Specifications
- Color FinishStainless steelProduct Height11 9/16 inchesProduct Width35 15/16 inchesProduct Depth11 inchesExhaust Vent LocationBackVent TypeDucted, Ductless
- Key Specs
- Color Finish: Stainless steel
- Product Height: 11 9/16 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 35 15/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 11 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Back
- Vent Type: Ducted, Ductless
- Vent Style: External, Recirculating (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Bosch
- Model Number: HUI56551UC
- Product Name: 500 Series 36" Convertible Range Hood
- Color: Stainless steel
- Color Finish: Stainless steel
- Vendor Collection: Bosch 500 Series (Part of a line of different product types, like kitchen appliances.)
- Dimensions
- Product Height: 11 9/16 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 30 inches
- Product Width: 35 15/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 11 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 36 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 32.4 pounds (The out of box weight of the item.)
- Duct Shape: Round
- Round Duct Diameter: 6 inches
- Cut-Out Dimensions
- Cut-Out Width: 25 1/2 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Depth: 10 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Features
- Exhaust Vent Location: Back
- Vent Type: Ducted, Ductless
- Vent Style: External, Recirculating (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Insert
- Wireless Connectivity: None (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Number of Fan Speeds: 3
- Temperature Sensor: false (Integrated sensor adjusts ventilation power as needed to accommodate high temperatures.)
- Control Type: Slide
- Display Type: None
- Delay Shut-Off: false (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: false
- Remote Control: false
- Damper Included: true
- Integrated Light(s): true
- Number of Lights: 2
- Number of Light Levels: 1
- Bulb Type Required: Halogen
- Bulb(s) Included: true
- Maximum Bulb Wattage: 40 watts
- Performance
- Maximum Air Flow Capacity: 500 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Minimum Air Flow Capacity: 300 cubic feet per minute (Minimum amount of air that the appliance will ventilate at its lowest setting.)
- Filter Info
- Filter Material: Aluminum
- Dishwasher-Safe Filter: true
- Removable Grease Filter: true
- Electrical Specification
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): cULus (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: 1 year
- Other
- UPC: 825225920533
Install this Bosch Benchmark pull-out hood over your range to keep down smoke and odors even on fish-fry nights. This stainless steel hood features two halogen lights for brightening up your cooking space. An LED display and a convenient timer on this Bosch Benchmark pull-out hood lets you take total control in the kitchen.
- 500 cfm exhaust capacity: Quickly pull smoke and cooking odors out of the air.
- 3 fan-speed settings: Allow you to adjust ventilation to meet your needs.
- Dual halogen lights: Illuminate the cooktop below with bright or subtle lighting for better visibility while cooking.
- Stainless steel finish: Offers a sleek, stylish look.
- Designed to fit standard 6" round ductwork: For ease of installation.
Whats Included
- Bosch 500 Series 36" Convertible Range Hood
- Owner's manual
Product Manuals
Q: Does this range hood come with a light?
A: Yes, the range hood features dual halogen lights to illuminate your cooking area.
Q: What type of ductwork is this range hood designed to fit?
A: This range hood is designed to fit standard 6-inch round ductwork.
Q: Is the grease filter on this range hood removable?
A: Yes, it has a removable grease filter that is dishwasher safe for easy cleaning.
Q: What is the minimum airflow capacity of this range hood?
A: The minimum airflow capacity for this range hood is 300 cubic feet per minute.
Q: What is the finish of this range hood?
A: This range hood has a sleek and stylish stainless steel finish.
Q: How many fan speeds does the Bosch range hood have?
A: This Bosch range hood offers 3 fan speed settings for different ventilation needs.
Q: What is the maximum air flow capacity of this range hood?
A: This range hood has a maximum airflow capacity of 500 cubic feet per minute.
Q: will the lights and vents work without the hood pulled out?
A: Hi Dale, thanks for your question and interest in model # HUI56551UC. This sleek, 36" integrated pull-out hood allows you to close the hood when not in use, Therefore, the ventilation and lighting are switched off when the drawer is closed.
