Specifications
- Motherboard Form FactorMini-ITX, microATX, ATXMaximum GPU Length400 millimetersProduct Height16 1/10 inchesProduct Width7 1/2 inchesProduct Depth18 1/2 inchesWindow Panel(s)Left side
- Key Specs
- Motherboard Form Factor: Mini-ITX, microATX, ATX (Physical size of the motherboard, which can determine how many PCIe slots are available. Smaller board means fewer slots and features.)
- Maximum GPU Length: 400 millimeters
- Product Height: 16 1/10 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 7 1/2 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 18 1/2 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Window Panel(s): Left side
- Case Material: Other
- General
- Brand: Thermaltake
- Model Number: CA-1K7-00M1NN-01
- Product Name: V100 Perforated Computer Case
- Color: Black
- Case Material: Other
- Assembly Required: No
- Compatibility
- Motherboard Form Factor: Mini-ITX, microATX, ATX (Physical size of the motherboard, which can determine how many PCIe slots are available. Smaller board means fewer slots and features.)
- Maximum Power Supply Length: 169.93 millimeters
- Maximum GPU Length: 400 millimeters
- Number of Expansion Slots: 7
- Ports
- USB Port Location: Front
- Number of USB Ports (Total): 3
- USB Ports: 3 x USB-A (The number and type of USB ports the product has.)
- Headphone Jack: true (The device features an interface that allows for the connection of headphones.)
- Microphone Input: true (The device features an input for connecting an external microphone.)
- Bays
- Number Of Internal 2.5" Bays: 2
- Number Of Internal 3.5" Bays: 2
- Dimensions
- Product Height: 16 1/10 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 7 1/2 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 18 1/2 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 176.32 ounces (The out of box weight of the item.)
- Features
- Enclosure Type: Mid tower
- Window Panel(s): Left side
- Customizable Case Lighting: false
- Lighting Type: None
- Cooling
- Maximum CPU Cooler Height: 160.02 millimeters
- Number of Fans Supported: 7
- Cooling System: Air (A computer's CPU generates heat while operating and requires a cooling system to keep internal components functioning properly. Air cooling uses fans to draw in cool air and exhaust hot air, while liquid cooling uses coolant-filled tubes and water blocks to regulate internal temperature more efficiently.)
- Cooling Support: Fan Cooling ready
- Number of Fans Included: 1
- Radiator Support: Yes
- Other
- UPC: 841163002391
ATX mid-tower chassis with one preinstalled 120mm fan and a perforated side panel Thermaltake V100 Mid-Tower Chassis The V100 mid-tower chassis features one preinstalled 120mm fan, a perforated side panel and supports up to a standard ATX motherboard. The V100 supports the latest PC hardware and all high-end GPU solutions, guarantees on unparalleled expandability for high-end configurations and liquid cooling system to satisfy the market where users have opted for stylish PC chassis with advanced features and aesthetic appeal. Gaming-Oriented Concept Designed for gamers, the heightened foot-stands at the bottom help enhance airflow and the side window panel offers a direct view of interior components of the system. Built-in PSU Cover Equipped with a full-length PSU cover with vent hole design to hide those unsightly cables from view and give your build a sleek and tidy look, and what's more, a better airflow. Outstanding Expandability The V100 supports motherboards up to standard ATX, a tower CPU cooler with maximum height 160mm, and a expansion slot VGA of up to 400mm in length without HDD rack. Most importantly, the hidden drive bay design guarantees expandability for more liquid cooling components. Outstanding Ventilation The V100's unparalleled cooling ability offers various mounting points to support any type of cooling you can dream of including DIY/AIO liquid-cooling systems and air-cooling units. Apart from the built-in 120mm rear fan, users are allowed to install up to 360mm DIY liquid cooling radiator or two 140mm fans at the front to optimize system ventilation.
- Front-panel Ports: Include Front USB, Front Audio In, Front Audio Out for installing peripherals.
- Total Drive Bays: Include 6 expansion drive bays
- 4.72" Fan: Along with a 4.72" fan helps dissipate heat for improved system operation. Supports up to 7 fans for expanded cooling options.
- 7 Expansion Slots: Lets you install a host of expansion cards
- Elegant Look: Black casing color to add a premium look and feel
- Construction: Manufactured with spcc material for durability
Whats Included
- Thermaltake V100 Perforated Computer Case
- Owner's manual
Product Manuals
Q: What is the Thermaltake V100 made of?
A: The Thermaltake V100 is made from SPCC steel for durability.
Q: What is the maximum length of a graphics card that can fit in the Thermaltake V100?
A: The Thermaltake V100 can support a graphics card with a maximum length of 400mm without the HDD rack.
Q: How many drive bays does the Thermaltake V100 have?
A: This computer case has 6 drive bays.
Q: How many expansion slots does the Thermaltake V100 have?
A: The Thermaltake V100 has 7 expansion slots for adding components like graphics cards.
Q: What type of motherboard does the Thermaltake V100 support?
A: The Thermaltake V100 supports motherboards up to standard ATX.
Q: Does the Thermaltake V100 case come with a fan?
A: Yes, the Thermaltake V100 comes with one preinstalled 120mm fan.
Q: Does the Thermaltake V100 have USB ports on the front panel?
A: Yes, the front panel includes one USB 3.0 port and two USB 2.0 ports.
A: Acrylic, according to ThermalTake's website.
Thermaltake - V100 Perforated Computer Case - Black
Related Item
Compare similar products
$49.99
ATX mid-tower chassis with one preinstalled 120mm fan and a perforated side panel Thermaltake V100 Mid-Tower Chassis The V100 mid-tower chassis features one preinstalled 120mm fan, a perforated side panel and supports up to a standard ATX motherboard. The V100 supports the latest PC hardware and all high-end GPU solutions, guarantees on unparalleled expandability for high-end configurations and liquid cooling system to satisfy the market where users have opted for stylish PC chassis with advanced features and aesthetic appeal. Gaming-Oriented Concept Designed for gamers, the heightened foot-stands at the bottom help enhance airflow and the side window panel offers a direct view of interior components of the system. Built-in PSU Cover Equipped with a full-length PSU cover with vent hole design to hide those unsightly cables from view and give your build a sleek and tidy look, and what's more, a better airflow. Outstanding Expandability The V100 supports motherboards up to standard ATX, a tower CPU cooler with maximum height 160mm, and a expansion slot VGA of up to 400mm in length without HDD rack. Most importantly, the hidden drive bay design guarantees expandability for more liquid cooling components. Outstanding Ventilation The V100's unparalleled cooling ability offers various mounting points to support any type of cooling you can dream of including DIY/AIO liquid-cooling systems and air-cooling units. Apart from the built-in 120mm rear fan, users are allowed to install up to 360mm DIY liquid cooling radiator or two 140mm fans at the front to optimize system ventilation.
$49.99
Build a PC that supports powerful hardware and advanced GPU solutions with this Thermaltake Versa H17 micro case. The top-facing I/O ports offer quick access when needed, while a cable routing management system hides cables behind the motherboard to avoid tangling and ensure better airflow. This Thermaltake Versa H17 micro case features an elegant front panel that keeps drivers hidden for an aesthetically pleasing look.
$54.99
Designed for entry-level PC builders and gamers, Thermaltake Versa H18 Tempered Glass Edition Micro Case features the simplicity appearance with easy cable management design, AIO liquid cooling compatible, and ample ventilation options. Supporting the latest PC hardware and all high-end GPU solutions, the Versa H18 TG is a good choice for those who opt for stylish PC case with manageable frame size and advanced features.The beautiful tempered glass window allows users to display all component of the build, offering a direct view of inner system. The mesh front panel and perforated top panel plus the heighted foot-stands at the bottom provide efficient airflow for the system.
$94.99
The H5 Flow boosts airflow and GPU cooling with its fully-perforated PSU shroud, mesh panels, and robust radiator support.
| Pros for Thermaltake - V100 Perforated Computer Case - Black | |||
|---|---|---|---|
| Price, Build Quality, USB Ports, Space | Cable Management | Cable Management | There were no pros for this product— |
| Cons for Thermaltake - V100 Perforated Computer Case - Black | |||
| There were no cons for this product— | There were no cons for this product— | Power Button, Size | There were no cons for this product— |
Specs
Explore tech essentials Sponsored
Reviews
Customers are saying
Customers value the V100 Perforated Computer Case for its budget-friendly price point and its clean aesthetics. The case is seen as a great option for budget builds, with customers appreciating the value it offers. The cable management features, such as the PSU shroud, are also seen as a positive aspect of the case.
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 4 out of 5 stars
It is a great case, but came defective.
I got this case for a budget build. I had the entire pc built and was putting in the power supply, when I noticed that the metal where the power supply should sit was bent. We were able to bend it back down a bit, and we only could screw in 3 of the 4 screws for the power supply.
Posted by TnoffApps
- Rated 5 out of 5 stars
Great case for my first build
Really good case for the price and for my first build. Was able to fit and install everything with ease. Currently using a MSI Z590 mobo, i7 11700k, RTX 3060, 32 GB RAM
Posted by mj41773
- Rated 4 out of 5 stars
Great case for minimilist build.
I guess I bought the last one on Best Buy. Highly recommend it if you can find it somewhere else. Plenty of room for your build, just mind the size of your heat sink if you mount a fan on the inside of the vent panel, I mounted mine on the outside and it cools great. Tight fit for large power supply's, having the power supply close to the HDD cage may cause some feed back over audio, recommend that you use an audio DI to negate that. Loses a star coz the hardware screws for mounting your mobo and other tech are quite small and didn't allow for as smooth a build as I wanted. Recommend buying a stand off kit with better mounting options.
Posted by bbilb
