Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - Black
Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - Black
Color
Black$39.99 delivery to
Need-haul away?
- We’ll haul away your old item and make sure it’s properly and safely recycled.
- We can also move it to another location in your home if the path is clear of obstructions.
- We can’t remove doors from your home (or a product) to make an item fit through a doorway
- Relocated appliances will not be connected to utilities
Related Item
Specifications
- Color FinishBlackProduct Height4 5/16 inchesProduct Width35 15/16 inchesProduct Depth18 5/8 inchesExhaust Vent LocationTopVent TypeDucted
- Key Specs
- Color Finish: Black
- Product Height: 4 5/16 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 35 15/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 18 5/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Top
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Whirlpool
- Model Number: UXT2030ADB
- Product Name: 30" Externally Vented Range Hood
- Color: Black
- Color Finish: Black
- Dimensions
- Product Height: 4 5/16 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 24 inches
- Maximum Installation Height Above Cooktop: 36 inches
- Product Width: 35 15/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 18 5/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 12 pounds (The out of box weight of the item.)
- Duct Shape: Round
- Round Duct Diameter: 6 inches
- Duct Length: 420 inches
- Features
- Exhaust Vent Location: Top
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Under cabinet
- Number of Fan Speeds: 2
- Temperature Sensor: false (Integrated sensor adjusts ventilation power as needed to accommodate high temperatures.)
- Control Type: Button
- Delay Shut-Off: false (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: false
- Remote Control: false
- Damper Included: true
- Integrated Light(s): true
- Number of Lights: 1
- Number of Light Levels: 2
- Bulb Type Required: Incandescent
- Bulb(s) Included: true
- Performance
- Maximum Air Flow Capacity: 250 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Maximum Operating Sound Level: 5.3 sones (The perceived intensity of the operating sound produced by the product at its highest setting. The higher the sone rating, the louder the noise level.)
- Minimum Operating Sound Level: 1.7 sones (The perceived intensity of the operating sound produced by the product at its lowest setting. The higher the sone rating, the louder the noise level.)
- Filter Info
- Dishwasher-Safe Filter: true
- Removable Grease Filter: true
- Number of Filters: 2
- Electrical
- Amperage: 15 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): CSA Listed, UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Warranty
- Warranty - Parts: 1 year limited
- Warranty - Labor: 1 year limited
- Other
- UPC: 883049326405
This Whirlpool UXT2030ADB externally vented range hood features a 2-speed, 250 cfm fan that effectively removes steam, smoke and odors from your kitchen. Incandescent lighting promotes clear visibility while cooking.
- Grease Filter: The grease filter helps trap unwanted grease and helps remove odors.
- Powerful 2-Speed Fan: Two fan speeds provide the right amount of ventilation for every meal you prepare. (Performance varies based on installation. Resources available at aham.org.)
- Incandescent Lighting: Incandescent lighting makes it easy to see what you’re cooking with bulbs that are inexpensive to replace.
- FIT system: The FIT system helps reduce measuring, cutting and trim so that your hood is a perfect fit every time. (Based on typical installation with existing electrical and ventilation connections. Consult a professional installer to ensure your installation complies with code requirements.)
Whats Included
- Hardware
- Whirlpool 30" Externally Vented Range Hood
A: Great question Charles. This unit has a width of 29 15/16 inches. We hope this information helps in moving forward.
Q: Does hood come with an over the stove light?
A: Handyman, thanks for the inquiry. There is a cooktop light on this model. Hopefully this information is beneficial to you. Thank you for your inquiry regarding our Whirlpool appliances!
Q: Do you have replacement screens that fit this model?
A: Hello! The replacement grease filters for model UXT2030ADW are W10395127. Thank you for your inquiry about our Whirlpool® appliances.
Q: Is it compatible for a rectangle vent 10" wide x 5" deep?
A: Hello VentQ, please see the link to the Installation Instructions for more information. bit.ly/3XVSsjO Thank you for your inquiry on our Whirlpool appliances.
Q: Light works but fan doesn't
A: Hello dough! We are terribly sorry to hear about your concern. We would recommend contacting Whirlpool at 800-253-1301. We are available Monday & Tuesday 8:00 am - 8:00 pm and Wednesday through Friday 9:00 am - 7:00 pm. They will be better able to assist you.
A: undefined
A: Hello Flatop, this model needs to be vented outside. Hopefully this information is beneficial to you. Thank you for your inquiry regarding our Whirlpool appliances!
Compare similar products
This Whirlpool UXT2030ADB externally vented range hood features a 2-speed, 250 cfm fan that effectively removes steam, smoke and odors from your kitchen. Incandescent lighting promotes clear visibility while cooking.
The F40000 series provides installation flexibility with 4-way convertibility to fit virtually all applications. The hood is designed for under cabinet use and installs as 3-1/4 in. x 10 in. ducted opening with vertical or horizontal ducting; or 7 in. round vertical ducting or as non-ducted with air recirculation. The hood is equipped with a 230 MAX Blower CFM designed for years of trouble free service, an easy to clean grease filter, and control switches for fan speed and light activation.
From the leader in residential indoor air quality, this under-cabinet range hood by Broan-NuTone is built to surpass industry standards with over 50 points of inspection, engineered as a reliable ventilation solution. The durable hood vent is up to 20% more effective at removing pollutants than the leading competitor with power ventilation at 350 Max Blower CFM to capture and remove smoke and odors from the kitchen. The Glacier range hood is also up to 44% quieter: 1.5 sones is equivalent to a refrigerator running, so it won't interfere with daily life. The EZ1 Install System allows for a quick and easy 1-person installation, and the ENERGY STAR Certification is both code compliant and provides cost savings. The 1-Level LED lighting and a 2-Speed hidden rocker controls make cooking a breeze. At Broan-NuTone we believe that better quality of air means better quality of life.
Upgrade your kitchen with this Whirlpool 30-inch white range hood. Two fan speed settings provide flexible ventilation for everyday cooking, and quiet operation at 45 to 50 dBA helps maintain a noise-free atmosphere. The FIT system on this Whirlpool 30-inch white range hood simplifies installation without the need for measuring and cutting.How to Measure for a New ApplianceA little measuring now can help you avoid delivery headaches later.
| Pros for Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - Black | |||
|---|---|---|---|
| There were no pros for this product— | Ease of use, Lighting, Fit, Performance, Color | There were no pros for this product— | Noise Level, Ease of Installation, Appearance, Price, Light |
| Cons for Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - Black | |||
| There were no cons for this product— | There were no cons for this product— | There were no cons for this product— | Fan Power, Suction, Size |
Specs
Reviews
Customers are saying
Customers consistently note the easy installation of the 30" Externally Vented Range Hood.
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 5 out of 5 stars
Great value.
Simple range hood. Great price. This was all I needed for my installation. The fan isn't too loud.
This review is from Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - Black
CSSB Posted
- Rated 5 out of 5 stars
Great range hood.
This is a great range hood for its intended purpose. For a basic range hood this one is hard to beat. It was easy to install, and it is well constructed and sturdy. The fan motor is quiet, even on the high speed setting. I bought this to replace the original Ventline range hood that I had for about 18 years. This seems to be a much better range hood. The price at Best Buy was the least expensive that I found. The Ventline range hood that I replaced moved about 100 cfm, this range hood moves up to 190 cfm, almost twice the capacity. It is also a rather nice looking range hood as well. I would purchase this range hood again, and would recommend it to others.
This review is from Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - White
Watchman555 Posted
- Rated 5 out of 5 stars
Perfect!
Just what I was looking for, quiet powerful fan with a light. Works well with my new range. Easy self install. Very happy with purchase.
This review is from Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - Black
Patriots88 Posted
