Seasonic - VERTEX PX 1000W Power Supply ATX 3.1 PCIe 5.1 (12V-2x6) Cybenetics Platinum A Fully Modular RTX 5090 AMD RX 9000 Ready - Black
Seasonic - VERTEX PX 1000W Power Supply ATX 3.1 PCIe 5.1 (12V-2x6) Cybenetics Platinum A Fully Modular RTX 5090 AMD RX 9000 Ready - Black
Wattage
1000 wattsRelated Item
Specifications
- Wattage1000 wattsModularFully modularEnergy EfficiencyCybenetics PlatinumATX Connector1PCIe Connector3Peripheral Connector1
- Key Specs
- Wattage: 1000 watts (Measurement of electrical power.)
- Modular: Fully modular
- Energy Efficiency: Cybenetics Platinum (Computer and server power supplies with the 80 PLUS certification are tested for operating efficiency at 10, 20, 50, and 100% of rated load. If a product tests at least 80% efficient, it qualifies for the base level 80 PLUS certification. Bronze, Silver, Gold, Platinum, and Titanium level certifications are given to products with even higher efficiency ratings.)
- ATX Connector: 1 (The configuration of the connector as it connects a computer power supply unit to an ATX motherboard.)
- PCIe Connector: 3 (The configuration of the connector as it connects a computer power supply unit to a PCIe (Peripheral Component Interconnect Express) motherboard interface.)
- Peripheral Connector: 1 (The configuration of the connector as it connects a computer power supply unit to a peripheral component such as a motherboard, video card, lighting, etc.)
- SATA Connector: 5 (The configuration of the connector as it connects a computer power supply unit to a SATA-based drive.)
- EPS12V Connector: 1 (The configuration of the connector as it connects a computer power supply unit to a EPS12V motherboard interface.)
- PCI Express Version: PCI Express 5.1
- Form Factor: ATX (The size, arrangement, and physical configuration of the product.)
- Product Length: 86.36 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- General
- Brand: Seasonic
- Model Number: Vertex PX-1000 ATX 3.1
- Product Name: VERTEX PX 1000W Power Supply ATX 3.1 PCIe 5.1 (12V-2x6) Cybenetics Platinum A Fully Modular RTX 5090 AMD RX 9000 Ready
- Color: Black
- Power
- Wattage: 1000 watts (Measurement of electrical power.)
- Modular: Fully modular
- Energy Efficiency: Cybenetics Platinum (Computer and server power supplies with the 80 PLUS certification are tested for operating efficiency at 10, 20, 50, and 100% of rated load. If a product tests at least 80% efficient, it qualifies for the base level 80 PLUS certification. Bronze, Silver, Gold, Platinum, and Titanium level certifications are given to products with even higher efficiency ratings.)
- Power Cord Included: true (Connects your product to an electrical outlet, allowing for immediate use (provided that other installation requirements are met).)
- Connectivity
- ATX Connector: 1 (The configuration of the connector as it connects a computer power supply unit to an ATX motherboard.)
- PCIe Connector: 3 (The configuration of the connector as it connects a computer power supply unit to a PCIe (Peripheral Component Interconnect Express) motherboard interface.)
- Peripheral Connector: 1 (The configuration of the connector as it connects a computer power supply unit to a peripheral component such as a motherboard, video card, lighting, etc.)
- SATA Connector: 5 (The configuration of the connector as it connects a computer power supply unit to a SATA-based drive.)
- EPS12V Connector: 1 (The configuration of the connector as it connects a computer power supply unit to a EPS12V motherboard interface.)
- PCI Express Version: PCI Express 5.1
- Form Factor: ATX (The size, arrangement, and physical configuration of the product.)
- Dimensions
- Product Height: 160.02 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 149.86 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 86.36 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 91.36 ounces (The out of box weight of the item.)
- Features
- Lighting Type: None
- Warranty
- Warranty - Parts: 12-Year
- Other
- UPC: 4711173877752
Designed for modern high-performance builds, VERTEX PX-1000 comes with a native 12V-2x6 connector and is NVIDIA RTX 5090 and AMD Radeon RX 9000 series ready. 80 PLUS and Cybenetics Platinum certified, Japanese capacitors, and a 12-year warranty provide long-term stability. The hybrid fan control and 135 mm FDB fan keep noise low while maintaining effective airflow.
- ATX 3.1 and 16-Pin PCIe Gen 5.1 Cable (12V-2x6): Seasonic’s latest VERTEX ATX 3 Series is designed and built to power new PC components requiring the new ATX 3.1 and PCIe 5.1 standards.
- Digital Hybrid Fan Control: Seasonic’s vast experience in designing the most silent and efficient power supplies on the market was translated into the development of Hybrid Mode; a state-of-the-art digital fan control that enables users to keep the overall fan noise at the lowest possible level.
- Fluid Dynamic Fan Bearing: High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. This reliable fan technology also greatly increases the lifespan of the fan.
- ATX 3.1 and 16-Pin PCIe Gen 5.1 Cable (12V-2x6): Seasonic’s latest VERTEX ATX 3 Series is designed and built to power new PC components requiring the new ATX 3.1 and PCIe 5.1 standards.
- Digital Hybrid Fan Control: Seasonic’s vast experience in designing the most silent and efficient power supplies on the market was translated into the development of Hybrid Mode; a state-of-the-art digital fan control that enables users to keep the overall fan noise at the lowest possible level.
- Fluid Dynamic Fan Bearing: High performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. This reliable fan technology also greatly increases the lifespan of the fan.
