Name: Kensington - SD4782P-EQ USB-C & USB-A Dual 4K Docking Station with 100W Power Delivery - Black
Brand: Kensington
SKU: 6604278
Rating: 0 (0 reviews)

Key Specs
- Maximum Number of Displays Supported: 2
- Maximum Supported Resolution: 4K (2160p)
- Number of DisplayPort Outputs (Total): 2
- Passthrough Power: true (Indicates whether the device allows power to passthrough, possibly with some loss, to another device, typically to charge that other device.)
General
- Brand: Kensington
- Model Number: K33650NA
- Product Name: SD4782P-EQ USB-C & USB-A Dual 4K Docking Station with 100W Power Delivery
- Color: Black
Display
- Maximum Number of Displays Supported: 2
- Maximum Supported Resolution: 4K (2160p)
- Maximum Supported Refresh Rate: 60Hz (The number of frames per second the device can support, expressed as a frequency. Higher rates help produce smooth, seamless pictures.)
Ports
- Display Connector(s): 2 x DisplayPort 1.2, 2 x HDMI 2.0 (The number and type of connectors used to connect to an external display.)
- Number of DisplayPort Outputs (Total): 2
- Number of HDMI Ports (Total): 2
- Number of VGA Ports: 0 (VGA (Video Graphics Adapter or Video Graphics Array) is a display standard that transmits via analog signals. This type of interface is typically used to connect a computer to a display device such as a monitor, projector, or TV.)
- Number Of Ethernet Ports: 1
- Number of USB Ports (Total): 6
- USB Ports: 5 x USB-A 3.2, 1 x USB-C 3.2 (The number and type of USB ports the product has.)
- Headphone Jack: true (The device features an interface that allows for the connection of headphones.)
- Microphone Input: true (The device features an input for connecting an external microphone.)
- Memory Card Slot: false
Power
- Powered: true
- Power Supply Included: true
- Power Supply Input: DC Jack
- Maximum Input Power: 170 watts (The maximum amount of power allowed to come into the device.)
- Maximum Input Voltage: 240 volts
- Maximum Input Amperage: 1.8 amperes (The maximum amount of amperage allowed to come into the device.)
- Passthrough Power: true (Indicates whether the device allows power to passthrough, possibly with some loss, to another device, typically to charge that other device.)
- Power Supply Output: USB-C (The connector type(s) used by the device to send electrical power to another device.)
- Maximum Output Power: 100 watts (The maximum amount of power produced or allowed to flow through the device.)
Compatibility
- Brand Compatibility: Universal compatibility
- Model Compatibility: Universal compatibility
Features
- Cable Lock Slot: Kensington Security Slot (K-Slot)
- Material: PC ABS with texture, Sheetmetal
- Indicator Light(s): true
Dimensions
- Product Height: 1.23 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Length: 3.54 inches (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Width: 8.26 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Weight: 15.52 ounces (The out of box weight of the item.)
Warranty
- Warranty - Parts: 3 Year Limited Manufacturer
- Warranty - Labor: 3 Year Limited Manufacturer
Other
- UPC: 085896336501

Ideal for professionals seeking a docking solution that overcomes the complex compatibility challenges of mixed technology environments, the SD4782P EQ USB-C & USB-A Dual 4K Docking Station with 100W Power Delivery supports Thunderbolt 4, USB4, USB-C, and legacy USB-A laptops with video, data, and power. Delivering a notable video experience with support for up to 2 external Ultra HD monitors (4K @ 60Hz), and the ability to select between HDMI 2.0 and DP++ 1.2 connections (4 video ports for up to 2 external displays), the SD4782P EQ provides flexible display options and eliminates the need for cumbersome adapters. Offering up to 10Gbps data transfer speeds via 6 USB ports and up to 100W Power Delivery to the laptop and dock for both USB-C Alt Mode and legacy USB-A laptops, the SD4782P EQ tackles the productivity and power needs of most setups. The SD4782P EQ USB-C & USB-A Dual 4K Docking Station with 100W Power Delivery provides an impressive docking experience that easily meets the video, data, and power needs of today’s workstations.

Dual 4K video via HDMI 2.0 and DP++ 1.2: Four video ports allow you to select between HDMI 2.0 and DP++ 1.2 without the need for cumbersome adapters. Also supports M1/M2 MacBook with dual displays.
Universal compatibility: Supports USB-C and legacy USB-A laptops running Windows 7 or above, macOS 10.14 or above, Chrome OS 44 or above.
Up to 100W power delivery: Delivers power to laptop, docking station, and connected accessories. Supports up to 100W for USB-C Alt Mode laptops.
Multiple ports: Delivers speeds up to 10Gbps via 1 USB-C port and 5 USB-A ports. Also includes two HDMI 2.0 ports, two DP++ 1.2 ports, a Gigabit Ethernet port, and an audio combo jack.
Secure screw lock connection: Host cable is equipped with secure screw lock connector for a consistent and reliable connection between the docking station and the laptop.
Zero-footprint mounting option and security cable lock slots: Maximize desktop space by mounting your docking station out of the way. Mounting bracket sold separately (K34050WW). Protect your investment with a Kensington cable lock (K65020WW or K65021WW), sold separately.
Sustainability focused: Composed of 73% postconsumer recycled content (PCR), the plastic material used in the SD4782P EQ docking station is aimed at reducing our environmental impact.
Dual 4K video via HDMI 2.0 and DP++ 1.2: Four video ports allow you to select between HDMI 2.0 and DP++ 1.2 without the need for cumbersome adapters. Also supports M1/M2 MacBook with dual displays.
Universal compatibility: Supports USB-C and legacy USB-A laptops running Windows 7 or above, macOS 10.14 or above, Chrome OS 44 or above.
Up to 100W power delivery: Delivers power to laptop, docking station, and connected accessories. Supports up to 100W for USB-C Alt Mode laptops.
Multiple ports: Delivers speeds up to 10Gbps via 1 USB-C port and 5 USB-A ports. Also includes two HDMI 2.0 ports, two DP++ 1.2 ports, a Gigabit Ethernet port, and an audio combo jack.
Secure screw lock connection: Host cable is equipped with secure screw lock connector for a consistent and reliable connection between the docking station and the laptop.
Zero-footprint mounting option and security cable lock slots: Maximize desktop space by mounting your docking station out of the way. Mounting bracket sold separately (K34050WW). Protect your investment with a Kensington cable lock (K65020WW or K65021WW), sold separately.
Sustainability focused: Composed of 73% postconsumer recycled content (PCR), the plastic material used in the SD4782P EQ docking station is aimed at reducing our environmental impact.
