Frigidaire - 30 inches - Convertible - Under cabinet Range Hood - Black
- Key Specs
- Color Finish: Black
- Product Height: 5 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 30 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 18 5/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Top/Rear
- Vent Type: Ducted, Ductless
- Vent Style: Convertible (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Frigidaire
- Model Number: FHWC3025MB
- Product Name: 30" Convertible Range Hood
- Color: Black
- Color Finish: Black
- Dimensions
- Product Height: 5 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 18 inches
- Product Width: 30 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 18 5/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 12 pounds (The out of box weight of the item.)
- Duct Shape: Rectangular
- Duct Length: 18 5/8 inches
- Duct Width: 30 inches
- Features
- Exhaust Vent Location: Top/Rear
- Vent Type: Ducted, Ductless
- Vent Style: Convertible (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Under cabinet
- Number of Fan Speeds: 2
- Temperature Sensor: false (Integrated sensor adjusts ventilation power as needed to accommodate high temperatures.)
- Control Type: Rocker
- Delay Shut-Off: false (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: false
- Remote Control: false
- Damper Included: true
- Integrated Light(s): true
- Number of Lights: 1
- Number of Light Levels: 1
- Bulb Type Required: Incandescent
- Bulb(s) Included: true
- Maximum Bulb Wattage: 75 watts
- Performance
- Maximum Air Flow Capacity: 220 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Minimum Operating Sound Level: 16 sones (The perceived intensity of the operating sound produced by the product at its lowest setting. The higher the sone rating, the louder the noise level.)
- Filter Info
- Dishwasher-Safe Filter: true
- Removable Grease Filter: true
- Number of Filters: 2
- Electrical Specification
- Amperage: 15 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): CSA Listed, UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Warranty
- Warranty - Parts: 1 year limited
- Warranty - Labor: 1 year limited
- Other
- UPC: 012505562624
This Frigidaire FHWC3025MB 30" convertible range hood features incandescent lighting that illuminates your cooktop surface for a clear view. The 2-speed exhaust fan helps remove smoke and odors from the air.
- 220 cfm blower and 2-speed fan: Blows cooking odors and smoke out of your kitchen.
- Rocker switch controls: Enable easy operation.
- Incandescent surface light: Shines down on your stovetop to ensure a clear view while you're cooking.
- Dishwasher-safe aluminum filter: Helps remove impurities from the air and can easily be cleaned.
- Convertible exhaust duct options: Let you choose between ventilating outside with ducting or recirculating air inside without ducting.
- Black finish: Provides a stylish appearance that complements your existing décor.
- Designed to fit 7" round or 3-1/4" x 10" ductwork: To make installation simple.
- 220 cfm blower and 2-speed fan: Blows cooking odors and smoke out of your kitchen.
- Rocker switch controls: Enable easy operation.
- Incandescent surface light: Shines down on your stovetop to ensure a clear view while you're cooking.
- Dishwasher-safe aluminum filter: Helps remove impurities from the air and can easily be cleaned.
- Convertible exhaust duct options: Let you choose between ventilating outside with ducting or recirculating air inside without ducting.
- Black finish: Provides a stylish appearance that complements your existing décor.
- Designed to fit 7" round or 3-1/4" x 10" ductwork: To make installation simple.
Whats Included
- 30" Convertible Range Hood
- Owner's manual
- 30" Convertible Range Hood
- Owner's manual
Q: does this hood also have a alight
A: Yes, the hood does have a light.
A: Great question, Zane1! After some research and based on the information provided this range hood should work for you. -Ciara
Q: Does this unit come with a power cord option or do you have to buy a separate power cord kit?
A: No, this does not come with a power cord option.
Q: What size/type incandescent light bulb do I use with the range hood?
A: Hello Frigidaire Shopper! The light bulb required in the range hood is a 75 watt 120 volt incandescent bulb. Hopefully this information is helpful towards your shopping experience. –Thanks!-
Q: Can this be used as an "under the cabinet" range hood?
A: Hello, Thank you for your inquiry. Range hood model FHWC3025MS can be installed as a under the cabinet, as well as range hood model FHWC3625MS. Thank you.
A: Hello, Jason. We appreciate your inquiry. Please know that these models of the Frigidaire 30" Overhead Range Hood have the same model number. The last letter of the model number indicates the color. We hope this information helps! - Christi
Q: Can this be used under cabinet and above cooktop? i do not have a range. does it matter?
A: Thank you for your inquiry, Jinfr73! After viewing the Installation Guide, we were able to see this model can be installed under a cabinet or above a cook-top. The range hood location should be away from strong draft areas, such as windows, doors and strong heating vents. We hope this information was helpful to you and your shopping experience. -Ciara
