ZLINE - 34 inches - Externally Vented - Under cabinet Range Hood - Brushed Stainless Steel
Need-haul away?
More Buying Options
Related Item
Specifications
- Color FinishStainless steelProduct Height14 1/5 inchesProduct Width34 inchesProduct Depth15 inchesVent TypeDuctedVent StyleExternal
- Key Specs
- Color Finish: Stainless steel
- Product Height: 14 1/5 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 34 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 15 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: ZLINE
- Model Number: 695-34
- Product Name: 34 in. Ducted Wall Mount Range Hood Insert in Stainless Steel (695-34)
- Color: Brushed Stainless Steel
- Color Finish: Stainless steel
- Dimensions
- Product Height: 14 1/5 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 30 inches
- Maximum Installation Height Above Cooktop: 36 inches
- Product Width: 34 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 15 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 34 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 45 pounds (The out of box weight of the item.)
- Features
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Under cabinet
- Number of Fan Speeds: 4
- Control Type: Button
- Display Type: LCD
- Integrated Light(s): true
- Bulb Type Required: LED
- Bulb(s) Included: true
- Filter Info
- Filter Material: Stainless steel
- Dishwasher-Safe Filter: true
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 0 years
- Other
- UPC: 855187005023
The ZLINE 34 in. Ducted Wall Mount Range Hood Insert in Stainless Steel (695-34) provides a professional culinary experience by pairing built-to-last quality with a timeless style. Achieve ZLINE Attainable Luxury® excellence with unrivaled performance designed to enhance your kitchen’s capability.
- Integrated Insert Design: This ZLINE wall mount range hood insert is designed to install seamlessly into custom-built cabinetry set-ups, providing professional-grade power without the visible exterior shell
- Corrosion-Resistant Stainless Steel: Manufactured with brushed 430 grade stainless steel, which contains rust and corrosion-resistant properties to ensure a durable insert that will last for years to come
- Convenient Control Panel: Easy-to-use push button controls let you easily adjust fan speeds and lighting options
- 4-Speed Fan Control: Choose the appropriate air flow among 280/420/560/700 CFM for your cooking situation
- Powerful Ventilation: The highest speed setting of 700 CFM air flow efficiently moves large amounts of air away from your cooking area
- Minimal Cleaning: This range hood includes dishwasher-safe stainless steel baffle filters that are easy to remove for regular cleaning
- Standard Ductwork: ZLINE range hoods are designed to fit standard (circular) ductwork for simple installation; this hood includes a transition piece for 8 in. diameter ducting
- LED Lighting: ZLINE range hoods come equipped with energy-efficient LED lights to illuminate the cooking surface below
- Electrical Requirements: Requires a dedicated 120V, 60Hz, 15-amp circuit with a NEMA 5-15 3-wire plug system
- Warranty: ZLINE range hoods carry a 3-year parts-only warranty, in addition to a lifetime motor warranty
Whats Included
- ZLINE 34" Externally Vented Range Hood
Product Manuals
Q: What is the exhaust capacity of this ZLINE range hood?
A: This ZLINE range hood has an exhaust capacity of 1,200 cfm.
Q: How powerful is the blower on this range hood insert?
A: This range hood insert has a powerful 1,200 cfm blower that can quickly pull smoke and cooking odors out of the air.
Q: Does this ZLINE range hood come with a light to illuminate the cooking surface?
A: Yes, this ZLINE range hood has built-in LED lighting to illuminate your cooktop.
Q: What type of filter does this range hood use, and is it easy to clean?
A: This range hood uses a dishwasher-safe grease filter, making cleanup easy.
Q: What is the maximum height at which this range hood can be installed above the cooktop?
A: The maximum installation height above the cooktop for this range hood is 36 inches.
Q: Is the blower equipped with code compliant controls, to adjust airflow to 400 cfm where required?
A: Hello, thank you for reaching out. This remote blower has a max of 700 CFMs. You can change the CFMs based on the speed: 280/420/560/700 CFMs. However, if you are required to have no more than 400 CFMs we do have many range hoods/remote blowers that have a max of 400 CFMs. Please contact us at zlienkitchen.com/contact for further recommendations. We would be happy to assist further. Thank you.
Q: What is the noise level of the fan motor on high setting, and what is the CFM?
A: Hi Lyn, Thanks for reaching out. On the highest fan speed, this motor will pull 700 CFM at 52 dB. If there is anything else we can help with, please feel free to reach out at zlinekitchen.com/contact. Thank you!
Compare similar products
The ZLINE 34 in. Ducted Wall Mount Range Hood Insert in Stainless Steel (695-34) provides a professional culinary experience by pairing built-to-last quality with a timeless style. Achieve ZLINE Attainable Luxury® excellence with unrivaled performance designed to enhance your kitchen’s capability.
One of our founding models, Typhoon is not only good looking but packed with powerful, virtually noise-free 850-CFM blowers. It includes a convenient self-cleaning system along with tri-level LumiLight LED lights that invite you and your guests to a warm respite from the everyday. Available in black, white and stainless steel. Now with Quiet Speed Setting (QSS) and ACT technology.
ZLINE 34" 700 CFM Outdoor Range Hood Insert in Stainless Steel (695-304-34) has a modern design and built-to-last quality, making it a great addition to any indoor or outdoor kitchen. Equipped with the highest quality, 304 grade stainless steel, this hood is rust and weather resistant, giving it the most desirable finish for indoor and outdoor kitchens alike. Easily conceal it in a custom made hood or cabinetry, over your kitchens stovetop or range, or use it over your grill for safer BBQing. This hood inserts high-performance, 700 CFM 4-speed motor will provide all the power you need to quietly and efficiently ventilate your kitchen while cooking. Enjoy modern features, including built-in LED lighting for illuminated cooking and dishwasher-safe stainless steel baffle filters for easy clean-up. ZLINE Hoods are ETL Listed and have one of the easiest installations in the industry. ZLINE continues to revolutionize the industry by providing our customers with Attainable Luxury. ZLINE stands by all products with its manufacturer parts warranty. The 695-304-34 ships next business day when in stock.
Clear kitchen air quickly with this 30-inch KitchenAid low profile hood. The perimeter ventilation system pulls in air from the edges for efficient smoke and odor removal, and the slim design leaves plenty of room underneath it to cook. This KitchenAid low profile hood uses a Whisper Quiet system to keep noise under control.
| Pros for ZLINE - 34 inches - Externally Vented - Under cabinet Range Hood - Brushed Stainless Steel | |||
|---|---|---|---|
| There were no pros for this product— | Noise Level, Design | There were no pros for this product— | Overall Performance |
| Cons for ZLINE - 34 inches - Externally Vented - Under cabinet Range Hood - Brushed Stainless Steel | |||
| There were no cons for this product— | Fan | There were no cons for this product— | There were no cons for this product— |
Specs
Reviews
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 3 out of 5 stars
Nice looking.
Very hard to install. I have installed many range hoods but this one is very difficult.
DCBuilders13 Posted
