Cerwin Vega - Cerwin Vega- XED4004D XED Series 4-Channel Full Range Class-D Amplifier - Black
Cerwin Vega - Cerwin Vega- XED4004D XED Series 4-Channel Full Range Class-D Amplifier - Black
Specifications
- Amplifier ClassDNumber Of Channels4Bass BoostVariable
- Key Specs
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Number Of Channels: 4
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- General
- Brand: Cerwin Vega
- Model Number: XED4004D
- Product Name: Cerwin Vega- XED4004D XED Series 4-Channel Full Range Class-D Amplifier
- Color: Black
- Audio Power
- Total Power Handling RMS: 400 watts
- Total Power Handling Maximum: 800 watts
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Audio
- Number Of Channels: 4
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Features
- Bluetooth Enabled: false (The device is capable of communicating with another device via Bluetooth, provided they are within the required range of each other. A Bluetooth-enabled device must also be the same Bluetooth version or higher than the accessory it is intended to pair with.)
- Marine: false
- Dimensions
- Product Height: 1.8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 4.7 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 6.3 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 0.01 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: 1 year
- Other
- UPC: 847169054013
The Cerwin-Vega XED Series Amplifiers are your ticket to high-performance car audio with power, precision, and reliability. Designed with Xtreme Energy Design, these amplifiers are engineered to take your sound system to the next level, delivering exceptional power and efficiency for every beat.The XED Series Amplifiers are built for those who crave deep bass, crisp highs, and seamless mids. With their cutting-edge technology and meticulous craftsmanship, they deliver the power and clarity needed to make every drive an immersive audio experience.Unleash the full potential of your car audio system with Cerwin-Vega XED Series Amplifiers—where Xtreme Energy meets extreme performance.
- Precision Engineering for Superior Performance: Class D Amplifier Technology: High-efficiency design ensures massive power output with minimal heat generation. Lightweight Aluminum Chassis: Enhances heat dissipation while reducing weight for efficient, long-lasting performance.
- Durability Meets Power: Robust Construction: Crafted with premium components for consistent, reliable operation. Built for Demanding Setups: Ideal for high-power audio systems, effortlessly driving subwoofers and speakers with clean, distortion-free sound. Performance that Thrills
- Power Rating (RMS): 90W x 4 @ 2Ω 60W x 4 @ 4Ω Power Supply Power Supply: Full WPM Power Supply Threshold: 10.0V-16.0V (DC) Idle Current: (0.7A) Distortion THD 4 (1KHZ @4Ω): 0.1% S/N RATIO (A WEIGHTED @1W): -85dBA S/N RATIO (A WEIGHTED @FP): -101.1dBA
- Input Sensitivity: Low Level Input: 250mV-10.0V High Level Input: 1.3V~>20.0V Input Impedance Low Level Input: 10KΩ High Level Input: 100KΩ Output Stage Output Impedance: 2Ω Damping Factor (50Hz@4Ω): >70 Bandwidth (-3db): 10Hz-30KHz Crossover (1-12dB/Oct) Variable High-Pass: 35Hz-250Hz Variable low-Pass: 35Hz-250Hz
- Fuse Rating (Inside): 30A Dimensions Length x Width x Height: 6.3”x4.7”x1.8” (160mm x 120mm x 46.5 mm) FEATURES LED Power/Protect Light Indicator Selectable X-Over: High Pass/Flat/Low Pass 1-year Manufacturer's Warranty MFR #: XED4004D
- Precision Engineering for Superior Performance: Class D Amplifier Technology: High-efficiency design ensures massive power output with minimal heat generation. Lightweight Aluminum Chassis: Enhances heat dissipation while reducing weight for efficient, long-lasting performance.
- Durability Meets Power: Robust Construction: Crafted with premium components for consistent, reliable operation. Built for Demanding Setups: Ideal for high-power audio systems, effortlessly driving subwoofers and speakers with clean, distortion-free sound. Performance that Thrills
- Power Rating (RMS): 90W x 4 @ 2Ω 60W x 4 @ 4Ω Power Supply Power Supply: Full WPM Power Supply Threshold: 10.0V-16.0V (DC) Idle Current: (0.7A) Distortion THD 4 (1KHZ @4Ω): 0.1% S/N RATIO (A WEIGHTED @1W): -85dBA S/N RATIO (A WEIGHTED @FP): -101.1dBA
- Input Sensitivity: Low Level Input: 250mV-10.0V High Level Input: 1.3V~>20.0V Input Impedance Low Level Input: 10KΩ High Level Input: 100KΩ Output Stage Output Impedance: 2Ω Damping Factor (50Hz@4Ω): >70 Bandwidth (-3db): 10Hz-30KHz Crossover (1-12dB/Oct) Variable High-Pass: 35Hz-250Hz Variable low-Pass: 35Hz-250Hz
- Fuse Rating (Inside): 30A Dimensions Length x Width x Height: 6.3”x4.7”x1.8” (160mm x 120mm x 46.5 mm) FEATURES LED Power/Protect Light Indicator Selectable X-Over: High Pass/Flat/Low Pass 1-year Manufacturer's Warranty MFR #: XED4004D
- Precision Engineering for Superior Performance: Class D Amplifier Technology: High-efficiency design ensures massive power output with minimal heat generation. Lightweight Aluminum Chassis: Enhances heat dissipation while reducing weight for efficient, long-lasting performance.
- Durability Meets Power: Robust Construction: Crafted with premium components for consistent, reliable operation. Built for Demanding Setups: Ideal for high-power audio systems, effortlessly driving subwoofers and speakers with clean, distortion-free sound. Performance that Thrills
- Power Rating (RMS): 90W x 4 @ 2Ω 60W x 4 @ 4Ω Power Supply Power Supply: Full WPM Power Supply Threshold: 10.0V-16.0V (DC) Idle Current: (0.7A) Distortion THD 4 (1KHZ @4Ω): 0.1% S/N RATIO (A WEIGHTED @1W): -85dBA S/N RATIO (A WEIGHTED @FP): -101.1dBA
- Input Sensitivity: Low Level Input: 250mV-10.0V High Level Input: 1.3V~>20.0V Input Impedance Low Level Input: 10KΩ High Level Input: 100KΩ Output Stage Output Impedance: 2Ω Damping Factor (50Hz@4Ω): >70 Bandwidth (-3db): 10Hz-30KHz Crossover (1-12dB/Oct) Variable High-Pass: 35Hz-250Hz Variable low-Pass: 35Hz-250Hz
- Fuse Rating (Inside): 30A Dimensions Length x Width x Height: 6.3”x4.7”x1.8” (160mm x 120mm x 46.5 mm) FEATURES LED Power/Protect Light Indicator Selectable X-Over: High Pass/Flat/Low Pass 1-year Manufacturer's Warranty MFR #: XED4004D
Whats Included
- amp
- amp
- amp
Compare similar products
The Cerwin-Vega XED Series Amplifiers are your ticket to high-performance car audio with power, precision, and reliability. Designed with Xtreme Energy Design, these amplifiers are engineered to take your sound system to the next level, delivering exceptional power and efficiency for every beat.The XED Series Amplifiers are built for those who crave deep bass, crisp highs, and seamless mids. With their cutting-edge technology and meticulous craftsmanship, they deliver the power and clarity needed to make every drive an immersive audio experience.Unleash the full potential of your car audio system with Cerwin-Vega XED Series Amplifiers—where Xtreme Energy meets extreme performance.
Create a custom sound experience with this KICKER CX-Series mono amplifier. The variable 12dB crossovers provide the control you need to get the exact sound you want, and the 24dB subsonic filter protects against damaging frequencies. With its small footprint and Fail-safe Integration Technology-PLUS, this KICKER CX-Series mono amplifier is easy to install and works with almost any radio.
Deliver pounding beats from this Planet Audio amplifier. This class A/B amplifier can produce up to 1500 watts of power across the single channel, and the monoblock construction ensures it does so with outstanding accuracy and precision. The MOSFET power supply on this Planet Audio amplifier keeps the current low to fit in with your audio system.
| Pros for Cerwin Vega - Cerwin Vega- XED4004D XED Series 4-Channel Full Range Class-D Amplifier - Black | |||
|---|---|---|---|
| There were no pros for this product— | Power, Sound Quality, Size, Ease of use, Price | There were no pros for this product— | There were no pros for this product— |
| Cons for Cerwin Vega - Cerwin Vega- XED4004D XED Series 4-Channel Full Range Class-D Amplifier - Black | |||
| There were no cons for this product— | Heat | There were no cons for this product— | There were no cons for this product— |
