NVX - BIR200 200 AMP Battery Relay Isolator and Relay for Cars, RVs, ATVs, UTVs, and Boats.

Model: bir200
SKU: 12379634

Reviews coming soon

Sold & shipped by

About this product

Product Features: Mobile Audio Relay and Battery Isolator. Great for isolating a second batter making it dedicated to the stereo system. Does not create a voltage drop to the second battery like conventional isolators. 200 Amps at 12V Continuous Power Handling. 300 Amps Surge Power Handling. Switching Power: 10 - 16 VDC. Draws Less Than 1 Amp When On. Dimensions: 2-3/8" W x 2-3/8" D x 3-3/4" H. Authorized Internet Dealer. 1-year Manufacturer's Warranty.

Features
  • Reliable Battery Isolation

    The NVX BIR200 200 Amp Relay Isolator ensures a dedicated power source for your stereo system by effectively isolating a second battery.

  • No Voltage Drop

    Unlike conventional isolators, this relay isolator maintains full voltage to your second battery, preventing power loss and ensuring optimal performance.

  • High Power Handling

    Designed to support 200 amps continuous power at 12V and 300 amps surge power, making it ideal for high-performance car audio systems.

  • Low Power Draw

    Efficient design draws less than 1 amp when activated, minimizing strain on your vehicle's electrical system.

  • Compact & Durable

    Measuring 2-3/8"W x 2-3/8"D x 3-3/4"H, this compact isolator is easy to install and built to withstand the demands of mobile audio setups.

Specifications
  • Brand
    NVX
    Model Number
    bir200
    Product Name
    BIR200 200 AMP Battery Relay Isolator and Relay for Cars, RVs, ATVs, UTVs, and Boats.
    Product Compatibility
    Audio/Video
    Product Type
    Relay
    UPC
    818060010750
