Arcam

Arcam - AVR5 595W 7.1 Ch. With Google Cast 4K Ultra HD HDR Compatible A/V Home Theater Receiver - Gray

Model: ARCAVR5AM
SKU: 6473960
Sold byBest Buy
$2,000.00
or
$83.34/mo.
suggested payments with 24-Month Financing
Show me how

Protect your AV Component

What's includedTerms & Conditions
Standard Geek Squad Protection
Warranty Protection Plans
  • No Plan selected
    No Plan
  • 4-Year
    $349.99
    About $7.29/mo.
Availability
FREE shipping to
Sold by
Best Buy
Return & Exchange Policy

Related Item

SponsoredOnkyo - TX-RZ50 9.2 Channel Network A/V Receiver - Black
$1,399.99
Specifications
  • Continuous Watts x Channel @ Ohms
    85 watts x 7 channels @ 8 ohms
    Number of Channels
    7.1
    Number of Audio Zones
    1
    Audio Only Inputs
    2 x Optical digital audio, 3 x Coaxial digital audio, 2 x 3.5mm audio, 5 x Analog audio
    Audio/Video Inputs
    7 x HDMI 2.0
    Network Connector(s)
    1 x RS-232, 1 x LAN
  • Key Specs
    • Continuous Watts x Channel @ Ohms: 85 watts x 7 channels @ 8 ohms
    • Number of Channels: 7.1 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
    • Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
    • Audio Only Inputs: 2 x Optical digital audio, 3 x Coaxial digital audio, 2 x 3.5mm audio, 5 x Analog audio
    • Audio/Video Inputs: 7 x HDMI 2.0 (The number and type of HDMI inputs the product has.)
    • Network Connector(s): 1 x RS-232, 1 x LAN
    • Video Pass-through: HDR, 2160 (4K) (Devices with this feature allow video signals to travel from their source to a target device without alteration. For example, a receiver with 4K pass-through would allow 4K video signal from a Blu-ray player to pass to a target TV with surround sound; without the pass-through ability, the receiver would not allow both 4K video and surround sound to be transmitted simultaneously.)
    • Audio/Video Outputs: 2 x HDMI 2.0 (The number and type of HDMI outputs the product has.)
    • Wireless Connectivity: Bluetooth, Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
    • Works With: Google Home (Compatible with or able to be connected to other smart devices or applications.)
  • General
    • Brand: Arcam
    • Model Number: ARCAVR5AM
    • Product Name: AVR5 595W 7.1 Ch. With Google Cast 4K Ultra HD HDR Compatible A/V Home Theater Receiver
    • Color: Gray
  • Audio
    • Continuous Watts x Channel @ Ohms: 85 watts x 7 channels @ 8 ohms
    • Number of Channels: 7.1 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
    • High Resolution Audio: true (Hear music the way musicians and sound technicians intended it to be heard. Products that support hi-res audio deliver audio signals with a dynamic range and bandwidth far greater than that of a standard CD so you'll be able to enjoy pure music with outstanding sound quality. The device supports high-resolution audio signals, which more closely resemble the quality of music as it was originally recorded, with more texture and detail than can be heard via typical music streaming services or CDs.)
    • Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
    • Surround Sound Supported: Dolby Digital, Dolby Atmos, DTS:X (Surround sound systems use multiple audio channels and speakers to create an immersive sound experience for the listener. There are also various proprietary technologies that imitate this kind of sound via a device's built-in speakers or soundbar.)
    • Tuner Type(s): FM only
  • Inputs
    • Audio Only Inputs: 2 x Optical digital audio, 3 x Coaxial digital audio, 2 x 3.5mm audio, 5 x Analog audio
    • Video Only Inputs: No video only inputs (The number and type of video signal only inputs the product has.)
    • Audio/Video Inputs: 7 x HDMI 2.0 (The number and type of HDMI inputs the product has.)
    • Network Connector(s): 1 x RS-232, 1 x LAN
    • Number of HDMI Inputs (Total): 7
    • Number of USB Inputs: 1
  • Video
    • Video Pass-through: HDR, 2160 (4K) (Devices with this feature allow video signals to travel from their source to a target device without alteration. For example, a receiver with 4K pass-through would allow 4K video signal from a Blu-ray player to pass to a target TV with surround sound; without the pass-through ability, the receiver would not allow both 4K video and surround sound to be transmitted simultaneously.)
    • High Dynamic Range Format: Dolby Vision (There are a few HDR formats that tell the TV or other HDR-compatible product how to best utilize its capabilities to display HDR content. HDR technology can support one or multiple formats, each with various benefits to picture quality.)
  • Outputs
    • Video Only Outputs: No video only outputs (The number and type of video signal only outputs the product has.)
    • Audio/Video Outputs: 2 x HDMI 2.0 (The number and type of HDMI outputs the product has.)
    • Speaker Connection Type: Binding posts
    • Number of HDMI Outputs (Total): 2
    • Headphone Jack: true (The device features an interface that allows for the connection of headphones.)
  • Features
    • Auto Calibration: false (Home theater systems and receivers with an autocalibration function can automatically determine basic settings like speaker volume, crossover point, equalization, and more.)
    • Digital Content Protection: HDCP 2.2 (High-bandwidth Digital Content Protection (HDCP) is designed to prevent copying of digital audio and video content as it travels across connections. Newer versions of HDCP support more connection types, increase security, and resolve weaknesses of previous versions.)
    • Remote Control Included: true
  • Connectivity
    • Wireless Connectivity: Bluetooth, Wi-Fi (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
  • Compatibility
    • Works With: Google Home (Compatible with or able to be connected to other smart devices or applications.)
  • Dimensions
    • Product Height: 6.7 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
    • Product Width: 17 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
    • Product Depth: 16.7 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
    • Product Weight: 36.4 pounds (The out of box weight of the item.)
  • Warranty
    • Warranty - Parts: 5 years
    • Warranty - Labor: 5 years
  • Other
    • UPC: 050667379056

Build a superb home theater system with this Arcam audiovisual receiver. Efficient Class AB 7 channel amplification with 12 total channels processing helps to deliver a captivating and transparent sound, and seven HDMI inputs let you connect a wide range of devices simultaneously. Google Cast streaming engine and Bluetooth support allows streaming wirelessly to this Arcam audiovisual receiver from your mobile device.

  • Connect To The Internet: Via built-in Wi-Fi for access to Google Cast.
  • Up To 4K HDMI Passthrough: Transfers 4K video and audio signals from your set-top devices to the TV via the AV receiver.
  • AirPlay 2: Stream audio from music services like Apple Music and Spotify or watch videos from services like YouTube and Netflix from any iPhone, iPad, Mac or Apple TV and hear the audio perfectly synced to your speakers AirPlay 2 sources.
  • 595W Total System Power: Enables you to achieve robust audio output.
  • Surround Sound Decoders: Include Dolby Digital, Dolby Atmos, DTS decoder, DTS:X and more for crystal surround sound.
  • Headphone Jack: Enables private listening.
  • USB Port: Enables simple connection of a variety of USB-enabled devices.
  • Auxiliary Input: Makes it easy to connect a variety of devices.
  • 7 HDMI Inputs, 2 HDMI Outputs: HDMI cable not included. High-speed HDMI cable is the only connection that can deliver a full high-definition experience with a full 1080p picture and digital surround sound.
  • EQ: 3 Dirac EQ profiles (input assignable).
  • Remote Control: Lets you control the receiver from afar.
  • Specifications Tab: For additional information please see the Specifications Tab.
Whats Included
  • Arcam HDA 595W 7.1 Ch. With Google Cast 4K Ultra HD HDR Compatible A/V Home Theater Receiver
  • Manuals & guides
  • Specification sheet (PDF)
  • Warranty manual (PDF)
Product Manuals

Q: Does this receiver offer any sound equalization features?

A: Yes, it includes 3 Dirac EQ profiles that are input assignable.

Q: How do I control this receiver?

A: You can control the receiver using the included remote control.

Q: Can I stream music wirelessly to this receiver from my Apple devices?

A: Yes, you can stream audio wirelessly via AirPlay 2 from any iPhone, iPad, Mac, or Apple TV.

Q: Which surround sound decoders are supported by this receiver?

A: This receiver supports Dolby Digital, Dolby Atmos, DTS decoder, DTS:X, and more.

Q: Does this receiver have a USB port?

A: Yes, it has a USB port for connecting USB-enabled devices.

Q: How can I connect my older audio devices to this receiver?

A: You can use the auxiliary input to connect a variety of devices.

Q: What is the total power output of this Arcam receiver?

A: This Arcam receiver has a total system power of 595W.

Q: Is Dirac live included free with the purchase of the Unit Is the Dirac microphone included with the unit

A: No.AVR5 doesnt have it included
