ASUS - PRIME NVIDIA GeForce RTX 5070 Ti OC Edition 16GB GDDR7 PCI Express 5.0 Graphics Card - Black
CORSAIR - XTM60 High Performance Thermal Paste - Gray$9.99$14.99
More Buying Options
Related Item
Specifications
- GPU Base Clock Frequency2.497 gigahertzGPU Boost Clock Frequency2.527 gigahertzDisplayPort Ports3 x DisplayPort 2.1HDMI Ports1 x HDMI 2.1Maximum Resolution8K (4320p)Maximum Number of Displays Supported4
- Key Specs
- GPU Base Clock Frequency: 2.497 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.527 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 1 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- GPU Video Memory (RAM): 16 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- Slot Size: 2.5-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 5.0
- Product Height: 50 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 126 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 306 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5070 Ti (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- General
- Brand: ASUS
- Model Number: PRIME-RTX5070TI-O16G
- Product Name: PRIME NVIDIA GeForce RTX 5070 Ti OC Edition 16GB GDDR7 PCI Express 5.0 Graphics Card
- Color: Black
- GPU Chipset Manufacturer: NVIDIA
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5070 Ti (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- Year of Release: 2025
- Performance
- GPU Base Clock Frequency: 2.497 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.527 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- Cooling System: Fan (A computer's CPU generates heat while operating and requires a cooling system to keep internal components functioning properly. Air cooling uses fans to draw in cool air and exhaust hot air, while liquid cooling uses coolant-filled tubes and water blocks to regulate internal temperature more efficiently.)
- Connectivity
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 1 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Display
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- Memory
- GPU Video Memory (RAM): 16 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- GPU Video Memory Base Clock Frequency (RAM): 14 gigahertz
- Compatibility
- Slot Size: 2.5-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- System Requirements: Windows 11 / Windows 10 (The software that a product must have for it to be able to integrate with another product.)
- PCI Express Version: PCI Express 5.0
- Operating System Compatibility: Windows
- Power
- Total Graphics Power: 300 watts
- Recommended Power Supply: 750 watts
- Dimensions
- Product Height: 50 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 126 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 306 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 2.58 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 3 years
- Other
- UPC: 197105878044
The ASUS Prime RTX 5070 Ti features a 2.5 slot design with a carefully arranged layout for the shroud, heatsink and heat pipes to let the three Axial-tech fans leverage chassis side-panel ventilation and deliver optimal thermal performance. A premium phase-change GPU thermal pad provides superior thermal conductivity and enhanced heat dissipation, ensuring optimal performance and longevity for graphics cards under heavy loads.
- Powered by: NVIDIA Blackwell architecture and DLSS 4
- SFF-Ready enthusiast GeForce card: Compatible with small-form-factor builds
- Axial-tech fans: Feature a smaller fan hub that facilitates longer blades and a barrier ring that increases downward air pressure
- Phase-change GPU thermal pad: Helps ensure optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability
- 2.5-slot design: Allows for greater build compatibility while maintaining cooling performance
- Dual-ball fan bearings: Last up to twice as long as standard sleeve bearings
- 0dB technology: Lets you enjoy light gaming in relative silence
- Dual BIOS switch: Lets you toggle between Quiet and Performance BIOS profiles
- Auto-Extreme: Manufacturing process for precision and reliability
- GPU Tweak III: Software provides intuitive performance tweaking, advanced thermal control and system monitoring
Whats Included
- Speedsetup Manual
- ASUS Velcro Hook & Loop
- Thank you Card
- Adapter Cable
Q: What type of cooling system does this graphics card use?
A: This graphics card uses a fan cooling system.
Q: What is the recommended power supply for this graphics card?
A: The recommended power supply for this graphics card is 750 watts.
Q: Does this graphics card come with a BIOS switch?
A: Yes, it has a Dual BIOS switch that lets you toggle between Quiet and Performance BIOS profiles.
Q: What is the slot size of this graphics card?
A: The ASUS GeForce RTX 5070 Ti graphics card has a 2.5 slot design.
Q: How many displays does this graphics card support?
A: The ASUS GeForce RTX 5070 Ti graphics card can support a maximum of 4 displays.
Q: What version of PCI Express does this graphics card use?
A: This graphics card uses PCI Express 5.0.
Q: Are these shipped unopened new or from a return center?
A: The ASUS PRIME-RTX5070TI-O16G GPU sold by Best Buy is a brand-new, unopened unit.
Q: What is the noise level on this card? Is it pretty quiet under load?
A: The ASUS PRIME-RTX5070TI-O16G Graphics Card is designed with a triple-fan cooling system that balances performance and acoustics. It features 0dB technology, meaning the fans remain silent during light tasks or idle periods. Under load, the noise level depends on the intensity of the workload, but the card is engineered to maintain relatively quiet operation while ensuring optimal cooling. https://www.asus.com/motherboards-components/graphics-cards/prime/prime-rtx5070ti-o16g/
Compare similar products
The ASUS Prime RTX 5070 Ti features a 2.5 slot design with a carefully arranged layout for the shroud, heatsink and heat pipes to let the three Axial-tech fans leverage chassis side-panel ventilation and deliver optimal thermal performance. A premium phase-change GPU thermal pad provides superior thermal conductivity and enhanced heat dissipation, ensuring optimal performance and longevity for graphics cards under heavy loads.
NVIDIA Blackwell architecture is elevated by enhanced cooling and power delivery, fortified with rugged reinforcements for exceptional durability. Lock, load, and dominate with the ASUS TUF Gaming GeForce RTX™ 5070 OC, designed to withstand the harshest conditions, and deliver unparalleled performance.
NVIDIA Blackwell architecture is elevated by enhanced cooling and power delivery, fortified with rugged reinforcements for exceptional durability. Lock, load, and dominate with the ASUS TUF Gaming GeForce RTX 5070 Ti, designed to withstand the harshest conditions, and deliver unparalleled performance.
The ASUS Prime RTX 5070 Ti features a 2.5 slot design with a carefully arranged layout for the shroud, heatsink and heat pipes to let the three Axial-tech fans leverage chassis side-panel ventilation and deliver optimal thermal performance. A premium phase-change GPU thermal pad provides superior thermal conductivity and enhanced heat dissipation, ensuring optimal performance and longevity for graphics cards under heavy loads.
| Pros for ASUS - PRIME NVIDIA GeForce RTX 5070 Ti OC Edition 16GB GDDR7 PCI Express 5.0 Graphics Card - Black | |||
|---|---|---|---|
| Performance, Noise Level, Size, Cooling System | Performance, Build Quality, Noise Level, Temperature, Aesthetics | Performance, Temperature, Build Quality, Noise Level, Visuals | Noise Level, Size, Build Quality, Graphics Performance, Heat Dissipation |
| Cons for ASUS - PRIME NVIDIA GeForce RTX 5070 Ti OC Edition 16GB GDDR7 PCI Express 5.0 Graphics Card - Black | |||
| There were no cons for this product— | Size | There were no cons for this product— | There were no cons for this product— |
Specs
Reviews
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 4 out of 5 stars
Good card, expensive at current price
I have this paired with a 9800x3d and it’s a beast, I've been using quiet mode since i bought it, and have been thoroughly impressed. I mostly play indie horror games, but while playing Street Fighter6 and Tekken 8 I'm getting 4k 60fps with no dropped frames. I did notice while doing some light editing in premier pro, and sony vegas that the rendering does take longer than i thought…this could be based off the 9800x3d but i will do some more testing later.
Posted by Maurice
- Rated 5 out of 5 stars
Best value for money RTX 50 series card
This card can run any modern game in 1440p at max settings with ray-tracing enabled. Moreover, combined with DLSS and Multi-frame generation, you can get a ridiculous amount of fps, taking full advantage of high refresh rate monitors (165hz, 240hz etc.). Currently I am playing Cyberpunk 2077 with path tracing enabled at around 160-200fps. Overall, this is probably the best cost-benefit card from NVIDIA right now and is a future proof purchase for AAA titles (I can't wait to test Doom the Dark Ages with this beast).
Posted by Armando
- Rated 5 out of 5 stars
Packs a punch
This GPU was an upgrade from my 3070. It has doubled the vram so there's a noticeable difference in performance. I also like that there's no RGB because it fits my all blackout setup. I am having issues where my computer doesn't go to sleep anymore which is a problem with an OLED monitor. I'm not sure if this is a common issue with 50 series gpus but hopefully it gets fixed.
Posted by Drew4723
