Mackie - ONYX24 24-Channel Premium Analog Mixer with 24-Bit 96kHz Multitrack Recording via USB, Bluetooth Streaming & Perkins EQ
Reviews coming soon
More Buying Options from Marketplace sellers
- General
- Brand: Mackie
- Model Number: 2051993-00
- Product Name: ONYX24 24-Channel Premium Analog Mixer with 24-Bit 96kHz Multitrack Recording via USB, Bluetooth Streaming & Perkins EQ
- Dimensions
- Product Width: 17 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Height: 8.5 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Length: 28 inches (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 25.64 pounds (The out of box weight of the item.)
- Features
- Effect Type(s): None
- Number Of Channels: 24
- Other
- UPC: 663961058918
Bring classic analog sound and modern recording flexibility to the center of your setup with this 24-channel premium analog mixer, built for live sound, studio production, and content creation. It features 18 award-winning Onyx mic preamps with up to 60dB of gain and switchable 48V phantom power for condenser microphones, along with 19 line inputs, including five stereo channels, for versatile source connectivity. Hi-Z switches on channels 1 and 2 allow direct connection of guitars, basses, and other high-impedance instruments. Legendary Perkins “British style” EQ with sweepable midrange adds classic tonal shaping, while analog and USB channel strips with flexible routing, mute, and AFL/PFL solo options help you manage and monitor your signal path with greater control. A robust digital effects engine provides user-customizable reverbs, delays, and more, along with a dedicated FX EQ and built-in effects presets for added sound enhancement. The mixer supports high-resolution 24-bit / 96kHz multitrack recording to Mac or PC via USB, plus direct stereo recording and playback to SD card for added convenience. Bluetooth streaming lets you route wireless audio to an Aux send or the Main Mix, making it useful for playback during sessions or set breaks. Dedicated control room outputs, support for monitoring through studio monitors or headphones with dedicated level controls, 1/4" and XLR main outputs, 100Hz low-cut filters, and included Waveform OEM software round out a powerful, flexible mixer designed to be the heart of your production system.
- 18 Onyx Preamps Deliver Powerful Analog Mixing Control: At the heart of this 24-channel premium analog mixer are 18 award-winning Onyx mic preamps with up to 60dB of gain, giving you the headroom needed to capture detailed performances from a wide range of microphones. With premium analog circuitry designed to keep noise to a minimum, this mixer delivers studio-quality sound and professional performance for both live use and recording applications.
- Flexible Inputs, Hi-Z Channels, And Routing Options Built In: This mixer offers 19 line inputs, including 5 stereo channels, for the kind of connectivity that works well in studio and live environments alike. Hi-Z switches on channels 1 and 2 allow direct connection of guitars, basses, and other high-impedance instruments, while analog and USB channel strips with mute plus AFL and PFL solo options provide flexible routing and practical signal-path monitoring as needed.
- Perkins EQ And Built-In FX Expand Sound Shaping Power: Legendary Perkins British-style EQ with sweepable midrange helps add classic analog tone inspired by the sounds of the 60s and 70s, while a robust digital effects engine adds even more creative control. With user-customizable reverbs, delays, and more, plus a dedicated FX EQ and built-in effect presets, this mixer gives you practical tools for shaping and enhancing your sound right out of the box.
- 24-Bit 96kHz USB And SD Recording Support Workflow: When your mix is dialed in, this mixer supports high-resolution 24-bit / 96kHz multitrack recording to Mac or PC via USB, plus direct stereo recording and playback to SD card for added convenience. This makes it a strong solution for users who want flexible capture options for studio sessions, live recording, and content production without relying on a more complicated external recording setup.
- Bluetooth Streaming And Pro Outputs Add Everyday Utility: Integrated Bluetooth streaming makes it easy to send wireless audio to an Aux send or the Main Mix, which is especially useful for set-break music or playback in a live environment. Dedicated control room outputs, support for monitoring through studio monitors or headphones with dedicated level controls, 1/4" and XLR main outputs, 100Hz low-cut filters, 48V phantom power, and included Waveform OEM software complete the package.
Whats Included
- 1 - ONYX24 24-Channel Premium Analog Mixer
