AudioControl - 1300W 5-Channel Class D Matrix DSP Amplifier - Black
AudioControl - 1300W 5-Channel Class D Matrix DSP Amplifier - Black
FREE shipping to
Specifications
- Continuous Watts x Channel @ Ohms100W x 4 + 300W x 1 @ 4 ohms, 200W x 4 + 500W x 1 @ 2 ohmsAmplifier ClassDNumber Of Channels5Bass BoostNoneBridgeableYesLow-Pass CrossoverVariable
- Key Specs
- Continuous Watts x Channel @ Ohms: 100W x 4 + 300W x 1 @ 4 ohms, 200W x 4 + 500W x 1 @ 2 ohms
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Number Of Channels: 5
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Bridgeable: true (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Low-Pass Crossover: Variable (Devices with this function allow only audio frequencies below a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- High-Pass Crossover: Variable (Devices with this function allow only audio frequencies above a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- Speaker-Level Inputs: true (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- General
- Brand: AudioControl
- Model Number: D-5.1300
- Product Name: 1300W 5-Channel Class D Matrix DSP Amplifier
- Color: Black
- Mounting Hardware Included: true
- Audio Power
- Continuous Watts x Channel @ Ohms: 100W x 4 + 300W x 1 @ 4 ohms, 200W x 4 + 500W x 1 @ 2 ohms
- Total Power Handling RMS: 1300 watts
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Audio
- Number Of Channels: 5
- Minimum Frequency Response: 20 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 22 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Total Harmonic Distortion: 0.1 percent (Measurement of the harmonic sound distortion. The lower the percentage, the cleaner the sound.)
- Signal-to-Noise Ratio (SNR): 102 decibels (The ratio of the desired signal's strength to the level of background noise. A ratio higher than 1:1, which equates to greater than 0 decibels, indicates more signal than noise.)
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Features
- Bridgeable: true (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Low-Pass Crossover: Variable (Devices with this function allow only audio frequencies below a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- High-Pass Crossover: Variable (Devices with this function allow only audio frequencies above a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- MOSFET Power Supply: false (A specific type of power supply with the advantages of high switching speed and efficiency at low voltages.)
- Bluetooth Enabled: true (The device is capable of communicating with another device via Bluetooth, provided they are within the required range of each other. A Bluetooth-enabled device must also be the same Bluetooth version or higher than the accessory it is intended to pair with.)
- Remote Control Included: No
- Marine: false
- Fan Cooled: true
- Input
- Line-Level Inputs: true (Also referred to as low-level inputs. Enables the amplifier to receive a sound signal from another device via RCA cables.)
- Speaker-Level Inputs: true (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- Output
- Preamp Outputs: false
- Dimensions
- Product Height: 8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 12 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 2.1 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 7.2 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 5 years
- Warranty - Labor: 5 years
- Other
- UPC: 851523007812
Experience powerful sound from your car’s audio system with this 1300W 5-Channel Class D Matrix DSP Amplifier by AudioControl. The D-5.1300 is a high-power amplifier equipped with a built-in digital signal processor (DSP) that provides complete control of the amplifier's tuning features. This matrix DSP amplifier also features AccuBASS technology so you can turn up the volume without losing bass.
- 5-channel full range Class D amplifier: Configurable for 5-channel or 3-channel audio systems.
- Handles up to 100W RMS (continuous) x 4 + 300W x 1 @ 4 ohms or 200W RMS x 4 + 500W x 1 @ 2 ohms: To deliver powerful audio. Up to 400W RMS @ 4 ohms bridged.
- 4 ohms and 2 ohms impedance: Conducts power evenly to keep speakers working at optimal levels.
- Built-in DSP: Gives complete control of all amplifier tuning features including EQ, signal delay, phase correction, AccuBASS, GTO Signal Sense, MILC Clip Detection, and integrated input and output real-time analyzers (RTAs) via the included DM Smart DSP app.
- Automatic and selectable signal summing: Combines the active speaker-level inputs (8 channels) for a full range signal.
- AccuBASS processing: Recovers bass frequencies lost at higher volumes.
- Selectable input modes: Accepts both high-level (speaker level) and low-level (RCA line level) signals for integration with your existing audio system.
- Maximum Input Level Control (MILC) with clipping indicator: Prevents damaging distortions and indicates input clipping on the MILC Source Clip LED.
- Independent variable low-pass, band-pass, and high-pass crossovers: Ensure flexible operation.
- 30-band equalizer with auto EQ: Customize how your audio sounds to get the perfect quality for your music.
- Programmable frequency match (PFM) subsonic filter: Eliminates speaker damage and wasted amplifier power.
- <0.1% THD (Total Harmonic Distortion): For clean sound.
- >102dBa signal-to-noise ratio: Ensures crisp audio.
- Adjustable gain with clipping indicator: Allows you to adjust the output signal and indicates signal clipping when gain is set to high.
- Option Port: Provides a Bluetooth connection to allow simultaneous high-resolution audio streaming and DSP programming (AC-BT24 sold separately).
- Great Turn On (GTO) Signal Sense: Automatically powers the amplifier when the radio is turned on.
- Heavy gauge quick connects: Provide added installation ease and serviceability.
- Optional dash remote: Allows you to select memory presets and adjust level control (ACR-3 sold separately).
- 5-year warranty: To protect against defects in materials and workmanship.
Whats Included
- AudioControl 1300W 5-Channel Class D Matrix DSP Amplifier
- Speaker connectors
- 30A fuses (4)
- Quick start guide
Product Manuals
Q: What is the signal-to-noise ratio of this amplifier?
A: This amplifier has a signal-to-noise ratio of >102 decibels.
Q: Does this amplifier have a built-in digital signal processor?
A: Yes, this amplifier is equipped with a built-in digital signal processor (DSP).
Q: Can this amplifier be used with a 2-ohm impedance system?
A: Yes, this amplifier is compatible with both 4-ohm and 2-ohm impedance systems.
Q: How many channels does this amplifier have?
A: This is a 5-channel amplifier, configurable for both 5-channel and 3-channel audio systems.
Q: How much power can this amplifier handle?
A: This amplifier can handle up to 1300 watts RMS.
Q: What kind of warranty does this amplifier come with?
A: This amplifier comes with a 5-year warranty to protect against defects in materials and workmanship.
Q: Does this amplifier have a built-in equalizer?
A: Yes, this amplifier features a 30-band equalizer with auto EQ for customized sound.
Compare similar products
Experience powerful sound from your car’s audio system with this 1300W 5-Channel Class D Matrix DSP Amplifier by AudioControl. The D-5.1300 is a high-power amplifier equipped with a built-in digital signal processor (DSP) that provides complete control of the amplifier's tuning features. This matrix DSP amplifier also features AccuBASS technology so you can turn up the volume without losing bass.
The KENWOOD KAC-835 is a 1600 watts high-performance 5-Channel Amplifier designed to deliver powerful, clear, and dynamic sound. Engineered for audio enthusiasts who seek both precision and versatility in their car audio systems. The KAC-835 provides the perfect blend of power, flexibility, and ease of installation. The 5-channel design allows the KAC-835 to power both front and rear speakers as well as a dedicated subwoofer channel, offering a complete audio solution in a single unit. Despite its powerful performance, the KENWOOD KAC-835 is designed to be compact and easy to install. The KAC-835 amplifier fits into tight spaces, making it ideal for vehicles where space is at a premium. The KENWOOD KAC-835 is equipped with both high-pass and low-pass filters. The high-pass filter is adjustable and allows users to set the crossover frequency for the full-range speakers, ensuring that only the appropriate frequencies are sent to the speakers, preventing distortion, and maximizing clarity. The low-pass filter, dedicated to the subwoofer channel, ensures that the subwoofer receives only the low-end frequencies, delivering tight, punchy bass. For those who crave deep, powerful bass, the KAC-835 features a variable bass boost function that allows you to adjust the low-frequency output to your preference.
Boost the sound of vehicle door speakers with this KICKER four-channel amplifier. The variable bass boost lets you easily tune the system as desired, and Fail-safe Integration Technology-PLUS provides clear sounds with its noise rejection. This KICKER four-channel amplifier features high-efficiency heat sinks, preventing overheating during long periods of use.
Boost the bass in your car with this KICKER 1200W mono amplifier. Stability at 1 ohm allows for use of multiple sound system wiring options, while a subsonic filter at 24dB protects speakers from dangerous frequencies. This KICKER 1200W mono amplifier features 12dB crossovers to control sound precisely and comes with vertical mounting hardware for unique configurations.
| Pros for AudioControl - 1300W 5-Channel Class D Matrix DSP Amplifier - Black | |||
|---|---|---|---|
| There were no pros for this product— | There were no pros for this product— | Sound Quality, Power, Ease of use, Size, Price | Power, Sound Quality, Size, Ease of use, Bass |
| Cons for AudioControl - 1300W 5-Channel Class D Matrix DSP Amplifier - Black | |||
| There were no cons for this product— | There were no cons for this product— | Heat | Heat |
Specs
Reviews
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 5 out of 5 stars
Love It
Great adjustment of frequencies and fine tuning based on desired sound.
Posted by Jacob
