Wavtech - Link1500.1plus 1500 Watt Mono Amplifier - Black/Gray
Specifications
- Amplifier ClassDNumber Of Channels1Bass BoostVariable
- Key Specs
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Number Of Channels: 1
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- General
- Brand: Wavtech
- Model Number: Link1500.1plus
- Product Name: Wavtech Link1500.1plus 1500 Watt Mono Amplifier
- Color: Black/Gray
- Audio Power
- Total Power Handling RMS: 1500 watts
- Total Power Handling Maximum: 3000 watts
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Audio
- Number Of Channels: 1
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Features
- Bluetooth Enabled: false (The device is capable of communicating with another device via Bluetooth, provided they are within the required range of each other. A Bluetooth-enabled device must also be the same Bluetooth version or higher than the accessory it is intended to pair with.)
- Marine: false
- Dimensions
- Product Height: 18.000 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 8.000 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 14.000 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 10.0 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1-Year Manufacturer Warranty
- Warranty - Labor: None
- Other
- UPC: 700987201512
The link1500.1plus is the result of extensive engineering and development. The goal was an amplifier with the same power output at either 2 or 1 ohm. This amp makes 1500 watts RMS @ 2 or 1 ohm. This is achieved with our new dual rail voltage power supply. When setting up the amp, simply select the impedance of your subwoofer with the 4/2 or 1 ohm switch and the amp does the rest. At 13.11”x6.5”x1.65”, it is incredible small for a 1500 watt RMS amp. The link1500.1plus features our bassFREQ preamp, with a 24dB per octave crossover, an adjustable parametric EQ and a 24dB per octave subsonic filter. Like all Wāvtech amplifiers, the speaker level inputs of the link1500.1plus can handle up to 40V and have our adaptive loading technology. The optional linkRC remote allows for control of the subwoofer system from the vehicles front seat. The link1500.1plus is also compatible with OEM start/stop systems. link1500.1plus Features 1500 Watt Mono Amplifier 900 watts x 1 @ 4 ohms 1500 watts x 1 @ 2 ohms 1500 watts x 1 @ 1 ohm Only 13.11”x6.5”x1.65” Dual Rail Voltage Power Supply Fully Adjustable Parametric EQ Variable Low-Pass Crossover (-24dB/oct) Variable Subsonic Filter (-24dB/oct) Remote Level Control (RLC) w/Optional linkRC bassFREQ Bass Processor w/Parametic EQ Active Thermal Management Start/Stop System Compatible Adaptive OEM Load Technology 40V Input Capability Differential Balanced Inputs Variable Gain Adjustment w/Clip LED Auto Turn-On via DC-Offset or Audio Signal Detect Locking Detachable Hi-Level Speaker Terminals 0 Gauge Power/Ground Terminals Professional Grade Panel Mount RCA’s Compact Aluminum Chassis w/Detachable Mounting tabs link1500.1plus Specifications Input Sensitivity: SPK: 1-20Vrms, 2-40Vrms, RCA: 0.2V-5Vrms, 0.4V-10Vrms Max Input Voltage (SPK): 40Vrms Frequency Response: 500Hz (=0/-3dB) THD+N: <1% at rated power S/N: >77dBA (1W, 4Ω)
- Key Feature: Dual Rail Voltage Power Supply
- Key Feature: Fully Adjustable Parametric EQ
- Key Feature: Variable Low-Pass Crossover (-24dB/oct)
- Key Feature: Variable Subsonic Filter (-24dB/oct)
- Key Feature: bassFREQ Bass Processor w/Parametic EQ
- Key Feature: Dual Rail Voltage Power Supply
- Key Feature: Fully Adjustable Parametric EQ
- Key Feature: Variable Low-Pass Crossover (-24dB/oct)
- Key Feature: Variable Subsonic Filter (-24dB/oct)
- Key Feature: bassFREQ Bass Processor w/Parametic EQ
Whats Included
- Wavtech Link1500.1plus 1500 Watt Mono Amplifier
- Wavtech Link1500.1plus 1500 Watt Mono Amplifier
