NVX - YSW122 1600W Peak (800W RMS) Y-Series 12in Dual 2-Ohm Car Subwoofer
NVX - YSW122 1600W Peak (800W RMS) Y-Series 12in Dual 2-Ohm Car Subwoofer
Woofer Size
12"Specifications
- RMS Power800 wattsPeak Power Handling1600 wattsImpedance2 ohmsWoofer Size12"
- Key Specs
- RMS Power: 800 watts (The maximum amount of continuous power the device is able to handle.)
- Peak Power Handling: 1600 watts (The maximum amount of power an electronic device, like a speaker, can handle without damage. This refers to short bursts of power, while root mean square (RMS) power handling indicates the amount of continuous power a device can sustain. Higher levels of distortion can also occur at peak power levels when the device is powered beyond its recommended usage.)
- Impedance: 2 ohms (Describes the resistance of an electric signal throughout the system. Devices with low impedance require less power to deliver optimal signals but are more at risk for damage from overloading. Higher impedance requires more power but is more protected from overload damage.)
- Woofer Size: 12"
- General
- Brand: NVX
- Model Number: ysw122
- Product Name: YSW122 1600W Peak (800W RMS) Y-Series 12in Dual 2-Ohm Car Subwoofer
- Number of Subwoofers Included: 1
- Audio Power
- RMS Power: 800 watts (The maximum amount of continuous power the device is able to handle.)
- Peak Power Handling: 1600 watts (The maximum amount of power an electronic device, like a speaker, can handle without damage. This refers to short bursts of power, while root mean square (RMS) power handling indicates the amount of continuous power a device can sustain. Higher levels of distortion can also occur at peak power levels when the device is powered beyond its recommended usage.)
- Audio
- Impedance: 2 ohms (Describes the resistance of an electric signal throughout the system. Devices with low impedance require less power to deliver optimal signals but are more at risk for damage from overloading. Higher impedance requires more power but is more protected from overload damage.)
- Features
- Marine: false
- Dimensions
- Woofer Size: 12"
- Product Height: 10 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 13.78 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 13.78 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 20.17 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1-year Manufacturer's Warranty
- Warranty - Labor: 1-year Manufacturer's Warranty
- Other
- UPC: 810021845456
Product Details: 12" Dual 2 ohm Y-Series Subwoofer. Power Handling: . Peak: 1600 watts. RMS: 800 watts. 15 mm Xmax. Enhanced Pressed Paper Cone. Custom High-Roll Foam Surround with Black Nylon Stitching. Stamped Steel Vented Basket with NVX Punched Logo. 3. 0" High Temperature Copper Voice coil with Aluminum Former. Progressive Roll Dual-layer Spider with Integrated Tinsel Leads. Optimized High-Velocity Pole Vent. 116 oz. Double Stacked Ferrite Magnet with Protective Rubber boot. Frequency Response: 20 - 200 Hz. Resonance Frequency (Fs): 27. 3 Hz. Sensitivity: 85 dB. Recommended sealed box volume: . 75 cubic feet. Recommended ported box volume: 1. 85 cubic feet. Top-mount depth: 6. 5". Cutout diameter: 11. 14". CTA-2031 Compliant. Authorized Internet Dealer. 1-year Manufacturer's Warranty. Priced Individually. NVX YSW122
- Exceptional Power Handling: Capable of delivering 1600 watts peak and 800 watts RMS, this subwoofer brings deep, powerful bass to your car audio system.
- Premium Build Materials: Features an enhanced pressed paper cone and custom high-roll foam surround with black nylon stitching for precise, distortion-free sound.
- Heavy-Duty Design: Built with a 3.0" high-temperature aluminum voice coil and a vented stamped steel basket with the NVX punched logo for superior heat dissipation and durability.
- Maximum Efficiency: Equipped with a 116 oz. double-stacked ferrite magnet, protective rubber boot, and optimized high-velocity pole vent to ensure efficient cooling and extended performance.
- Versatile Dual 2-Ohm Impedance: Offers flexible wiring configurations, with a wide frequency response of 20 - 200 Hz and a sensitivity of 85 dB for clear, resonant bass.
Whats Included
- 1
Compare similar products
Product Details: 12" Dual 2 ohm Y-Series Subwoofer. Power Handling: . Peak: 1600 watts. RMS: 800 watts. 15 mm Xmax. Enhanced Pressed Paper Cone. Custom High-Roll Foam Surround with Black Nylon Stitching. Stamped Steel Vented Basket with NVX Punched Logo. 3. 0" High Temperature Copper Voice coil with Aluminum Former. Progressive Roll Dual-layer Spider with Integrated Tinsel Leads. Optimized High-Velocity Pole Vent. 116 oz. Double Stacked Ferrite Magnet with Protective Rubber boot. Frequency Response: 20 - 200 Hz. Resonance Frequency (Fs): 27. 3 Hz. Sensitivity: 85 dB. Recommended sealed box volume: . 75 cubic feet. Recommended ported box volume: 1. 85 cubic feet. Top-mount depth: 6. 5". Cutout diameter: 11. 14". CTA-2031 Compliant. Authorized Internet Dealer. 1-year Manufacturer's Warranty. Priced Individually. NVX YSW122
Pump up the bass with this CompR 12-inch subwoofer enclosure. This setup features Kicker's 12-inch, 2-ohm subwoofer installed in a carpeted, black MDF box. The enclosure also features a double-stacked magnet and internal bracing for secure operation. This CompR 12-inch subwoofer enclosure operates on 500W of power and can produce 1000W of peak power.
Hook this 12-inch CompR subwoofer to 500W of power in a sealed or ported enclosure for intense power and reliability. The Spiralead tinsel emits powerful sound, while ribbed Santoprene surround produces deep, clear, chest-thumping bass notes. This CompR subwoofer has dual voice coils with 2 ohms for flexible system design. Geek Squad Installation Recommended Visit your local Best Buy store for more information.
The CompRT Down-Firing Subwoofer Enclosures come loaded with a passive reFLEX subwoofer and KICKER CompRT active subwoofers. The patented design of the TRTP was created in-house by KICKER engineers. The new benchmark in ultra-thin, pre-loaded enclosures, the TRTP’s unique shape and beefy construction are the perfect combination of convenience and reliability. Place the TRTP under your truck seat or cargo area for great bass – no grille needed! Covered in stylish black carpeting and built with thick MDF, these tough enclosures take serious power without taking up needed space. Heat is the enemy of endurance. To make our subs even more reliable, KICKER engineers developed Forced-Air Cooling to help our CompRT subs run 25 percent cooler. RoHS Compliant.
| Pros for NVX - YSW122 1600W Peak (800W RMS) Y-Series 12in Dual 2-Ohm Car Subwoofer | |||
|---|---|---|---|
| There were no pros for this product— | Sound Quality, Bass, Size, Price, Power | Sound Quality, Bass, Price, Power, Size | Sound Quality, Bass, Size, Price, Design |
| Cons for NVX - YSW122 1600W Peak (800W RMS) Y-Series 12in Dual 2-Ohm Car Subwoofer | |||
| There were no cons for this product— | Durability, Weight | Durability | Durability, Power Handling |
Specs
Reviews
This product doesn't have any reviews yet.
