Key Digital - 4K/18G HDBaseT POH Extenders Kit - Black Metal

Complete your home theater or conference room setup with these Key Digital 4K/18G HDBaseT POH extenders. With a super-slim chassis design, this long-reach extender system uses one power connection to send 1080p and 4K signals over CAT5e/6 UTP/STP extension. These Key Digital 4K/18G HDBaseT POH extenders feature CEC Pass-thru and Full Buffer System for enhanced control.

• HDBaseT via single Cat-5e/6 UTP/STP extension: Fully automatic adjustment of feedback, equalization, and amplification depending on cabling length.
• 4K support: The unit supports such resolution as 4096 x 2160 or 3840 x 2160 24/25/30/60Hz at 4:4:4 (signals up to 18 Gbps bandwidth).
• Power over HDBaseT: Only one power connection needed, the transmitter may power the receiver or the receiver may power the transmitter.
• Super slim low-profile design: Ensures flexible integration with no hassle.
• Signal extension: Provides extension up to 125' at 4K UHD using Cat-5e/6 or up to 230' at 1080p Full HD using Valens VS10.
• Long range mode: Extends 1080p signals up to 500' using Cat-5e/6 (UHD/4K not supported).
• 10G pass-through: Enables uncompressed 10.2 Gbps signal extension.
• HDR10 (High Dynamic Range): More lifelike images through greater range of luminance levels.
• HDMI and HDCP licensing: Fully licensed and compatible with HDCP 2.2 and HDMI latest technology, such as 4K/UHD 4:2:0/8-bit at 60 fps.
• EDID Control: Internal library with 15 EDID handshakes, including 4K with HDR in addition to native EDID data from an output/display device connected to Rx.
• Hot-plug detection control: Enables the integrator to choose if active signal voltage is forced to connected input and output devices.
• Full Buffer System: Manages TMDS re-clocking/signal re-generation, HDCP authentication with source and display, EDID Control handshake, and hot-plug detection control.
• 3D pass-through: Support for 3D enabled by default EDID handshake library or EDID copy from 3D supported display.
• IR sensor: Sensor powering via +5V on IR In ports collects line-of-sight IR from remote(s) without an external IR connecting block.
• Up/down IR: Two channels of IR enable control to/from devices or control systems connected to Tx and Rx units.
• RS-232: Bidirectional control to/from Tx and Rx unit on Phoenix connector.
• Lossless compressed digital audio: Support for Dolby® TrueHD, Dolby® Digital Plus, Dolby Atmos®, and DTS-HD Master Audio™.
• CEC pass-through: Offers inter-device control between the input and output HDMI channel.
