Square D - QO 20 amps Plug In 2-Pole Circuit Breaker

The Square D Homeline 20 Amp Dual Function Circuit Breaker provides advanced protection by combining CAFI and GFCI (Class A) technologies into a single device, ensuring compliance with all code requirements while saving space and installation time. Designed for quick and easy setup, its pigtail neutral design connects directly to the neutral bar, allowing seamless power-up in Homeline load centers while also being compatible with plug-on neutral load centers. This single-pole breaker operates on 120/240V AC circuits and is ideal for residential branch circuits supplying wall receptacles, lighting fixtures, dishwashers, and disposals. Engineered for superior circuit protection, it effectively prevents overloads, short circuits, and dangerous arc and ground faults. Featuring a compact design that occupies just one space in the load center, it boasts a 20A current rating, 10kA breaking capacity, and UL-listed safety certification. Dimensions: 3.13" H x 1" W x 2.98" D.

Square D™ Homeline™ Miniature Circuit Breakers, HOM120CAFIC, is in a 1 inch wide format for 1-pole circuit breakers. They are designed to plug into Homeline load centers. Equipped with Combination ground and Arc-fault interrupter (Pigtail Neutral). Comes in clam packing. UL listed.

Plug In Circuit Breaker, Amps 20, Number of Poles 1, Circuit Breaker Type Combination Arc Fault Circuit Interrupter, AC Voltage Rating 120VAC, DC Voltage Rating Not Rated, For Use With QO Load Centers, Series QO, Terminal Connection Screw Clamp, Min. Wire Size 14 AWG, Max. Wire Size 8 AWG, Length 4.75 In., Width 0.75 In., Depth 2.98 In., Standards UL Listed, CSA Certified, NEC, Max. AIR Rating 10kA 'Manufacturer Contact InformationHAUPPAUGE, NY, 11788 US
