Zoom - LiveTrak L-12 Digital Mixer/Recorder - Black
More Buying Options from Marketplace sellers
Related Item
Reviews coming soon
- General
- Brand: Zoom
- Model Number: L-12
- Product Name: LiveTrak L-12 Digital Mixer/Recorder
- Color: Black
- Dimensions
- Product Width: 17.5 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Height: 2.78 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Length: 11.1 inches (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 5.58 pounds (The out of box weight of the item.)
- Features
- Effect Type(s): Delay, EQ, Reverb
- Number Of Effects: 16
- On-Screen Display: true
- Input(s): RCA, TRS, USB 2.0
- Output(s): TRS, USB 2.0, XLR
- Headphone Jack: true (The device features an interface that allows for the connection of headphones.)
- LED Metering: true
- Number Of Channels: 12
- Wattage: 17 watts (Measurement of electrical power.)
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: 1 year
- Other
- Recording Feature: true
- Operation: Analog, Digital
- Screen Display: true
- UPC: 884354018054
Mix and manage premium-quality tracks with this Zoom LiveTrak L-12 digital mixer. The 12 inputs with channel faders produce high-definition audio on stage or in the studio, while a built-in USB interface lets you connect directly to a computer or flash drive. This Zoom LiveTrak L-12 digital mixer includes 16 onboard effects to enhance your tracks and a bright LCD screen for easy customization of recorder settings.
- 12-channel digital mixer and multitrack recorder: Combines a digital mixer with 12 total input channels (8 mono and 2 stereo), multitrack recorder that can simultaneously record up to 14 tracks, and 14-in/4-out USB audio interface.
- High-quality microphone preamplifiers: Eight high-quality analog inputs can provide +48V phantom power, have a -128dBu EIN rating, and +60dB maximum input gain. In addition, channels 1 and 2 also support Hi-Z input, while channels 3 to 8 have PAD functions (26dB attenuation).
- Five monitor out channels: In addition to the master out, LiveTrak L-12 offers five monitor out channels. The monitor out mixes can be set separately for each output. Since they support a headphone output, headphones are everything that is needed to send different mixes to each performer.
- Intuitive controls: Control every mixer parameter with its knobs and keys. Each channel has a three-band EQ, and the mono channels have compressor functions. The mixer also includes high-quality send effects. In addition, up to nine mixer status scenes can be saved in the unit.
- Records 14 tracks and plays 12 tracks simultaneously: Record every channel and the master fader stereo signal output for a total of 14 tracks. Since the recorded data is saved in a 16-/24-bit, 44.1/48/96kHz WAV format, the files can easily be copied to a computer and used in a DAW.
- 14-in/4-out USB audio interface: The signals from each input and the master fader output can be recorded in a DAW. In addition, signals output from a computer can also be assigned to a stereo channel.
- Compact and lightweight design: This digital mixer is easy to transport and can even be used with PA systems for live performances in rehearsal studios, cafés and other small venues.
Whats Included
- Zoom LiveTrak L-12 Digital Mixer/Recorder
- USB 2.0 cable
- AC adapter
- Owner's manual
Product Manuals
Q: Can this mixer be used with a Mevo Livestream Camrecorder?
A: undefined
