product image

JennAir - 30" Built-In Electric Double Wall Oven - Stainless Steel

Model: JMW2430LL
SKU: 6500265
This item is no longer available in new condition. See similar items below
  • Key Specs
    • Color Finish: Stainless steel
    • Product Height: 43 3/4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
    • Product Width: 30 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
    • Product Depth: 23 1/4 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
    • Depth Without Handle: 24 5/16 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
    • Depth With Handle: 27 1/8 inches (Measurement from the back of the product to its front (with door closed), including the handle.)
    • Oven 1 Convection: true (A fan and exhaust system that circulate air to heat the entire oven interior consistently for baking and roasting.)
    • Oven 2 Convection: true (A fan and exhaust system that circulate air to heat the entire oven interior consistently for baking and roasting.)
    • App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
  • General
    • Brand: JennAir
    • Model Number: JMW2430LL
    • Product Name: 30" Built-In Electric Double Wall Oven
    • Color: Stainless Steel
    • Color Finish: Stainless steel
  • Dimensions
    • Product Height: 43 3/4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
    • Product Width: 30 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
    • Product Depth: 23 1/4 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
    • Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
    • Depth Without Handle: 24 5/16 inches (Measurement from the back of the product to its front (with door closed), not including handle.)
    • Depth With Handle: 27 1/8 inches (Measurement from the back of the product to its front (with door closed), including the handle.)
    • Depth With Door 90 Degrees Open: 45 7/16 inches (Measurement from the back of the product to its front, with the door open at a 90-degree angle.)
    • Product Weight: 262 pounds (The out of box weight of the item.)
  • Cut-Out Dimensions
    • Cut-Out Height: 41 1/2 inches (Minimum required height of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
    • Cut-Out Width: 28 1/2 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
    • Cut-Out Depth: 24 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
  • Capacity
    • Oven 1 Capacity: 5 cubic feet
    • Oven 2 Capacity: 1.4 cubic feet
  • Features
    • Oven Type: Double wall oven
    • Oven Power Source: Electric
    • Fingerprint Resistant: false
    • Auto Shut-Off: true (Feature automatically turns off the product.)
    • Control Type: Touchscreen
    • Clock Display: true
    • Lock Type: Self-cleaning mode lock, Control panel lock, Child safety lock
    • Oven Light: true
    • Wireless Connectivity: None (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
  • Functions
    • Sabbath Mode: true (This mode complies with the rules of Halakha and allows Shabbat-observant people to use the appliance on the Shabbat and other Jewish holidays.)
    • Hidden Bake Element: true (This feature provides more space within the cooking cavity and allows for cleaning without navigating around an exposed heating element.)
    • Keep Warm Setting: true
    • Timer: true
    • Time Bake: true (Allows you to program the appliance to run at a pre-determined time and automatically turn off when baking time is finished. Plan for mealtime or entertaining by setting your oven to start baking at a convenient time and reduce the worry of overcooking your food with the automatic shut off feature.)
    • Rapid Preheat: true
  • Oven 1 Specification
    • Oven 1 Location: Lower
    • Oven 1 Convection: true (A fan and exhaust system that circulate air to heat the entire oven interior consistently for baking and roasting.)
    • Oven 1 Convection Type: Convection (Convection adds a fan system to the two heating elements for continuous air motion and efficient cooking. True convection adds a third heating element to the fan system, for even more uniform heating.)
    • Oven 1 Window: true
    • Oven 1 Cleaning Method: Self-High Heat Cleaning (There are several ways to clean the inside of your oven. Depending on the model, it might require manual cleaning or have a self-clean function. Self-clean functions use either high heat or steam to break down grease and food debris within the cooking cavity.)
    • Number of Oven 1 Rack Positions: 3
    • Number of Oven 1 Racks: 6
  • Oven 2 Specification
    • Oven 2 Location: Upper
    • Oven 2 Convection: true (A fan and exhaust system that circulate air to heat the entire oven interior consistently for baking and roasting.)
    • Oven 2 Window: true
    • Oven 2 Cleaning Method: Manual, Manual (There are several ways to clean the inside of your oven. Depending on the model, it might require manual cleaning or have a self-clean function. Self-clean functions use either high heat or steam to break down grease and food debris within the cooking cavity.)
  • Electrical Specification
    • Amperage: 40 amperes (Strength of electrical current.)
  • Certifications Listings & Approvals
    • Chemical Disclosures: This product may contain one or more regulated perfluoroalkyl and polyfluoroalkyl substances or PFAS. Mandatory reporting is not required until January 1, 2025.  Whirlpool Corporation is in the process of gathering more information on PFAS use across our supplier base, and will update this disclosure as we learn more. For more information about chemicals in this product, visit www.jennair.com/regulatory.html. [Este producto puede contener una o más sustancias perfluoroalquilo y polifluoroalquilo reguladas o PFAS. No se requieren informes obligatorios hasta el 1 de enero de 2025. Whirlpool Corporation está en el proceso de recopilar más información sobre el uso de PFAS en nuestra base de proveedores y actualizará esta divulgación a medida que sepamos más. Para obtener más información sobre los químicos en este producto, visite www.jennair.com/regulatory.html.] (The disclosure of Per- and Polyfluorinated Substances (PFAS) and/or other chemicals.)
  • Warranty
    • Warranty - Parts: 1 year limited
    • Warranty - Labor: 1 year limited
  • Compatibility
    • App Compatible: false (The product can be connected to a program or software application on a mobile device, which then receives collected data from the product.)
  • Other
    • UPC: 883049610283

Let your appetite run wild with microwave and convection energy. With curated recipes and full-color doneness images, an intelligent culinary experience awaits your touch.

  • Irresistible Interior: Captivation cloaked in black. Beyond a dark glass expanse, cinematic lighting illuminates smooth racks, flat tines, and an enticing jet black interior.
  • 4.3-Inch Full Color LCD Display: A highly interactive, full-color LCD touchscreen is packed with dynamic features that allow you to navigate effortlessly through settings and cooking options including temperature and cooking mode.
  • Cinematic Lighting: Lights, camera, cook. Halogen lighting increases to full intensity, minimizing shadows and dramatically showcasing food.
  • Seamless Touches: Seamlessly designed. Concealed details melt into their stainless steel surround, as dark interiors and glass expanses pull you in.
  • Stainless Steel Microwave Interior: Wrapped in luminous steel, intrinsic beauty is reflected in every corner.
  • Glide Rack: Smooth moves. Glides in and out fluidly and quietly, even when fully loaded.
  • 5.0 Cu. Ft. Capacity: Big on entertaining. Generous capacity to cook multiple dishes at once.
  • 5.0 Cu. Ft. Oven Capacity: Big on entertaining. Generous capacity to cook multiple dishes at once.
  • 1.4 Cu. Ft. Microwave Capacity: Explore your options. There’s room for whatever you’re craving.
  • MultiMode Convection System: Steady heat is circulated by whirling metal blades, weaving around every flat tine. Wield your cooking prowess from marbled meats to succulent roasts.
  • Closed Door Broiling: Turn up the heat behind closed doors. Caramelized crust. Delicate char. Tender center. High, even heat with outstanding ventilation means you can sear fearlessly. And without opening the door.
  • Versatile Cooking Modes: Uncompromising results, untroubled process. Automatically convection cook by food type, or manually select convection modes by cooking method. Take the guesswork out of convection cooking with automatic temperature and time conversions.
  • Temperature Probe: Know when dinner is done without ever opening the door. 4 points of contact deliver temperature readings visible on the LCD screen.
  • Convection & Microwave Combination Cooking: Let your appetite run wild—broil, bake or warm with convection and microwave energy.
  • 3,200-Watt Convection Element: Power, controlled. Evenly bake breads and cook main dishes in a controlled environment powered by this 3,200-watt convection element.
  • 2,800-Watt Hidden Bake Element: Unleash hidden power. This 2,800-watt bake element is concealed beneath the oven floor, providing even heat and a smooth surface that is easy to clean.
  • 4,000-Watt Broil Element: Tap into high-watt, even heat designed to broil meats with this 4,000-watt element for savory, caramelized crust.
  • 8-Pass Reflective Broil Element: Maximum coverage. Even heat distribution. Beneath a stainless steel broil plate, this element radiates heat back onto cookware and food.
  • 1,200-Watt Convection Element: This 1,200-watt element surrounds your cravings with circulating, consistent heat until baked to your satisfaction.
  • 900-Watt Microwave Element: Harness 900 watts of microwave energy to rapidly cook and reheat a variety of foods.
  • Speed-Cook: Renounce accepted limitations of the microwave. Three potent methods converge to deliver convection's steady heat, microwave speed and broiled caramelization in each oven-caliber bite.
  • Sensor Cooking: An intuitive sensor responds to humidity levels, altering time and power for results that aim to please.
  • Soften/Melt Cycle: Ribbons of molten chocolate. Butter that yields to your knife. Melt and soften with delicate heat that ignites passionate appetites.
  • Keep Warm Option: Reward anticipation. Low heat keeps tempting dishes ready and waiting for the right moment.
  • Auto Convection Conversion: Bake with abandon. The oven automatically converts temperature and cook time to make any recipe a convection recipe.
  • Irresistible Interior: Captivation cloaked in black. Beyond a dark glass expanse, cinematic lighting illuminates smooth racks, flat tines, and an enticing jet black interior.
  • 4.3-Inch Full Color LCD Display: A highly interactive, full-color LCD touchscreen is packed with dynamic features that allow you to navigate effortlessly through settings and cooking options including temperature and cooking mode.
  • Cinematic Lighting: Lights, camera, cook. Halogen lighting increases to full intensity, minimizing shadows and dramatically showcasing food.
  • Seamless Touches: Seamlessly designed. Concealed details melt into their stainless steel surround, as dark interiors and glass expanses pull you in.
  • Stainless Steel Microwave Interior: Wrapped in luminous steel, intrinsic beauty is reflected in every corner.
  • Glide Rack: Smooth moves. Glides in and out fluidly and quietly, even when fully loaded.
  • 5.0 Cu. Ft. Capacity: Big on entertaining. Generous capacity to cook multiple dishes at once.
  • 5.0 Cu. Ft. Oven Capacity: Big on entertaining. Generous capacity to cook multiple dishes at once.
  • 1.4 Cu. Ft. Microwave Capacity: Explore your options. There’s room for whatever you’re craving.
  • MultiMode Convection System: Steady heat is circulated by whirling metal blades, weaving around every flat tine. Wield your cooking prowess from marbled meats to succulent roasts.
  • Closed Door Broiling: Turn up the heat behind closed doors. Caramelized crust. Delicate char. Tender center. High, even heat with outstanding ventilation means you can sear fearlessly. And without opening the door.
  • Versatile Cooking Modes: Uncompromising results, untroubled process. Automatically convection cook by food type, or manually select convection modes by cooking method. Take the guesswork out of convection cooking with automatic temperature and time conversions.
  • Temperature Probe: Know when dinner is done without ever opening the door. 4 points of contact deliver temperature readings visible on the LCD screen.
  • Convection & Microwave Combination Cooking: Let your appetite run wild—broil, bake or warm with convection and microwave energy.
  • 3,200-Watt Convection Element: Power, controlled. Evenly bake breads and cook main dishes in a controlled environment powered by this 3,200-watt convection element.
  • 2,800-Watt Hidden Bake Element: Unleash hidden power. This 2,800-watt bake element is concealed beneath the oven floor, providing even heat and a smooth surface that is easy to clean.
  • 4,000-Watt Broil Element: Tap into high-watt, even heat designed to broil meats with this 4,000-watt element for savory, caramelized crust.
  • 8-Pass Reflective Broil Element: Maximum coverage. Even heat distribution. Beneath a stainless steel broil plate, this element radiates heat back onto cookware and food.
  • 1,200-Watt Convection Element: This 1,200-watt element surrounds your cravings with circulating, consistent heat until baked to your satisfaction.
  • 900-Watt Microwave Element: Harness 900 watts of microwave energy to rapidly cook and reheat a variety of foods.
  • Speed-Cook: Renounce accepted limitations of the microwave. Three potent methods converge to deliver convection's steady heat, microwave speed and broiled caramelization in each oven-caliber bite.
  • Sensor Cooking: An intuitive sensor responds to humidity levels, altering time and power for results that aim to please.
  • Soften/Melt Cycle: Ribbons of molten chocolate. Butter that yields to your knife. Melt and soften with delicate heat that ignites passionate appetites.
  • Keep Warm Option: Reward anticipation. Low heat keeps tempting dishes ready and waiting for the right moment.
  • Auto Convection Conversion: Bake with abandon. The oven automatically converts temperature and cook time to make any recipe a convection recipe.

Q: What cooking modes are available, and how do they ensure uncompromising results?

A: The JennAir 30" Built-In Electric Double Wall Oven offers various cooking modes to ensure uncompromising results. Automatic convection modes adjust temperature and airflow for baking, broiling, or roasting based on the selected food type. Manual convection modes allow users to choose specific presets like Convect Bake, Convect Roast, and Convect Broil. Additionally, the oven features a Rapid Preheat function to reduce preheat time and a Proofing Option for consistent dough rising.

Q: What is the power output of the hidden bake element, and how does it contribute to even heat distribution?

A: The hidden bake element in this JennAir 30" Built-In Electric Double Wall Oven has a power output of 2,800 watts. It is concealed beneath the oven floor, providing even heat distribution and creating a smooth surface that is easy to clean. This design ensures consistent baking and cooking results.

Q: What is the size and type of the display screen, and how does it facilitate navigation and control?

A: The display screen is a 4.3-inch full-color LCD touchscreen. It allows users to navigate effortlessly through settings and cooking options, including temperature and cooking mode, with its highly interactive and dynamic features. The temperature readings from the temperature probe are also visible on this LCD screen.

Q: Can you elaborate on the Convection & Microwave Combination Cooking feature and its versatility?

A: The Convection & Microwave Combination Cooking feature in the JennAir 30" Built-In Electric Double Wall Oven allows users to broil, bake, or warm food using both convection and microwave energy. This versatile feature provides even heat distribution and faster cooking times, making it ideal for a variety of dishes. Users can choose to cook by food type or manually select convection modes based on the cooking method.

Q: What is the wattage of the convection element, and how does it contribute to efficient baking and cooking?

A: The convection element in this JennAir 30" Built-In Electric Double Wall Oven has a wattage of 1,200. It contributes to efficient baking and cooking by surrounding food with circulating, consistent heat, ensuring even cooking and baking results.

Q: What is the purpose of the Seamless Touches design, and how does it enhance the overall appearance?

A: The Seamless Touches design in the JennAir 30" Built-In Electric Double Wall Oven is characterized by concealed details that seamlessly blend into the stainless steel surround. This design element enhances the overall appearance by creating a sleek and sophisticated look, with dark interiors and expansive glass panels that draw attention to the oven's interior.

Q: What material is used for the microwave interior, and how does it enhance the overall aesthetic?

A: The microwave interior of this JennAir 30" Built-In Electric Double Wall Oven is made of stainless steel. This material not only adds to the overall aesthetic of the oven but also reflects light, creating a visually appealing and captivating interior. The luminous steel enhances the overall appearance of the oven, making it a stylish addition to any kitchen.

Q: What is the Auto Convection Conversion feature, and how does it simplify convection cooking?

A: The Auto Convection Conversion feature in the JennAir 30" Built-In Electric Double Wall Oven simplifies convection cooking by automatically converting the temperature and cook time of any recipe to its convection equivalent. This eliminates the need for manual calculations and ensures optimal cooking results when using the convection setting.
