PRODUCT OVERVIEW Using proprietary software technology and a powerful digital sound processor, we pushed the envelope of what’s possible in a sound system, redefining how you experience your music on the road. PRODUCT FEATURES H.E.D.G.E. Surround – The symmetrical shape, coupled with the High Excursion Design Gathered Edge, allows the speaker to operate more symmetrically and linearly for increased output and extended low frequency. Unique Design – The unique lapeled cone shape allows us to achieve high cone excursion for more motion and height when compared to a traditional speaker. OPTIM Sync Technology – Using a proprietary dynamic bass boost algorithm, we can extend the bass frequency on each speaker while staying within the safe operating limits. Each speaker features a pre-EQ to enhance the tonal balance during playback. OVERVIEW FEATURES • High Excursion Design Gathered Edge (H.E.D.G.E.) rubber surround increases output and low frequency extension • Unique lapel cone shape for high excursion • OPTIM Sync Technology pre - EQ selection specific to each driver (requires 3.0 or newer update on PXE -C80-88) • Polypropylene and Mica Cone Material for increased rigidity • Ferrite magnet • Gun metal chemical topcoat for premium aesthetic SYSTEM TECH SPECS • Woofer Size: 8” • Tweeter Size: 1” (Coaxial) • Maximum Peak Power: 150W • Maximum RMS Power: 50W • Frequency Response: Without BassRev 55 Hz – 20k Hz, With BassRev 35 Hz – 20k Hz • Impedance: 4 Ω • Sensitivity: 87 • 30% SPL increase for increased loudness • 25% X - Max increase for increased cone • Mounting Depth : 7.4mm (2 15/16”) SYSTEM COMPONENTS • 8” Component Speaker Set • 0.75” Tweeter Set

Enhance your in-vehicle sound with this pair of KICKER CS-Series three-way speakers. Polypropylene woofer cones with ribbed UV-treated surrounds and Extended Voice Coil technology provide deep, rich bass while ensuring efficient performance. The mid-range drivers and PEI balanced dome tweeters of these KICKER CS-Series three-way speakers produce clear, dynamic higher-frequency audio details. Geek Squad Installation Recommended Visit your local Best Buy store for more information.

The TS-WX1010A is a powerful sealed pre-loaded subwoofer enclosure. Featuring a built-in high bandwidth, high output and low distortion 1100 W Max Class D amplifier mated to a 10" subwoofer with a urethane surround and oversized magnet structure specifically optimized for use sealed enclosures. User adjustable controls include an LPF, phase control, variable bass boost level (0 to +12 dB), and bass boost frequency adjuster (40Hz to 100Hz) to provide enhanced subwoofer control. To expand system flexibility and user control, input gain can be adjusted using the included wired remote bass control knob or via the input gain control mounted on the enclosure side panel. The TS-WX1010A can be installed with the subwoofer firing rear or front for optimal bass tuning.
