Zephyr - 36 inches - Convertible - Wall Range Hood - Black Stainless Steel
Color
Black Stainless SteelDelivery to
Need-haul away?
- We’ll haul away your old item and make sure it’s properly and safely recycled.
- We can also move it to another location in your home if the path is clear of obstructions.
- We can’t remove doors from your home (or a product) to make an item fit through a doorway
- Relocated appliances will not be connected to utilities
Related Item
Specifications
- Color FinishBlack stainless steelProduct Height27 inchesProduct Width35 7/16 inchesProduct Depth22 1/16 inchesExhaust Vent LocationTopVent TypeDucted, Ductless
- Key Specs
- Color Finish: Black stainless steel
- Product Height: 27 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 35 7/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 22 1/16 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Top
- Vent Type: Ducted, Ductless
- Vent Style: Convertible (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Zephyr
- Model Number: ZAN-M90DBS
- Product Name: Anzio 36 in. 600 CFM Wall Mount Range Hood with LED Light
- Color: Black Stainless Steel
- Color Finish: Black stainless steel
- Dimensions
- Product Height: 27 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 24 inches
- Maximum Installation Height Above Cooktop: 34 inches
- Product Width: 35 7/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 22 1/16 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 36 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 38.1 pounds (The out of box weight of the item.)
- Duct Shape: Round
- Round Duct Diameter: 6 inches
- Features
- Exhaust Vent Location: Top
- Vent Type: Ducted, Ductless
- Vent Style: Convertible (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Wall
- Number of Fan Speeds: 5
- Delay Shut-Off: true (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: true
- Remote Control: false
- Damper Included: false
- Integrated Light(s): true
- Number of Lights: 2
- Number of Light Levels: 2
- Bulb Type Required: LED
- Bulb(s) Included: true
- Maximum Bulb Wattage: 6 watts
- Performance
- Maximum Air Flow Capacity: 600 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Minimum Air Flow Capacity: 200 cubic feet per minute (Minimum amount of air that the appliance will ventilate at its lowest setting.)
- Filter Info
- Filter Material: Aluminum
- Dishwasher-Safe Filter: true
- Removable Grease Filter: true
- Number of Filters: 2
- Electrical Specification
- Amperage: 4 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 1 year
- Other
- UPC: 646328010699
Anzio, a low-profile, chimney-style range hood that will add style and value to any kitchen. Available in stainless steel and Titanium-coated, black stainless steel finishes for improved durability and easy cleaning. Complete with a 600-CFM blower, ICON Touch controls, LumiLight LED lighting and our exclusive Airflow Control Technology (ACT). Now available with an optional ADA-compliant remote control.
- Airflow Control Technology (ACT): Airflow Control Technology or ACT is an exclusive technology that gives installers the ability to set the maximum CFM levels to meet local code requirements.
- ICON Touch Controls: ICON Touch Controls seamlessly integrate into the hood’s stainless steel canopy, which lets users control functions such as the 5 speeds, delay-off, dual-level lighting, and auto reminders.
- Low-Profile Body: Low-profile body for a minimalist appearance.
- LumiLight LED Lighting: LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours. The tri-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
- Dual-Level Lighting: The dual-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
- Optional Ductless Recirculating Kit: Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen. (Part # ZRC-01AN)
- Optional Extension Duct Cover Kit: Extension duct cover kit to accommodate ceiling heights up to 12 ft. (see spec sheets for more details). (Part # Z1C-00ANBS)
Product Manuals
A: The optional ductless recirculating kit is used when venting air outside the home is not possible. It functions by passing smoke and odors through charcoal filters, purifying the air and reintroducing it into the kitchen. This allows for effective air filtration and odor removal even without an external ventilation system.
A: This range hood offers 5 fan speeds. Having multiple speed settings allows users to adjust the fan speed according to their cooking needs, from low speed for simmering to high speed for heavy-duty cooking. This helps in effectively removing smoke, grease, and odors from the kitchen.
A: The recommended maximum installation height above the cooktop for the Anzio 36 in. 600 CFM Wall Mount Range Hood with LED Light is 34 inches. This specification is important because installing the range hood too high can reduce its effectiveness in capturing smoke and fumes from cooking.
A: The ICON Touch Controls seamlessly integrate into the hood's stainless steel canopy, providing an intuitive and user- friendly interface. Users can effortlessly control various functions, including the 5 fan speeds, delay-off feature, dual-level lighting, and auto reminders, all at the touch of a button.
A: Yes, this range hood has a dual-level lighting feature. It allows users to control the brightness of the LumiLight LED lights, which are energy-efficient and provide uniform light distribution. This feature enhances the lighting options in the kitchen by providing adjustable lighting levels to suit different needs and preferences.
A: The minimum installation height for this range hood above the cooktop is 24 inches. Installing the range hood below this height may affect its performance by reducing its efficiency in capturing smoke and fumes from the cooktop.
A: The low-profile body design of the Anzio range hood contributes to its minimalist appearance. It provides a sleek and contemporary look that can complement various kitchen styles. The low-profile design allows the range hood to blend seamlessly into the surrounding cabinetry, creating a streamlined and modern aesthetic.
A: Yes, an optional extension duct cover kit is available for this range hood. Its purpose is to accommodate ceiling heights of up to 12 feet. The part number for this kit is Z1C-00ANBS.
