GE Profile - Advantium 30" Built-In Single Electric Wall Oven with Microwave - Stainless Steel
- Key Specs
- Color Finish: Stainless steel
- Product Height: 19 1/8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 3/4 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 21 1/2 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Depth Without Handle: 21 1/2 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- General
- Brand: GE Profile
- Model Number: PSB9240SFSS
- Product Name: Advantium 30" Built-In Single Electric Wall Oven with Microwave
- Color: Stainless Steel
- Color Finish: Stainless steel
- Dimensions
- Product Height: 19 1/8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 3/4 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 21 1/2 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Depth Without Handle: 21 1/2 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
- Depth With Door 90 Degrees Open: 34 1/2 inches (Measurement from the back of the product to its front, with the door open at a 90-degree angle.)
- Interior Oven Height: 8 1/2 inches
- Interior Oven Width: 20 1/16 inches
- Interior Oven Depth: 17 inches
- Product Weight: 77 pounds (The out of box weight of the item.)
- Cut-Out Dimensions
- Cut-Out Height: 17 1/2 inches (Minimum required height of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Width: 25 1/4 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Depth: 23 1/2 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Capacity
- Oven Capacity: 1.7 cubic feet (Standard ovens typically have capacities of about 5 cubic feet, while wall ovens typically have about 3 cubic feet of space.)
- Features
- Oven Type: Single wall oven
- Oven Power Source: Electric
- Fingerprint Resistant: false
- Control Type: Touchpad, Dial
- Clock Display: true
- Lock Type: Control panel lock
- Oven Light: true
- Wireless Connectivity: None (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Functions
- Sabbath Mode: false (This mode complies with the rules of Halakha and allows Shabbat-observant people to use the appliance on the Shabbat and other Jewish holidays.)
- Delay Clean Option: false
- Hidden Bake Element: true (This feature provides more space within the cooking cavity and allows for cleaning without navigating around an exposed heating element.)
- Keep Warm Setting: true
- Variable Broil: false (This feature allows you to change the temperature of the broil function, which provides more versatility and control when preparing your favorite foods.)
- Timer: true
- Time Bake: false (Allows you to program the appliance to run at a pre-determined time and automatically turn off when baking time is finished. Plan for mealtime or entertaining by setting your oven to start baking at a convenient time and reduce the worry of overcooking your food with the automatic shut off feature.)
- Rapid Preheat: true
- Dehydration Settings: false (This function sets the oven at a low temperature, typically under 200 degrees Fahrenheit, for an extended period of time. During this time, warm air circulates throughout the oven to draw moisture out of foods.)
- Broil Element: 1200 watts
- Oven Features
- Oven Convection: true (A cooking process that consistently circulates heated air to quickly and evenly cook food.)
- Oven Cleaning Method: Manual (There are several ways to clean the inside of your oven. Depending on the model, it might require manual cleaning or have a self-clean function. Self-clean functions use either high heat or steam to break down grease and food debris within the cooking cavity.)
- Oven Window: true
- Number of Oven Racks: 1
- Number of Rack Positions: 1
- Electrical Specification
- Amperage: 30 amperes (Strength of electrical current.)
- Voltage: 240 volts (Amount of power needed to support an electrical current.)
- Wattage: 950 watts (Measurement of electrical power.)
- Amperage At 208 Volts: true
- Amperage At 240 Volts: true
- Included
- Power Cord Included: false (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Certifications Listings & Approvals
- ADA Compliant: false (Meets standards set by the Disabilities Act (ADA) Standards for Accessible Design)
- Product Safety Certifications and Standard(s): None (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Chemical Disclosures: For more information about chemicals in this product, including PFAS chemicals, visit: https://www.geappliances.com/chemical-reports. Para obtener más información sobre los productos químicos de este producto, incluidos los productos químicos PFAS, visite: https://www.geappliances.com/chemical-reports.” (The disclosure of Per- and Polyfluorinated Substances (PFAS) and/or other chemicals.)
- Warranty
- Warranty - Parts: 1 year limited
- Warranty - Labor: 1 year limited
- Compatibility
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Other
- UPC: 084691256250
Prepare your meals with ease using this GE Profile Series Advantium 240V PSB9240SFSS built-in microwave that features more than 175 preprogrammed recipes and instantaneous halogen heat, letting you quickly create a variety of favorite dishes.
- Speedcook oven (240V): Enjoy oven-quality results two- to eight- times faster than a conventional oven
- Multiple cooking functions: Expand your cooking versatility with an all in one oven
- Halogen heat: Skip the preheating with nearly instantaneous halogen heat
- Over 175 preprogrammed menu selections: Preprogrammed selections make meals easy
- Custom Recipe Saver: Conveniently store cooking instructions for up to 30 different recipes
- Speedcook oven (240V): Enjoy oven-quality results two- to eight- times faster than a conventional oven
- Multiple cooking functions: Expand your cooking versatility with an all in one oven
- Halogen heat: Skip the preheating with nearly instantaneous halogen heat
- Over 175 preprogrammed menu selections: Preprogrammed selections make meals easy
- Custom Recipe Saver: Conveniently store cooking instructions for up to 30 different recipes
Whats Included
- Advantium 30" Built-In Single Electric Wall Oven
- Owner's manual
- Wire oven rack
- grill pan
- Advantium 30" Built-In Single Electric Wall Oven
- Owner's manual
- Wire oven rack
- grill pan
A: None that I've found so far. GE needs to provide a compatible model. Shouldn't have to rip out your cabinets and start over.
A: Hi Tom - We certainly appreciate your loyalty! Model PSB9240SFSS can be installed in the same cabinet with JX2201 storage drawer (sold separately). This allows for retrofit into previous 240V Advantium (SCB2000/1) wall oven outlet. We suggest viewing the Installation Guide at the following link: https://products.geappliances.com/MarketingObjectRetrieval/Dispatcher?RequestType=PDF&Name=49-40690-2.PDF - Keep in touch at GEAppliances.com. Sue
A: Comparing your current JEB1055 model to the PSB9240SFSS model, they both have the same cutout width of 25-1/4” and height of 17-1/2” for standard installation. However, your current model only requires a 17” minimum depth cutout, while the PSB9240SFSS model requires a 23-1/2” depth cutout. If your cabinet depth meets the 23-1/2” cutout depth requirement, this model would be a great fit. We recommend measuring your cutout space to ensure compatibility. For more information, check out the Installation Instructions on the GE Appliances website.
A: Hi - Thank you for reaching out to us. Your original Advantium is a 240 volt unit which we no longer offer. Any of our over-the-range style microwaves will fit in the same space. They do operate on 120 volts so you will need to provide the proper voltage and outlet. You will also need to use the mounting bracket and hardware packaged with the new unit. Here are a couple of models you might have interest in Profile models PVM9215SKSS, PVM9179SRSS or GE model JVM7195SKSS. We hope you find this helpful. Kind regards - Vikki@GEA
A: Hi - Thank you for your interest in our Profile Advantium wall oven. We apologize for any confusion we may have created with the listed specifications. This unit requires 240 volts and a 30 amp circuit breaker or fuse to operate properly. We will make our dealer partner aware of this issue with the specifications and appreciate you letting us know. We hope this great model will work for you. Kind regards - Vikki@GEA
A: Hi - Thank you for reaching out to us and for your interest in a new built-in Profile Advantium oven. Our current model is a PSB9240SFSS. There have been changes to the cutout dimensions needed for the new model. The new models are more streamlined and don't require the same size cutout as your existing model so be sure to review the installation instructions thoroughly to see what changes would be needed. We hope you find this helpful. Kind regards - Vikki@GEA
A: Preheating is not necessary when using the 240-volt Advantium unless you're using the convection bake mode. Even then, there's no way to provide an exact length of time to preheat as there are several variables that may impact the preheat time such as the temperature of the room, the starting temperature of the Advantium oven and more. On average, you can expect it to take approximately 8-10 minutes for the oven to preheat.
A: The PSB9240SFSS would be the closest comparable model in terms of electrical requirements. That said, the cutout that was required for your existing model is larger than what is needed for the new models. The new model require a cutout opening of 17 1/2"H x 25 1/8"W x 23 1/2"D.
