MSI - NVIDIA GeForce RTX 5060 8G GAMING TRIO OC 8GB GDDR7 PCI Express Gen 5 Graphics Card - White
MSI - NVIDIA GeForce RTX 5060 8G GAMING TRIO OC 8GB GDDR7 PCI Express Gen 5 Graphics Card - White
Related Item
Specifications
- GPU Base Clock Frequency2.28 gigahertzGPU Boost Clock Frequency2.625 gigahertzDisplayPort Ports3 x DisplayPort 2.1HDMI Ports1 x HDMI 2.1Maximum Resolution8K (4320p)Maximum Number of Displays Supported4
- Key Specs
- GPU Base Clock Frequency: 2.28 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.625 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 1 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- GPU Video Memory (RAM): 8 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- Slot Size: 2.5-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 5.0
- Product Height: 150 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 66 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 357 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5060 (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- General
- Brand: MSI
- Model Number: G5060-8GTCW
- Product Name: NVIDIA GeForce RTX 5060 8G GAMING TRIO OC White 8GB GDDR7 PCI Express Gen 5 Graphics Card
- Color: White
- GPU Chipset Manufacturer: NVIDIA
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5060 (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- Year of Release: 2025
- Performance
- GPU Base Clock Frequency: 2.28 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.625 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- Cooling System: Fan (A computer's CPU generates heat while operating and requires a cooling system to keep internal components functioning properly. Air cooling uses fans to draw in cool air and exhaust hot air, while liquid cooling uses coolant-filled tubes and water blocks to regulate internal temperature more efficiently.)
- Connectivity
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 1 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Display
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- Memory
- GPU Video Memory (RAM): 8 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- GPU Video Memory Base Clock Frequency (RAM): 28 gigahertz
- Compatibility
- Slot Size: 2.5-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 5.0
- Operating System Compatibility: Windows
- Power
- Total Graphics Power: 155 watts
- Recommended Power Supply: 550 watts
- Dimensions
- Product Height: 150 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 66 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 357 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 2.94 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 3 years
- Other
- UPC: 824142422779
The MSI Gaming Trio OC series graphics card captures the spirit of exploration, blending premium gaming craftsmanship with aerodynamic contours, bold fractured lines, and futuristic RGB lighting. Designed to empower players, it pushes the limits of performance as they journey into uncharted worlds
- Graphics Processing Unit (GPU)/Clock Speed: Powered by the NVIDIA GeForce RTX 5060 graphics processing unit (GPU) with boost clock.
- 8GB GDDR7: 8GB GDDR7 video memory.
- Interface Compatibility: PCI Express Gen 5 offers compatibility with a range of systems.
- NVIDIA G-SYNC: The ultimate gaming display technologies.
- TRI FROZR 4 Thermal Design: Upgraded fans, enhanced airflow control, and advanced thermal innovations provide superior cooling and quieter operation, boosting the overall performance of the graphics card.
Whats Included
- NVIDIA GeForce RTX 5060 8G GAMING TRIO OC White 8GB GDDR7 PCI Express Gen 5 Graphics Card
- Support Stand
- Adapter Cable
Q: What is the maximum resolution supported by this graphics card?
A: The maximum resolution supported by this graphics card is 8K (4320p).
Q: What is the video memory type of this graphics card?
A: The video memory type is GDDR6.
Q: How many displays can this graphics card support?
A: This graphics card can support a maximum of four displays.
Q: What is the boost clock frequency of the GPU?
A: The GPU boost clock frequency is 2.625 gigahertz.
Q: How many HDMI ports does this graphics card have?
A: This graphics card has one HDMI 2.1 port.
Q: How much power does this graphics card consume?
A: This graphics card consumes a total graphics power of 155 watts.
Q: Does this graphics card use DLSS for advanced rendering?
A: Yes, this graphics card uses DLSS 4 (Deep Learning Super Sampling) for advanced graphics rendering.
Q: Is this a good budget graphics card for game development and what cpu would go with this
A: Hello Honor - the CPU recommendation will depend on the software you will be utilizing for development and will be best to pair with the software developers recommendations.
Compare similar products
The MSI Gaming Trio OC series graphics card captures the spirit of exploration, blending premium gaming craftsmanship with aerodynamic contours, bold fractured lines, and futuristic RGB lighting. Designed to empower players, it pushes the limits of performance as they journey into uncharted worlds
The MSI VENTUS OC series graphics card delivers reliable performance with a no-nonsense design philosophy. Featuring a robust cooling solution, clean-cut aesthetics, and precision engineering, VENTUS OC is built to power through demanding games and applications. It's a streamlined solution for gamers who value strength, efficiency, and straightforward power.
Ahead of its time, ahead of the game is the GIGABYTE GeForce RTX 5060 AERO OC 8G Graphics Cards. Powered by NVIDIA's new RTX architecture, the GIGABYTE GeForce RTX 5060 AERO OC 8G brings stunning visuals, amazingly fast frame rates, and AI acceleration to games and creative applications with its enhanced RT Cores and Tensor Cores, along with a staggering 8 GB of GDDR7 memory.
MSI RTX 5060 Ti 8G SHADOW 2X OC PLUS brings a performance-focused design that delivers the gaming experience players want, making it the ideal choice when upgrading or building a gaming rig.
| Pros for MSI - NVIDIA GeForce RTX 5060 8G GAMING TRIO OC 8GB GDDR7 PCI Express Gen 5 Graphics Card - White | |||
|---|---|---|---|
| There were no pros for this product— | Performance | There were no pros for this product— | There were no pros for this product— |
Specs
Reviews
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 5 out of 5 stars
Love this gpu
Love the look of the design, especially when it’s on. Runs smoothly and looks good!
This review is from MSI - NVIDIA GeForce RTX 5060 8G GAMING TRIO OC 8GB GDDR7 PCI Express Gen 5 Graphics Card - White
LoganD Posted
- Rated 5 out of 5 stars
good affordable gift
Got this as a christmas gift very good and affordable deal! nice upgrade from my 3050 dual
This review is from MSI - NVIDIA GeForce RTX 5060 8G GAMING TRIO OC 8GB GDDR7 PCI Express Gen 5 Graphics Card - White
jjezicale Posted
- Rated 5 out of 5 stars
Affordable, Yet Powerful
This was exactly what i wanted. It came in sealed and protected.
This review is from MSI - NVIDIA GeForce RTX 5060 8G GAMING TRIO OC 8GB GDDR7 PCI Express Gen 5 Graphics Card - White
RavReviews Posted
