Denon - PMA-1700NE 140W 2.0-Ch Integrated Amplifier - Black
- Key Specs
- Continuous Watts x Channel @ Ohms: 70W x 2 @ 8 Ohms, 140W x 2 @ 4 Ohms.
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Audio Only Inputs: 1 x USB-B, Unbalanced RCA, 2 x Optical digital audio, 1 x Coaxial digital audio, 1 x Phono
- Preamp Outputs: true
- General
- Brand: Denon
- Model Number: PMA1700NEBK
- Product Name: PMA-1700NE 140W 2.0-Ch Integrated Amplifier
- Color: Black
- Audio
- Continuous Watts x Channel @ Ohms: 70W x 2 @ 8 Ohms, 140W x 2 @ 4 Ohms.
- Maximum Watts x Channel @ Ohms: 140W x 2 @ 4 Ohms (This is the maximum load the speaker, subwoofer or amp can drive.)
- Number of Channels: 2 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Number of Audio Zones: 1 (Audio zones, typically designated by rooms in a home, are areas in which all speakers are dependent on the same sound source. Whether a zone encompasses one or multiple rooms, the receiver or preamp/processor is used to control all aspects of its audio and is able to select which zones receive sound.)
- Minimum Frequency Response: 5 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 100 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Amplifier Class: AB (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Amplifier Type: Integrated amplifiers
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Inputs
- Audio Only Inputs: 1 x USB-B, Unbalanced RCA, 2 x Optical digital audio, 1 x Coaxial digital audio, 1 x Phono
- Speaker-Level Inputs: true (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- Line-Level Inputs: true (Also referred to as low-level inputs. Enables the amplifier to receive a sound signal from another device via RCA cables.)
- Outputs
- Preamp Outputs: true
- Features
- App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Bridgeable: false (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Connectivity
- Wireless Multi-Room Audio: false (Technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Dimensions
- Product Height: 5.3 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 17.1 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 16.2 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 39.8 pounds (The out of box weight of the item.)
- Other
- UPC: 747192137632
The Denon PMA-1700NE Stereo Integrated Amplifier powered with Ultra-High Current (UHC) single push-pull circuit power amplifier provides exceptional sound quality that balances high power with delicate, musical details. Equipped with Advanced AL32 Processing Plus which supports high-resolution audio sources and delivers highly detailed, free of interference, richly expressive, and beautifully faithful to the original sound. Featuring a vibration-resistant six-block design, the amp reduces the adverse audio effects and the vibration surrounding the chassis and reproduces pristine sound with no distortions. The Analog Mode allows the PMA-1700NE to operate as a purely analog amp, disabling coaxial digital and optical digital inputs and stopping operation of the digital input circuitry. Enjoy your favorite analog sources with unmatchable clarity and detailed reproduction. Equipped with 3 Optical & Coaxial Digital Inputs, 1 USB-DAC input, and 1 Phono Input, the amp allows you to connect various audio sources such as a CD Player, Blu-Ray, TV audio, turntables and more to create a complete home theater system.
- Powerful 2-Ch Integrated Amplifier: The Denon PMA-1700NE 2-Channel Integrated Amplifier (140W x 2) with Advanced AL32 Processing Plus supports high-resolution 384-kHz/32-bit audio sources and delivers highly detailed, rich playback beautifully faithful to the original sound
- Precise, Detailed Audio Output: Powered by the Denon advanced ultra-high current single (UHC) push-pull circuit, this amp perfectly balances high power & music details - the audio output is clean, rich, and immersive. The UHC design ensures drivability of a wide range of loudspeakers
- Enjoy your Vinyl Collection: Features a built-in phono equalizer that supports input from both MM and MC cartridges, the integrated amp brings your vinyl records to life. With the analog mode, you can turn off power to digital sources for a smooth playback from analog sources
- Versatile Connection Options: The stereo amp is equipped with 3 digital inputs for connecting audio sources like CD players, Blu-Ray, TV audio, and more, a USB-DAC for seamless D/A conversion, and pre-amp input terminals for connecting external amplifiers
- Compatible with Various Audio Formats: The hi-res audio certified amp supports a wide range of audio formats including MP3, ALAC, WAV, FLAC HD, and DSD, so you can enjoy your audiophile-quality digital collection from a USB drive or through your network connection
- Built with Thoughtfully Selected Audio Components: With more than 110 years of defining audio excellence, Denon brings purity of sound and joy to your lives. Immerse yourself in an unmatchable home theater audio experience in a sleek, modern design
Whats Included
- power cord
- remote
- 2xAAA batteries
- Amplifier
- 2 x External Antennas
Product Manuals
Q: What is the weight of the amplifier?
A: The product weight of the Denon PMA-1700NE Integrated Amplifier is 39.8 pounds.
Q: What is the maximum frequency response of the amplifier?
A: The maximum frequency response is 100 kilohertz.
Q: What is the power output of the amplifier at 8 ohms?
A: The Denon PMA-1700NE Integrated Amplifier has a continuous power output of 70 watts per channel at 8 ohms.
Q: What is the purpose of the Analog Mode?
A: The Analog Mode allows the PMA-1700NE to operate as a purely analog amp, disabling coaxial digital and optical digital inputs and stopping operation of the digital input circuitry.
Q: Can the amplifier be used with a turntable?
A: This amplifier allows you to connect various audio sources such as a CD Player, Blu-Ray, TV audio, turntables and more.
A: Hello Scoob. Yes - with the addition of an optional speaker switching box with impedance correction, the PMA-1700NE is well equipped to drive the 601's, AM5's (so long as the cube speakers are wired through the Bass Module), and the CS99A's at conventional volume levels in a typical domestic setting. I suggest speaking with a Best Buy Audio Specialist for details on the speaker switching box options.
A: Hello. Yes - the PMA-1700NE can accept all the components you list. That sound like an impressive system with lots of functionality.
