Windster Hoods - 48 inches - Externally Vented - Range Hood Insert - Stainless Steel
Need-haul away?
Related Item
Specifications
- Color FinishStainless steelProduct Height4 inchesProduct Width46 3/8 inchesProduct Depth22 inchesExhaust Vent LocationTopVent TypeDucted
- Key Specs
- Color Finish: Stainless steel
- Product Height: 4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 46 3/8 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 22 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Top
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Windster Hoods
- Model Number: WS-69TS48SS
- Product Name: 48" Externally Vented Range Hood
- Color: Stainless Steel
- Color Finish: Stainless steel
- Dimensions
- Product Height: 4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 29 inches
- Product Width: 46 3/8 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 22 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 48 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 64 pounds (The out of box weight of the item.)
- Cut-Out Dimensions
- Cut-Out Width: 46.875 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Depth: 18.5 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Features
- Exhaust Vent Location: Top
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Insert
- Number of Fan Speeds: 3
- Temperature Sensor: false (Integrated sensor adjusts ventilation power as needed to accommodate high temperatures.)
- Control Type: Rocker
- Delay Shut-Off: false (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: false
- Remote Control: false
- Damper Included: false
- Integrated Light(s): true
- Number of Lights: 2
- Number of Light Levels: 3
- Bulb Type Required: Halogen
- Bulb(s) Included: true
- Maximum Bulb Wattage: 140 watts
- Performance
- Maximum Air Flow Capacity: 750 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Filter Info
- Dishwasher-Safe Filter: true
- Removable Grease Filter: false
- Electrical
- Amperage: 4 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): CSA Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Warranty
- Warranty - Parts: 2 years
- Warranty - Labor: 1 year
- Other
- UPC: 812641022620
Integrate kitchen ventilation into your custom cabinetry with this 48-inch Windster hood insert. It has three speed settings to effectively clear excess heat, smoke and airborne grease when needed. The four 35W halogen lights in this stainless steel Windster hood insert provide ample illumination while you prepare and cook meals.
- 750 cfm exhaust capacity: Quickly pull smoke and cooking odors out of the air.
- 3 fan-speed settings: Allow you to adjust ventilation to meet your needs.
- 140W halogen lights: Illuminate the cooktop below with bright or subtle lighting for better visibility while cooking.
- Stainless steel finish: Offers a sleek, stylish look.
- Designed to fit standard 8" round ductwork: For ease of installation.
Whats Included
- Windster 48" Externally Vented Range Hood
Product Manuals
Q: What is the amperage of this range hood?
A: The amperage of the 48" Externally Vented Range Hood by Windster Hoods is 4 amperes. This information can be found in the product specifications table under the "Amperage" row.
Q: Does this range hood have a temperature sensor?
A: No, this range hood does not have a temperature sensor. The product specifications clearly state "Temperature Sensor: false". The context mentions the range hood has three fan-speed settings, stainless steel finish, 140W halogen lights, and a 750 cfm exhaust capacity.
Q: What is the voltage requirement for this range hood?
A: The voltage requirement for the 48" Externally Vented Range Hood by Windster Hoods is 120 volts. This information can be found in the product specifications section, under the "Voltage" category.
Q: What is the maximum air flow capacity of this range hood?
A: The maximum air flow capacity of the 48" Externally Vented Range Hood by Windster Hoods is 750 cubic feet per minute (CFM). This information can be found in the "Product Specifications" section of the product description, under the "Maximum Air Flow Capacity" specification.
Q: Does this range hood have a delay shut-off feature?
A: The Windster Hoods 48" Externally Vented Range Hood does not have a delay shut-off feature. The context mentions "Auto Fan Shut-Off: false" and "Delay Shut-Off: false", indicating the absence of both automatic fan shut-off and delay shut- off features in this range hood.
Q: What is the minimum height above the cooktop that this range hood needs to be installed?
A: The minimum height above the cooktop that this range hood needs to be installed is 29 inches. This information is found in the installation section of the product specifications.
Q: How deep is this range hood?
A: The product depth of the 48" Externally Vented Range Hood by Windster Hoods is 22 inches.
Q: What type of mount does this range hood use?
A: The Windster Hoods 48" Externally Vented Range Hood uses an under-cabinet mount. This means that it is designed to be installed beneath a kitchen cabinet, with the bottom of the range hood flush against the underside of the cabinet.
