Pioneer - Compact Class FD 4-Channel Amplifier - Black
More Buying Options from Marketplace sellers
Specifications
- Continuous Watts x Channel @ Ohms45 W x 4-Channel - 4 OhmAmplifier ClassDNumber Of Channels4Bass BoostNone
- Key Specs
- Continuous Watts x Channel @ Ohms: 45 W x 4-Channel - 4 Ohm
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Number Of Channels: 4
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- General
- Brand: Pioneer
- Model Number: GM-DX104
- Product Name: Compact Class FD 4-Channel Amplifier
- Color: Black
- Audio Power
- Continuous Watts x Channel @ Ohms: 45 W x 4-Channel - 4 Ohm
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Audio
- Number Of Channels: 4
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Features
- Marine: false
- Dimensions
- Product Height: 2.5 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 1.5 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 7.125 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 1.3 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: 1 year
- Other
- UPC: 884938525664
Experience unparalleled sound quality with compatibility for high-resolution audio sources, delivering rich detail, an expansive soundstage, and stunning realism. Engineered with high-performance operational amplifiers, the GM-DX104 minimizes noise in small-signal circuits to produce crystal-clear tones across a wide bandwidth. This compact amplifier also offers the flexibility to amplify 4, 3, or 2 speakers by bridging or not bridging the outputs, resulting in available power of 4x 45 watts RMS at 4 ohms or 90 watts RMS when bridged. Its compact, energy-efficient design and high-voltage compatibility ensure effortless installation in virtually any vehicle, making it the ultimate choice for audiophiles seeking exceptional performance and versatility.
- Exceptional Sound Quality Beyond Its Size: Achieve premium audio performance with the GM-DX104, designed with high-resolution compatible components for outstanding sound clarity.
- Adaptable Installation for Any Vehicle: The compact design of the GM-DX104 eliminates the need for extra space, allowing for seamless installation in virtually any vehicle.
- Easy and Efficient Installation: The GM-DX104 simplifies installation with no need for wiring to the engine compartment, significantly reducing setup time.
- High Voltage Compatibility for Versatile Applications: Engineered for compatibility with high voltage systems up to 16V, the GM-DX104 is an ideal solution for electric vehicles (EVs) and other advanced applications.
- High-Quality Affordable Design: Pioneer designed a high-quality power supply to sustain constant power requirements.
- Hi-Res Certified: An optimal printed circuit board design reduces signal interference, improves channel separation, and provides better dynamics and lower distortion.
- Gold Plated Terminals: These terminals maintain an accurate signal with increased electrical conductivity, prevent corrosion, and offer enhanced durability with excellent resistance to wear.
- Pioneer’s TVC (Total Vibration Control): Pioneer's TVC (Total Vibration Control) concept used in this amplifier not only increases the rigidity of the unit but also counteracts vibrations that affect sound quality at various points.
Whats Included
- Amplifier
- Connector Cables
- Mounting Screws
Product Manuals
