PNY - GeForce RTX 4070 Ti SUPER VERTO Overclocked 16GB Graphics Card with Triple Fans - Black
Model: VCG4070TS16TFXPB1-O
SKU: 6574653
This item is no longer available in new condition. See similar items below
- Key Specs
- GPU Base Clock Frequency: 2.34 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.625 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- DisplayPort Ports: 3 x DisplayPort 1.4 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 1 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 3 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- GPU Video Memory (RAM): 16 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR6X (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- Slot Size: 3-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 3.0
- Product Height: 2.4 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 4.7 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 12.01 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 4070 Ti SUPER (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- General
- Brand: PNY
- Model Number: VCG4070TS16TFXPB1-O
- Product Name: GeForce RTX 4070 Ti SUPER VERTO Overclocked 16GB Graphics Card with Triple Fans
- Color: Black
- GPU Chipset Manufacturer: NVIDIA
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 4070 Ti SUPER (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- Year of Release: 2024
- Performance
- GPU Base Clock Frequency: 2.34 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.625 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- Cooling System: Fan (A computer's CPU generates heat while operating and requires a cooling system to keep internal components functioning properly. Air cooling uses fans to draw in cool air and exhaust hot air, while liquid cooling uses coolant-filled tubes and water blocks to regulate internal temperature more efficiently.)
- Connectivity
- DisplayPort Ports: 3 x DisplayPort 1.4 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 1 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Display
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 3 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- Memory
- GPU Video Memory (RAM): 16 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR6X (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- GPU Video Memory Base Clock Frequency (RAM): 16 gigahertz
- Compatibility
- Slot Size: 3-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 3.0
- Operating System Compatibility: Windows, Linux
- Power
- Total Graphics Power: 285 watts
- Recommended Power Supply: 700 watts
- Dimensions
- Product Height: 2.4 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 4.7 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 12.01 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 1.75 pounds (The out of box weight of the item.)
- Other
- UPC: 751492786391
NVIDIA GeForce RTX 40 Series GPUs are beyond fast for gamers and creators. They're powered by the ultra-efficient NVIDIA Ada Lovelace architecture which delivers a quantum leap in both performance and AI-powered graphics. Experience lifelike virtual worlds with ray tracing and ultra-high FPS gaming with the lowest latency. Discover revolutionary new ways to create and unprecedented workflow acceleration. Supercharge your PC with the NVIDIA GeForce RTX 4070 Ti SUPER, built with the ultra-efficient ADA Lovelace architecture and up to 16GB of superfast G6X memory. Experience fast ray tracing, AI-accelerated performance with DLSS 3, new ways to create and much more.
- Powered by NVIDIA DLSS 3: Ultra-efficient Ada Lovelace arch, and full ray tracing.
- NVIDIA Ada Lovelace: With 2340MHz core clock and 2625MHz boost clock speeds to help meet the needs of demanding games.
- On-board memory, memory type, and memory bandwidth: 16GB GDDR6X (256-bit) on-board memory, plus 8448 CUDA processing cores and up to 672GB/sec of memory bandwidth provide the memory needed to create striking visual realism.
- PCI Express 4.0 interface: Offers compatibility with a range of systems. Also includes DisplayPort and HDMI outputs for expanded connectivity.
- NVIDIA GeForce Experience: Capture and share videos, screenshots, and livestreams with friends. Keep your drivers up to date and optimize your game settings. It's the essential companion to your GeForce graphics card.
Whats Included
- 1x PNY GeForce RTX 4070 Ti SUPER 16GB VERTO Overclocked Triple Fan Graphics Card DLSS 3
- 1x GPU support bracket
- 1x 16-pin to 2x 8-pin adapter
Q: How many displays can this graphics card support?
A: This graphics card can support a maximum of 4 displays.
Q: What is the boost clock speed of this graphics card?
A: The boost clock speed of this graphics card is 2625MHz.
Q: What type of memory does this graphics card use?
A: This graphics card uses GDDR6X type of memory.
Q: How much memory does the PNY graphics card have?
A: This PNY graphics card has 16GB of GDDR6X memory.
Q: What version of HDMI does this graphics card have?
A: This graphics card is equipped with a HDMI 2.1 port.
Q: Does this graphics card support PCI Express 4.0?
A: Yes, this graphics card supports PCI Express 4.0 interface.
A: Hi John! You might be okay. To be sure, go to pcpartpicker.com and add your pc components to the parts list and you will be able to see how many watts you're using with the parts in your current system.
Q: What are the physical dimensions of the card it-self?
A: For model number: VCG4070TS16TFXPB1-O PNY's website states the cards size is 12.01" x 4.7" x 2.4"; 3 slot Converted into metric the cards size is 305.00 mm x 119.38 mm x 61.00 mm
