ASUS - ROG Strix NVIDIA GeForce RTX 5070 Ti OC Edition 16GB GDDR7 PCI Express 5.0 Graphics Card - Black
More Buying Options
Related Item
Specifications
- GPU Base Clock Frequency2.602 gigahertzGPU Boost Clock Frequency2.625 gigahertzDisplayPort Ports3 x DisplayPort 2.1HDMI Ports2 x HDMI 2.1Maximum Resolution8K (4320p)Maximum Number of Displays Supported4
- Key Specs
- GPU Base Clock Frequency: 2.602 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.625 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 2 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- GPU Video Memory (RAM): 16 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- Slot Size: 3.25-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 5.0
- Product Height: 64 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 147.3 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 332 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5070 Ti (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- General
- Brand: ASUS
- Model Number: ROG-STRIX-RTX5070TI-O16G-GAMIN
- Product Name: ROG Strix NVIDIA GeForce RTX 5070 Ti OC Edition 16GB GDDR7 PCI Express 5.0 Graphics Card
- Color: Black
- GPU Chipset Manufacturer: NVIDIA
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5070 Ti (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- Year of Release: 2025
- Performance
- GPU Base Clock Frequency: 2.602 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.625 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- Cooling System: Fan (A computer's CPU generates heat while operating and requires a cooling system to keep internal components functioning properly. Air cooling uses fans to draw in cool air and exhaust hot air, while liquid cooling uses coolant-filled tubes and water blocks to regulate internal temperature more efficiently.)
- Connectivity
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 2 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Power Connector: 1 x 12-pin (The configuration of the connector as it connects the motherboard to a power supply unit.)
- Display
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- Memory
- GPU Video Memory (RAM): 16 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- GPU Video Memory Base Clock Frequency (RAM): 14 gigahertz
- Compatibility
- Slot Size: 3.25-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 5.0
- Operating System Compatibility: Windows
- Power
- Total Graphics Power: 300 watts
- Recommended Power Supply: 850 watts
- Dimensions
- Product Height: 64 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 147.3 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 332 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 3.51 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 3 years
- Other
- UPC: 197105955080
The premium performance ASUS ROG Strix GeForce RTX 5070 Ti, featuring advanced cooling system with axial-tech fan, vapor chamber, phase-change GPU thermal pad, and MaxContact design, lowering GPU temperature to reach higher performance. Aura sync provides endless possibilities for personalization with color or functional effects.
- AI Performance: 1492 AI TOPS.
- OC Edition: 2625 MHz OC mode, 2602 MHz default mode.
- 3.2-Slot Design: Massive fin array optimized for airflow from the three Axial-tech fans.
- Axial-Tech Fans: Have been scaled up to propel more air through the card to reach higher performance.
- 0dB Technology: Lets you enjoy light gaming in relative silence.
- MaxContact Design With Vapor Chamber: Ensures efficient heat transfer, providing a premium performance.
- Phase-Change GPU Thermal Pad: Helps ensure optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability.
- Premium Power Delivery: With digital power control and 15K caps ensure high performance.
- Protective PCB Coating: Envelops the circuit board to help protect against short-circuits caused by moisture, dust, or debris.
- Aura Sync: Features Aura-compatible ARGB lighting on the shroud and perimeter allows endless personalization.
- GPU Tweak III: Software provides intuitive performance tweaking, advanced thermal control, and system monitoring.
- AI Performance: 1492 AI TOPS.
- OC Edition: 2625 MHz OC mode, 2602 MHz default mode.
- 3.2-Slot Design: Massive fin array optimized for airflow from the three Axial-tech fans.
- Axial-Tech Fans: Have been scaled up to propel more air through the card to reach higher performance.
- 0dB Technology: Lets you enjoy light gaming in relative silence.
- MaxContact Design With Vapor Chamber: Ensures efficient heat transfer, providing a premium performance.
- Phase-Change GPU Thermal Pad: Helps ensure optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability.
- Premium Power Delivery: With digital power control and 15K caps ensure high performance.
- Protective PCB Coating: Envelops the circuit board to help protect against short-circuits caused by moisture, dust, or debris.
- Aura Sync: Features Aura-compatible ARGB lighting on the shroud and perimeter allows endless personalization.
- GPU Tweak III: Software provides intuitive performance tweaking, advanced thermal control, and system monitoring.
Q: Does this graphics card have any lighting effects?
A: Yes, this graphics card features Aura Sync for personalization with ARGB lighting.
Q: What is the recommended power supply for this graphics card?
A: The recommended power supply for this graphics card is 850 watts.
Q: Does this graphics card have a coating for protection?
A: Yes, this graphics card has a protective PCB coating to help against short-circuits.
Q: How many displays can this graphics card support?
A: This graphics card can support a maximum of four displays.
Q: What type of memory is used in this graphics card?
A: This graphics card uses GDDR7 type memory.
Q: What is the boost clock frequency of this graphics card?
A: The boost clock frequency of this graphics card is 2.625 gigahertz.
Q: Are there HDMI ports on this graphics card?
A: Yes, this graphics card has two HDMI 2.1 ports.
Q: Which power supply should be paired with this?
A: Any 850w atx 3.1 will do fine with this card
