Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - Black
Color
BlackDelivery to
Need-haul away?
- We’ll haul away your old item and make sure it’s properly and safely recycled.
- We can also move it to another location in your home if the path is clear of obstructions.
- We can’t remove doors from your home (or a product) to make an item fit through a doorway
- Relocated appliances will not be connected to utilities
Related Item
Specifications
- Color FinishBlackProduct Height4 15/16 inchesProduct Width29 15/16 inchesProduct Depth18 5/8 inchesExhaust Vent LocationRearVent TypeDucted
- Key Specs
- Color Finish: Black
- Product Height: 4 15/16 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 15/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 18 5/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Rear
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Whirlpool
- Model Number: UXT3030ADB
- Product Name: 30" Externally Vented Range Hood
- Color: Black
- Color Finish: Black
- Dimensions
- Product Height: 4 15/16 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 24 inches
- Maximum Installation Height Above Cooktop: 36 inches
- Product Width: 29 15/16 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 18 5/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 12 pounds (The out of box weight of the item.)
- Duct Shape: Rectangular
- Duct Length: 420 inches
- Duct Width: 10 inches
- Features
- Exhaust Vent Location: Rear
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Under cabinet
- Number of Fan Speeds: 2
- Temperature Sensor: false (Integrated sensor adjusts ventilation power as needed to accommodate high temperatures.)
- Control Type: Rocker
- Delay Shut-Off: false (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: false
- Remote Control: false
- Damper Included: true
- Integrated Light(s): true
- Number of Lights: 1
- Number of Light Levels: 2
- Bulb Type Required: Incandescent
- Bulb(s) Included: true
- Performance
- Maximum Air Flow Capacity: 250 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Maximum Operating Sound Level: 3.2 sones (The perceived intensity of the operating sound produced by the product at its highest setting. The higher the sone rating, the louder the noise level.)
- Minimum Operating Sound Level: 1.3 sones (The perceived intensity of the operating sound produced by the product at its lowest setting. The higher the sone rating, the louder the noise level.)
- Filter Info
- Dishwasher-Safe Filter: false
- Removable Grease Filter: true
- Number of Filters: 2
- Electrical Specification
- Amperage: 15 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Warranty
- Warranty - Parts: 1 year limited
- Warranty - Labor: 1 year limited
- Other
- UPC: 883049326429
Rid your kitchen of lingering cooking odors with the help of this Whirlpool UXT3030ADB externally vented range hood, which features a 2-speed fan with a 250 cfm exhaust capacity to help keep your kitchen smelling fresh.
- Grease Filter: The grease filter helps trap unwanted grease and helps remove odors.
- Powerful 2-Speed Fan: Two fan speeds provide the right amount of ventilation for every meal you prepare. (Performance varies based on installation. Resources available at aham.org.)
- Incandescent Lighting: Incandescent lighting makes it easy to see what you’re cooking with bulbs that are inexpensive to replace.
- FIT System: The FIT system helps reduce measuring, cutting and trim so that your hood is a perfect fit every time. (Based on typical installation with existing electrical and ventilation connections. Consult a professional installer to ensure your installation complies with code requirements.)
- Grease Filter: The grease filter helps trap unwanted grease and helps remove odors.
- Powerful 2-Speed Fan: Two fan speeds provide the right amount of ventilation for every meal you prepare. (Performance varies based on installation. Resources available at aham.org.)
- Incandescent Lighting: Incandescent lighting makes it easy to see what you’re cooking with bulbs that are inexpensive to replace.
- FIT System: The FIT system helps reduce measuring, cutting and trim so that your hood is a perfect fit every time. (Based on typical installation with existing electrical and ventilation connections. Consult a professional installer to ensure your installation complies with code requirements.)
Whats Included
- Hardware
- Whirlpool 30" Externally Vented Range Hood
- Hardware
- Whirlpool 30" Externally Vented Range Hood
Q: Light works but fan doesn't
A: Hello dough! We are terribly sorry to hear about your concern. We would recommend contacting Whirlpool at 800-253-1301. We are available Monday & Tuesday 8:00 am - 8:00 pm and Wednesday through Friday 9:00 am - 7:00 pm. They will be better able to assist you.
A: undefined
A: Hello Flatop, this model needs to be vented outside. Hopefully this information is beneficial to you. Thank you for your inquiry regarding our Whirlpool appliances!
Q: what is the overall depth for this model?
A: The depth is 18 5/8 inches for this Whirlpool® Range Hood. Thank you for your interest in our Whirlpool Appliances!
Q: Does this hood have to be mounted to cabinet or just to the wall
A: Cabinets and has a plug in
A: Hello rangehood3! Yes, there are 2 lights on this model. They will use a standard Incandescent bulb. Thank you for your inquiry on our Whirlpool appliances.
Q: Is this available in black?
A: Dee, the Range Hood is available in black. Hopefully this information is beneficial to you. Thank you for your inquiry regarding our Whirlpool appliances! https://www.bestbuy.com/site/searchpage.jsp?st=UXT3030ADB&_dyncharset=UTF-8&id=pcat17071&type=page&sc=Global&cp=1&nrp=&sp=&qp=&list=n&af=true&iht=y&usc=All+Categories&ks=960&keys=keys
Q: Is this vent hood available in a Coeur s alene? Johnny C
A: undefined
Compare similar products
Rid your kitchen of lingering cooking odors with the help of this Whirlpool UXT3030ADB externally vented range hood, which features a 2-speed fan with a 250 cfm exhaust capacity to help keep your kitchen smelling fresh.
FOTILE Slant Vent Series, 30 In. wall mount under-cabinet ducted range hood with Dual-Centrifuge Fan System is capable of normally producing 530 CFMs, but with WhisPower Motor Technology and Capture-Shield extraction, it can achieve a maximum power of 850 CFM and a lowest noise level of 39dB. With a 90 degree Open Fume Baffle Plate it captures smoke and fumes before they escape. A large 6 square feet coverage area easily covers all 4/5 burners on your cooktop, guiding smoke upwards and creating a barrier to prevent you from breathing in harmful smoke and grease. Mechanical buttons with Memory Function keep your preference for fan speed. The Onyx Black color compliments all modern kitchen designs.
The F40000 series provides installation flexibility with 4-way convertibility to fit virtually all applications. The hood is designed for under cabinet use and installs as 3-1/4 in. x 10 in. ducted opening with vertical or horizontal ducting; or 7 in. round vertical ducting or as non-ducted with air recirculation. The hood is equipped with a 230 MAX Blower CFM designed for years of trouble free service, an easy to clean grease filter, and control switches for fan speed and light activation.
Clear away smoke and odors with this stainless steel Whirlpool range hood. At low speeds, the fan operates quietly to allow uninterrupted conversations, and incandescent bulbs brighten up the cooktop to support food preparation. This Whirlpool range hood features a duct-free design for quick and easy installation with no measuring, cutting or filler strips.How to Measure for a New ApplianceA little measuring now can help you avoid delivery headaches later.
| Pros for Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - Black | |||
|---|---|---|---|
| Noise Level, Lighting, Overall Performance, Installation Ease | There were no pros for this product— | Lighting, Ease of use, Fit, Color, Performance | Noise Level, Ease of Installation, Appearance, Price, Light |
| Cons for Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - Black | |||
| There were no cons for this product— | There were no cons for this product— | There were no cons for this product— | Fan Power, Suction, Size |
Specs
Reviews
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 5 out of 5 stars
Great value.
Simple range hood. Great price. This was all I needed for my installation. The fan isn't too loud.
Posted by CSSB
- Rated 5 out of 5 stars
Great range hood.
This is a great range hood for its intended purpose. For a basic range hood this one is hard to beat. It was easy to install, and it is well constructed and sturdy. The fan motor is quiet, even on the high speed setting. I bought this to replace the original Ventline range hood that I had for about 18 years. This seems to be a much better range hood. The price at Best Buy was the least expensive that I found. The Ventline range hood that I replaced moved about 100 cfm, this range hood moves up to 190 cfm, almost twice the capacity. It is also a rather nice looking range hood as well. I would purchase this range hood again, and would recommend it to others.
This review is from Whirlpool - 30 inches - Externally Vented - Under cabinet Range Hood - White
Posted by Watchman555
- Rated 5 out of 5 stars
Perfect!
Just what I was looking for, quiet powerful fan with a light. Works well with my new range. Easy self install. Very happy with purchase.
Posted by Patriots88
