Powerbass - PBX1-10D4 - 10" Dual 4 ohm VC 450Wrms / 900Wmax - Black/Gray

PowerBass S-84 8" Single 4-Ohm Subwoofer PowerBass S-Series woofers featuring a 4-layer wool/paper cone now sport a treated non-resonant finished, stamped steel basket that is custom tooled with distinctive X design. A 1.5” BASV voice coil former is used on the 8-inch, and a Large Roll foam surround for precise linear movement of the cone, which equals loud bass. The S Series subwoofers are well-suited for small sealed or ported enclosures and use dual 4-ohm and single 4-ohm voice coils for multiple bass applications. Now more than ever, S-Series woofers provide lots of value without sacrificing hard-hitting performance. Features - • 8" Single 4-Ohm Subwoofer • 125 watt RMS/250 Watts Max • Proprietary DDC Coated Paper/Wool Cone • Pressed 4-Layer Large Roll Foam Surround • 1.5" Vented BASV Voice Coil Former • Perimeter Aero-Vent Voice Coil Cooling Vents • Non Resonance DDC Coated Stamped Steel Basket • Rubber Mounting Gasket/Trim Ring • Chrome Push Terminals • Optimally Designed for Both Small Sealed or Ported Enclosures Specifications - • Nominal Impedance: 4-ohm • BL: 9 • Inputs: Single Coil • Subwoofer Frequency Range: 41 Hz - 800 Hz • Voice Coil Size: 1.5" • Material: Pressed Wool / Paper • Magnet Size: 116 oz • Sensitivity (1W / 1M): 86 dB • Motor Structure: 116 oz Ferrite • Cutout Diameter: 7 1/8 in • Mounting Depth: 3.5 in • Xmax: 7 mm • Spl: 86 dB • No: 0.24% • Qts: 0.43 • Qes: 0.467 • Qms: 4.85 • Mms: 49.6 g • Cms: 317 uM/N • Vas: 19 Ltr • SD: 206.12 sqCM • Fs: 41 Hz • Test Impedance: 3.2-ohms • VC Impedance: 4-ohm • Size: 8" • Sensitivity: 86 dB • Frequency Response: 41 Hz - 800 Hz • Voice Coil Size: 1.5 in • Power Handling (RMS/Peak): 125 / 250 watts

PowerBass XL-1044D 10" Dual 4-Ohm 350 Watt RMS Subwoofer Boasting a custom turbine style frame constructed of polycarbonate/glass fiber, this unique basket supports dual stack magnets and a extended dome backplate. They utilize a combination of perimeter and pole venting to keep air circulating over the voice coil so everything stays cool. A non-pressed paper cone was selected for its natural smooth bass reproduction and its ability to provide high output with low distortion even under the stress of high SPL. Finally, to make sure the power gets to the subwoofer, they used chrome push terminals for maximum current transfer. Features - • NEW Large Roll Santoprene® Surround • 10" Dual 4-Ohm Subwoofer • 350 watt RMS/700 Watts Max • Proprietary Non-pressed Paper DDC Coated Cone • 2.0" Vented BASV Voice Coil Former • Perimeter Aero-Vent Voice Coil Cooling Vents • Proprietary Non Resonance Polycarbonate/Glass Fiber Basket • Chrome Push Terminals • Optimally Designed for Both Small Sealed or Ported Enclosures Specifications - • Nominal Impedance: Dual 4-ohm • BL: 14.48 • Inputs: Dual Voice Coil • Subwoofer Frequency Range: 28 Hz - 350 Hz • Voice Coil Size: 2 in • Material: Non Pressed Paper • Magnet Size: 164 oz • Sensitivity (1W / 1M): 85.60 dB • Motor Structure: 164 oz • Cutout Diameter: 9 5/16" (237mm) • Mounting Depth: 5.25 in • Xmax: 8 mm • Spl: 85.60 dB • No: 0.219% • Qts: 0.387 • Qes: 0.423 • Qms: 4.558 • Mms: 146.27 g • Cms: 195 uM/N • Vas: 36.31 Ltr • SD: 363.05 sqCM • Fs: 29.8 Hz • Test Impedance: 3.24-ohm • VC Impedance: 4-ohm • Size: 10 in • Sensitivity: 85.60 dB • Frequency Response: 28 Hz - 350 Hz • Voice Coil Size: 2 in • Power Handling (RMS/Peak): 350 / 700 watts

PowerBass XL-1040T 10" 4-Ohm Shallow Mount Subwoofer The proprietary one piece cone gives accurate and efficient bass to a system without taking a whole lot of space. Designed to work best in a small sealed enclosure that will fit in most spaces that a standard woofer won't opens up new possibilities for the most discerning music fan. Using the same turbine style Poly/Glass Fiber basket as the standard XL subwoofers this shallower version offers all the features and reliability from the Xtreme family. Boasting a flat injection molded cone and inverted ferrite magnet these drivers come in nearly 2-inches shorter than their standard XL counterparts. Features - • New PBX logo dust cap • 10" Shallow Mount Single 4-Ohm Subwoofer • 350 Watts RMS/700 Watts Max • Proprietary Single Piece Injection Molded Flat Cone Design • High Roll Santoprene Surround • 2.0" Vented KSV Voice Coil Former • Perimeter Aero-Vent Voice Coil Cooling Vents • Proprietary Non Resonance Polycarbonate/Glass Fiber Basket • Chrome Push Terminals • Optimally Designed for Small Sealed Enclosures Specifications - • Nominal Impedance: single 4-ohm • BL: 14.693 • Inputs: Single Coil • Subwoofer Frequency Range: 35Hz - 500Hz • Voice Coil Size: 2 in • Material: Injection molded Polypropylene • Magnet Size: 116 oz • Sensitivity (1W / 1M): 88 dB • Cutout Diameter: 9 5/16 in • Mounting Depth: 3.4" • Xmax: 7.5 mm • Spl: 88db • No: 0.147% • Qts: 0.487 • Qes: 0.577 • Qms: 3.655 • Mms: 164.056 g • Cms: 127.039 uM/N • Vas: 21.02 Ltr • SD: 346.360 sqCM • Fs: 35hz • Test Impedance: 3.2-ohm • VC Impedance: 4-ohm • Size: 10" shallow • Sensitivity: 88 dB • Frequency Response: 35Hz - 500Hz • Voice Coil Size: 2" • Power Handling (RMS/Peak): 350 / 700 watts
