Seasonic - VERTEX GX-1200 - 1200W - 80+ Gold - ATX 3.0 & PCIe 5.0 Ready - Full-Modular - ATX Form Factor - Low Noise
Related Item
Specifications
- Wattage1200 wattsModularFully modularEnergy Efficiency80 PLUS GoldATX Connector5PCIe Connector12V-2x6EPS12V Connector0
- Key Specs
- Wattage: 1200 watts (Measurement of electrical power.)
- Modular: Fully modular
- Energy Efficiency: 80 PLUS Gold (Computer and server power supplies with the 80 PLUS certification are tested for operating efficiency at 10, 20, 50, and 100% of rated load. If a product tests at least 80% efficient, it qualifies for the base level 80 PLUS certification. Bronze, Silver, Gold, Platinum, and Titanium level certifications are given to products with even higher efficiency ratings.)
- ATX Connector: 5 (The configuration of the connector as it connects a computer power supply unit to an ATX motherboard.)
- PCIe Connector: 12V-2x6 (The configuration of the connector as it connects a computer power supply unit to a PCIe (Peripheral Component Interconnect Express) motherboard interface.)
- EPS12V Connector: 0 (The configuration of the connector as it connects a computer power supply unit to a EPS12V motherboard interface.)
- PCI Express Version: PCI Express 5.0
- Form Factor: ATX (The size, arrangement, and physical configuration of the product.)
- Product Length: 86 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- General
- Brand: Seasonic
- Product Name: VERTEX GX-1200 - 1200W - 80+ Gold - ATX 3.0 & PCIe 5.0 Ready - Full-Modular - ATX Form Factor - Low Noise
- Power
- Wattage: 1200 watts (Measurement of electrical power.)
- Modular: Fully modular
- Energy Efficiency: 80 PLUS Gold (Computer and server power supplies with the 80 PLUS certification are tested for operating efficiency at 10, 20, 50, and 100% of rated load. If a product tests at least 80% efficient, it qualifies for the base level 80 PLUS certification. Bronze, Silver, Gold, Platinum, and Titanium level certifications are given to products with even higher efficiency ratings.)
- Power Cord Included: true (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Connectivity
- ATX Connector: 5 (The configuration of the connector as it connects a computer power supply unit to an ATX motherboard.)
- PCIe Connector: 12V-2x6 (The configuration of the connector as it connects a computer power supply unit to a PCIe (Peripheral Component Interconnect Express) motherboard interface.)
- EPS12V Connector: 0 (The configuration of the connector as it connects a computer power supply unit to a EPS12V motherboard interface.)
- PCI Express Version: PCI Express 5.0
- Form Factor: ATX (The size, arrangement, and physical configuration of the product.)
- Dimensions
- Product Height: 160 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 150 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 86 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 116.48 ounces (The out of box weight of the item.)
- Warranty
- Warranty - Parts: None
- Warranty - Labor: None
- Other
- UPC: 882016002380
Fully compatible with ATX 3.1 and PCIe 5.1 standards. Full modularity for the best cable management options. Added 12V-2×6 cable to comply with the new graphic cards. 135mm Fluid Dynamic Bearing (FDB) fan for quiet operation. Seasonic Hybrid Silent Fan Control for optimal cooling. Complete protection features: OPP / OVP / UVP / SCP / OCP / OTP.
- Micro Tolerance Load Regulation: Seasonic’s latest design keeps the output voltage within a very tight range, achieving under 0.5 % load regulation. This impressive electrical performance and stability makes this power supply an ideal choice for high-performance systems.
- Digital Hybrid Fan Control: Seasonic’s vast experience in designing the most silent and efficient power supplies on the market was translated into the development of Hybrid Mode; a state-of-the-art digital fan control that enables users to keep the overall fan noise at the lowest possible level.
- Fluid Dynamic Fan Bearing: High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption.
- Micro Tolerance Load Regulation: Seasonic’s latest design keeps the output voltage within a very tight range, achieving under 0.5 % load regulation. This impressive electrical performance and stability makes this power supply an ideal choice for high-performance systems.
- Digital Hybrid Fan Control: Seasonic’s vast experience in designing the most silent and efficient power supplies on the market was translated into the development of Hybrid Mode; a state-of-the-art digital fan control that enables users to keep the overall fan noise at the lowest possible level.
- Fluid Dynamic Fan Bearing: High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption.
