for one year.)
- Certifications Listings & Approvals
- ENERGY STAR Certified: true (Devices carrying the ENERGY STAR service mark, such as computer products and peripherals, kitchen appliances, and other products, generally use 20% to 30% less energy than required by federal standards.)
- Consortium for Energy Efficiency (CEE) Rating: CEE Not Qualified
- Warranty
- Warranty - Parts: 5 years
- Warranty - Labor: 5 Years
- Compatibility
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Works With: Amazon Alexa, Google Home (Compatible with or able to be connected to other smart devices or applications.)
- Other
- UPC: 4002516768586
The Miele KFMC 3836 L MasterCool™ built-in bottom-mount refrigerator combines advanced food preservation technology with premium design and seamless panel-ready integration. Designed for luxury kitchens, this 30-inch refrigerator-freezer offers 16.53 cu. ft. of total capacity and features a fully customizable exterior that blends beautifully with surrounding cabinetry. MasterFresh Pro technology creates the ideal environment for storing fresh foods, helping fruits, vegetables, meats, and dairy products stay fresher for longer. DailyFresh ExtraCool provides dedicated storage for temperature-sensitive items, while the Longlife AirClean System reduces odors and maintains a fresher interior environment. DynaCool technology circulates air evenly throughout the refrigerator, ensuring consistent temperatures on every shelf. BrilliantLight Pro LED illumination provides exceptional visibility throughout the interior, while the intuitive M Touch Pro display allows precise control of refrigeration settings. FoodView interior cameras let you check refrigerator contents remotely through the Miele app, helping simplify meal planning and grocery shopping. Miele@home connectivity enables smart monitoring and control from compatible mobile devices. For added convenience, the KFMC 3836 L features an integrated IceMaker and water dispenser, providing fresh ice and chilled filtered water whenever you need it. NoFrost technology eliminates manual defrosting, while SoftClose and SelfClose door systems enhance everyday usability. FullAccess shelving, adjustable storage options, and spacious freezer baskets maximize organization and accessibility. Built to Miele's exacting standards, the MasterCool KFMC 3836 L delivers exceptional performance, premium craftsmanship, and sophisticated refrigeration technology for the modern luxury kitchen.
- MasterFresh Pro: The drawers of your Miele MasterCool appliance provide the perfect climate for the gentle storage of your food. In the automatically controlled temperature range between 32 and 37°F (0 and +3°C), vitamins and minerals are preserved for a long time. Thanks to the electronic humidity controls in the drawer, meat, fish and dairy products stay fresh up to 3 times longer and fruit and vegetables up to 5 times longer.
- Longlife AirClean System: Noticeably reduce odors and their transfer to food by up to 95 %. The filter is located in the air flow of the appliance, for an exceptionally long-lasting and effective reduction in odors. To ensure a long service life, the filter can be reactivated in the oven to reduce the odor. This means it remains functional for a full three years. The above-average service life ensures sustainability and conservation of resources.
- IceMaker: The IceMaker enables your Miele bottom-mount unit to produce up to 3 lb (1.4 kg) of fresh ice cubes a day, completely automatically. With a plumbed water connection, ice cubes are produced continuously until the ice cube container is full. A water filter ensures optimum water quality.
- Water Dispenser: The MasterCool appliances serve you chilled and filtered water at any time for ultimate convenience. Save quantities for different container sizes as favorites in the display.
- DynaCool: Top or bottom – where is the best place to store your groceries? Thanks to DynaCool, you’ll never have to ask yourself this question again. In Miele MasterCool refrigeration appliances, you can store your food wherever you like as a fan on the rear panel of the refrigerator compartment circulates the cold air for a uniform temperature throughout the entire unit.
- Spill-proof glass shelves: No need to panic if something leaks: The glass shelves have an aluminum profile on all sides which blocks leaking liquids and protects the lower levels of the refrigerator appliance interior.
- Cameras in the refrigerator: Integrated cameras allow you to keep an eye on the contents of your refrigerator at all times – no matter where you are. This means you always know exactly what supplies you still have at home.
- Gallon bins: Wonderful use of space: Large containers for liquids, such as gallon containers, can be safely stored on the door shelves, leaving more space inside for other food.
- NoFrost: All Miele MasterCool appliances – both refrigerators and freezers – are equipped with a sophisticated NoFrost system. It saves you the trouble of defrosting and cleaning the appliance. Automatic defrosting also protects the evaporator units – not to mention the environment, as the appliance is particularly energy-efficient to keep cool because it is constantly free of ice.
- M Touch Pro: Intuitive to use for excellent convenience: The innovative, high-resolution TFT touch display allows you to configure all kinds of settings directly on your MasterCool appliance. A single touch of a fingertip on the ergonomically positioned display is all it takes to adjust the temperature to suit your preferences. Step-by-step instructions and helpful information are available for selected processes, such as replacing or cleaning the filter.
- Brilliant Light Pro: Thanks to BrilliantLight Pro, the interior of your Miele MasterCool appliance shines in the best light – even if it is filled to maximum capacity. For a perfect overview of your food, flush LED light strips in the side panels gently light up as soon as you open the door. BrilliantLight features flush side LEDs. BrilliantLight Pro also includes LEDs in the ceiling – high-quality, elegant, and easy to clean.
- SmartLight: Adjust the illumination according to the time of day and lighting mood: In your Miele MasterCool appliance, a sensor ensures that the brightness in the interior is automatically adjusted to the ambient light. You define how much the light is dimmed down in the dark or twilight and always benefit from optimum illumination without unpleasant glare effects.
- Sliding Shelf: Small items such as tubes or small glass containers can be stored in a drawer below the glass shelf that can be pulled out to the front and removed – separated from the rest of the interior and the other food.
- Miele At Home: With our innovative Miele@home system, you can exploit the full potential of your Miele appliances and make your everyday life even smarter. All intelligent Miele domestic appliances can be networked conveniently and securely. Operation is simple – whether you use the Miele app, voice control, or integration into existing Smart Home solutions. The appliances are networked via a home Wi-Fi router and the Miele Cloud.
- Capacity: Unit Capacity- 16.5 Cubic Feet
- MaxLoad Hinge: The extremely strong door hinges can safely cope with large, heavy, and fully laden refrigerator doors, and still open smoothly. The doors can be opened wide, which makes loading and unloading the refrigerator easy and convenient
Whats Included
- KFMC3836L
- Ice Scoop
- Longlife AirClean filter
- Water filter
Product Manuals
Documents
- Energy_Guide_PDF
Disclaimers
- Panel-ready products are designed to be fitted with custom cabinetry panels and handles, allowing them to blend seamlessly into your kitchen's design. If you do not install a panel on a panel-ready product, the unit will still function properly, but it will appear unfinished and aesthetically unappealing. Panels/Handles are sold separately.
Q: Does this refrigerator have a water dispenser?
A: Yes, this MasterCool appliance has an ice and water dispenser.
Q: Does this refrigerator have cameras inside?
A: Yes, integrated cameras allow you to keep an eye on the contents of your refrigerator at all times.
Q: Are the refrigerator shelves made of glass?
A: Yes, the refrigerator shelves are made of tempered glass.
Q: Can this refrigerator be connected to WiFi?
A: Yes, this refrigerator has wireless connectivity via Wi-Fi.
Q: Does this appliance have a door open alarm?
A: Yes, this appliance features a door-open alarm.
Q: Does this refrigerator have an air filter?
A: Yes, this refrigerator has an air filter.
Q: Can this refrigerator's temperature be controlled using a touchscreen?
A: Yes, the temperature control type is touchscreen.
