JBL - AWC526 All-Weather 15" 2400W 8 Ohm and 70V/100V High Power 2-way Speaker (Each) - Black
Related Item
Specifications
- Speaker TypeLandscapeRMS Power600 watts
- Key Specs
- Speaker Type: Landscape
- RMS Power: 600 watts (The maximum amount of continuous power the device is able to handle.)
- General
- Brand: JBL
- Model Number: AW526-BK
- Product Name: AWC526 All-Weather 15" 2400W 8 Ohm and 70V/100V High Power 2-way Speaker (Each)
- Color: Black
- Audio
- Speaker Type: Landscape
- RMS Power: 600 watts (The maximum amount of continuous power the device is able to handle.)
- Peak Power Handling: 2400 watts (The maximum amount of power an electronic device, like a speaker, can handle without damage. This refers to short bursts of power, while root mean square (RMS) power handling indicates the amount of continuous power a device can sustain. Higher levels of distortion can also occur at peak power levels when the device is powered beyond its recommended usage.)
- Impedance: 8 ohms (Describes the resistance of an electric signal throughout the system. Devices with low impedance require less power to deliver optimal signals but are more at risk for damage from overloading. Higher impedance requires more power but is more protected from overload damage.)
- Minimum Frequency Response: 55 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 17 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Sensitivity: 113 decibels
- Number of Speakers: 2
- Number of Tweeters: 1
- Tweeter Size: 1.5 inches
- Number of Woofers: 1
- Woofer Size: 15 inches
- Connectivity
- Speaker Connectivity: Wired
- Wireless Multi-Room Audio: false (Technology that allows multiple speakers and/or soundbars to be connected wirelessly and play audio in separate rooms.)
- Audio Only Inputs: No audio only inputs
- Network Connector(s): No network connectors
- Speaker Wire Connection Type: Banana Jack/Screw Terminals
- Features
- Indoor Or Outdoor Use: Indoor and outdoor (Indicates the appropriate environment product was designed to be used in.)
- Dimensions
- Product Height: 19.1 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 31.9 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 18.8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 62.5 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 2 years
- Warranty - Labor: 2 years
- Other
- UPC: 691991014277
The AW526 is a high power, lightweight, 2-way, full-range loudspeaker system comprised of the JBL Differential Drive dual voice coil and dual magnetic gap 2265H 380 mm (15 in) low-frequency driver and 2432H high-frequency 38 mm (1.5 in) exit, 75 mm (3 in) voice-coil compression driver. The large format Progressive Transition wave-guide provides excellent 120° x 60° coverage. The waveguide is rotatable so the loudspeaker system can used in either the vertical or horizontal orientation. The system can be operated as an 8-ohm device and is equipped with a 400W transformer for 70/100V applications. A corrosion-resistant extra-thick zincplated polyester powder coated U-type mounting bracket is included. The enclosure is constructed of multilayer glass composite and is heavily braced to maximize lowfrequency performance. The 16-gauge stainless steel grille, backed with open cell foam and stainless steel mesh, provides excellent protection in the harshest environments. The AW526 is part of JBL’s AE Series, a versatile family of loudspeakers intended for a wide variety of applications.
- IP56 Rating: Weather-resistant, all fiberglass enclosure.
- Sound Coverage: 120° x 60° Coverage.
- Sound: 2265H Differential Drive Low Frequency Driver & 2432H High Frequency Compression Driver.
- Sound: Large PT progressive transition waveguide for excellent pattern control and low distortion.
- multi-tap: 400 watt 70v/100v multi-tap (built-in transformer) or direct 8Ω low-impedance
- 70V/100W Transformer Taps: 70V: 400 W, 200 W, 100W 100V: 400W, 200W
- Installation: U-type Mounting Bracket Included.
- IP56 Rating: Weather-resistant, all fiberglass enclosure.
- Sound Coverage: 120° x 60° Coverage.
- Sound: 2265H Differential Drive Low Frequency Driver & 2432H High Frequency Compression Driver.
- Sound: Large PT progressive transition waveguide for excellent pattern control and low distortion.
- multi-tap: 400 watt 70v/100v multi-tap (built-in transformer) or direct 8Ω low-impedance
- 70V/100W Transformer Taps: 70V: 400 W, 200 W, 100W 100V: 400W, 200W
- Installation: U-type Mounting Bracket Included.
Whats Included
- 1 Speaker
- 1 U-Bracket
- 1 Speaker
- 1 U-Bracket
Product Manuals
Q: What is the weight of the loudspeaker?
A: The product weight of the loudspeaker is 62.5 pounds.
Q: What is the frequency response range of the loudspeaker?
A: The minimum frequency response is 55 hertz and the maximum frequency response is 17 kilohertz.
Q: Are there any other loudspeakers in the same series?
A: The AW526 is part of JBL’s AE Series, a versatile family of loudspeakers intended for a wide variety of applications.
Q: Can the loudspeaker be used in 70/100V applications?
A: The system can be operated as an 8-ohm device and is equipped with a 400W transformer for 70/100V applications.
