Eaton - 20 amps Combination AFCI Single Pole Circuit Breaker

Square D by Schneider Electric homeline 20 amp 1-pole plug-on neutral dual function circuit breaker is a space and labor saving device, engineered to meet prevailing national electric code requirements. This device combines two critical technologies; combination arc fault protection and ground fault protection (class a), in a single, easy-to-install device. The national electric code now requires both combination arc fault and ground fault protection on all 1-pole, 15 amp and 20 amp kitchen and laundry circuits. Prior to the release of this new device, a contractor or homeowner's only choice would have been to use a combination arc fault circuit breaker in conjunction with an expensive, bulky ground fault receptacle. The new dual function circuit breakers help reduce cost and eliminate the hassle of using two separate devices to provide this essential protection. It's a win for contractors and homeowners alike. Designed for reliability, the homeline plug-on neutral dual function circuit breaker connects directly to the neutral bar, providing a time and labor-saving installation. Several advantages from the plug-on neutral design are fewer connections which lead to faster installation and an innovative neutral clip eliminates pigtails which in turn frees gutter space. Like all square d cafi circuit breakers, it is integrated with time saver diagnostics, a unique feature that provides additional circuit information and minimizes troubleshooting at the touch of a button.Manufacturer Contact InformationSANDY, UT, 84070 US

The Square D Homeline 20 Amp Dual Function Circuit Breaker provides advanced protection by combining CAFI and GFCI (Class A) technologies into a single device, ensuring compliance with all code requirements while saving space and installation time. Designed for quick and easy setup, its pigtail neutral design connects directly to the neutral bar, allowing seamless power-up in Homeline load centers while also being compatible with plug-on neutral load centers. This single-pole breaker operates on 120/240V AC circuits and is ideal for residential branch circuits supplying wall receptacles, lighting fixtures, dishwashers, and disposals. Engineered for superior circuit protection, it effectively prevents overloads, short circuits, and dangerous arc and ground faults. Featuring a compact design that occupies just one space in the load center, it boasts a 20A current rating, 10kA breaking capacity, and UL-listed safety certification. Dimensions: 3.13" H x 1" W x 2.98" D.

These circuit breakers offer the new Self-Test and Lockout feature as required by UL 943, enabling the GFCI to automatically and continuously test itself to ensure that it is working properly. If it is detected that the device has been compromised, the device trips itself and locks out the homeowner from resetting the device, reducing the possibility of the homeowner incorrectly assuming that the device was tripped to prevent a ground fault.
