Garmin - ECHOMAP Chartplotter GPS UHD2 73sv with transducer - Black
FREE shipping to
Specifications
- Screen Size7 inchesTouch ScreenYes3D-Map ViewYesChartplotterYesTopographic MapsYesProgrammable RoutesYes
- Key Specs
- Screen Size: 7 inches (Size of the screen, measured diagonally from corner to corner.)
- Touch Screen: true (Touch-screen devices make navigating more intuitive. Using a touch-screen display, you can do things such as tap to select, hold and drag to move items, swipe to scroll, and pinch to zoom.)
- 3D-Map View: true
- Chartplotter: true
- Topographic Maps: true
- Programmable Routes: true
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Fish Finder: true
- General
- Brand: Garmin
- Model Number: 010-02684-01
- Product Name: ECHOMAP Chartplotter GPS UHD2 73sv with transducer
- Color: Black
- Designed Usage: Boating
- Display
- Screen Size: 7 inches (Size of the screen, measured diagonally from corner to corner.)
- Touch Screen: true (Touch-screen devices make navigating more intuitive. Using a touch-screen display, you can do things such as tap to select, hold and drag to move items, swipe to scroll, and pinch to zoom.)
- Color Display: true
- 3D-Map View: true
- Resolution: 800 x 480 (Refers to the number of pixels, both horizontally and vertically, used to capture video/images. The higher the resolution the finer the detail that can be seen.)
- Backlit Display: true (Integrated lights allow for visibility of the display in low-light conditions.)
- Display Type: Other
- Multi Window Display: true
- Fish Icon Display: true
- Map
- Integrated Base Maps: true
- Map Coverage Area: U.S.
- Map Provider: Navionics
- Number Of Waypoints: 5000
- Chartplotter: true
- Topographic Maps: true
- HD Mapping: true
- Optional Chart Upgrades: true
- Navigation
- Programmable Routes: true
- Voice Prompts: false
- Electronic Compass: true
- Environmental
- Water Resistant: true (Resists some degree of water penetration.)
- Maximum Depth Of Water Resistance: 3 feet (Measurement of the maximum depth of water in which the product is able to resist some degree of water penetration.)
- Hunt/Fish Calendar: true
- Features
- Location Reporting: true
- Radar: Included
- Storage
- Memory Card Slot: true
- Memory Card Included: false (Indicates whether a memory card is included.)
- Compatibility
- App Compatible: true (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
- Computer Compatibility: Android, Apple iOS
- Connectivity
- Bluetooth Enabled: true (The device is capable of communicating with another device via Bluetooth, provided they are within the required range of each other. A Bluetooth-enabled device must also be the same Bluetooth version or higher than the accessory it is intended to pair with.)
- Depthfinding
- Downscan Imaging: true
- Side Imaging: true
- Fish Finder: true
- Dimensions
- Product Height: 5.6 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 8.6 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 3.2 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 2.2 pounds (The out of box weight of the item.)
- Power
- Power Source: Hard wired
- Mounting
- GPS Mount Type: Flush
- Other
- UPC: 753759307899
The 7” ECHOMAP™ UHD2 touchscreen with keyed-assist chartplotter knows the water better than a local. See clear, sharp fish arches with Garmin traditional sonar. ClearVü™ and SideVü™ scanning sonars feature vivid color palettes for clear, high-contrast views all around your boat. ECHOMAP UHD2 also supports LiveScope™ sonar systems. Navigate the waters with built-in Garmin Navionics+™ cartography. Built-in Wi-Fi® connectivity lets you wirelessly share sonar, waypoints and routes with another ECHOMAP UHD2 chartplotter. Wherever you drop your line, get improved position accuracy, particularly in areas where signals are reflected or weak, with multi-band GPS. You can also pair with the free all-in-one ActiveCaptain® app on your compatible smartphone for access to the OneChart™ feature, software updates and more. The chartplotter supports NMEA 2000® networks to connect your compatible autopilots, digital switching, music, and more to view all on one screen.
- Sonar support: With crisp, clear traditional sonar and brilliant ClearVü and SideVü scanning sonars, the fish will have nowhere to hide. Your ECHOMAP UHD2 also supports LiveScope live-scanning sonar.
- Vivid color palettes: High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.
- Bundle your transducer: Your ECHOMAP UHD2 device supports a variety of Garmin transducers. The 6” and 7” chartplotters come bundled with a GT54 transducer — while the 9” chartplotter comes with a GT56 transducer.
- Preloaded charts: Know the waters you're in as if you grew up fishing them by using built-in Garmin Navionics+ coastal or inland mapping which includes a 1-year subscription for downloadable daily updates and more.
- Wirless networking: If you have another compatible ECHOMAP UHD2 chartplotter on your boat, the 5” and 7” models can wirelessly share information — such as sonar, waypoints and routes — with them.
- Activecaptain app: Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart feature, software updates, Garmin Quickdraw Community data and more.
- Auto Guidance+ technology: Chartplotters with built-in Garmin Navionics+ charts include downloadable Auto Guidance+ technology with the ActiveCaptain app.
- Troll with force: Your ECHOMAP UHD2 wirelessly connects to your Force trolling motor to create and follow routes, navigate to waypoints, control speed, check battery life and more.
- Power-Pole shallow water anchor: By networking select Garmin chartplotters with a Force trolling motor and your compatible Power-Pole shallow water anchoring system, you can access advanced boat control features4 from your plotter, including smart anchor auto-deployment, smart anchor jog, auto stow, anchor drag detection and auto guidance5 end-of-route anchoring. Spend more time fishing, less time positioning.
- CHARGE integration from Power-Pole: Your CHARGE Marine Power Manager from Power-Pole integrates with compatible Garmin chartplotters to help keep your battery power going longer and stronger on the water. You’re able to charge batteries on the run, monitor power use, select where power is allocated, control emergency starts and even transfer power between battery banks — all from your chartplotter display.
- Multi-band GPS: Get improved position accuracy, particularly in areas where signals are reflected or weak, with multi-band GPS.
Whats Included
- ECHOMAP UHD2 (device varies depending on selection)
- GT54-TM transducer
- Power/data cable
- Tilt/swivel mount with quick release cradle
- Protective cover
- Hardware
- Documentation
Q: Can I connect this chartplotter to my phone?
A: Yes, it has built-in Wi-Fi and pairs with the free ActiveCaptain app for access to OneChart, software updates, and more.
Q: Is this chartplotter compatible with a trolling motor?
A: Yes, the ECHOMAP UHD2 wirelessly connects to the Force trolling motor for creating routes, navigating to waypoints, controlling speed, and checking battery life.
Q: Does this device have preloaded charts?
A: Yes, it comes with built-in Garmin Navionics+ coastal or inland mapping, including a 1-year subscription for downloadable daily updates.
Q: How many waypoints can this device store?
A: It can store up to 5000 waypoints.
Q: What kind of sonar does this chartplotter use?
A: This chartplotter uses Garmin traditional sonar, ClearVü and SideVü scanning sonars, and it also supports LiveScope sonar systems.
Q: What type of GPS does this chartplotter have?
A: It uses multi-band GPS for improved position accuracy, especially in areas with weak or reflected signals.
Q: What is the screen size of this ECHOMAP UHD2?
A: The screen size is 7 inches.
Q: What kind of antenna does it require?
A: undefined
