Specifications
- Color FinishStainless steelProduct Height11 1/4 inchesProduct Width29 7/8 inchesProduct Depth11 1/8 inchesExhaust Vent LocationTop/RearVent TypeDucted, Ductless
- Key Specs
- Color Finish: Stainless steel
- Product Height: 11 1/4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 29 7/8 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 11 1/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Exhaust Vent Location: Top/Rear
- Vent Type: Ducted, Ductless
- Vent Style: Convertible (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: Zephyr
- Model Number: ZPI-E30BG
- Product Name: Pisa 30 in. 500 CFM Under Cabinet Range Hood
- Color: Stainless Steel
- Color Finish: Stainless steel
- Dimensions
- Product Height: 11 1/4 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 20 inches
- Maximum Installation Height Above Cooktop: 32 inches
- Product Width: 29 7/8 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 11 1/8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 30 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 33 pounds (The out of box weight of the item.)
- Duct Shape: Round
- Cut-Out Dimensions
- Cut-Out Width: 19 7/8 inches (Minimum required width of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Cut-Out Depth: 10 1/8 inches (Minimum required depth of the installation location for a standard installation of the product. This measurement will help you determine if the appliance will fit into the desired space and have the clearance necessary for proper operational use. Please refer to the manufacturer’s installation documentation for detailed measurement requirements.)
- Features
- Exhaust Vent Location: Top/Rear
- Vent Type: Ducted, Ductless
- Vent Style: Convertible (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Insert
- Number of Fan Speeds: 3
- Temperature Sensor: false (Integrated sensor adjusts ventilation power as needed to accommodate high temperatures.)
- Control Type: Slide
- Display Type: None
- Delay Shut-Off: false (Use this feature after cooking to continue ventilating any fumes or odors. When time's up, the operation automatically shuts off.)
- Auto Fan Shut-Off: false
- Remote Control: false
- Integrated Light(s): true
- Number of Lights: 2
- Number of Light Levels: 2
- Bulb Type Required: LED
- Bulb(s) Included: true
- Maximum Bulb Wattage: 6 watts
- Performance
- Maximum Air Flow Capacity: 500 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Minimum Air Flow Capacity: 230 cubic feet per minute (Minimum amount of air that the appliance will ventilate at its lowest setting.)
- Maximum Operating Sound Level: 5.3 sones (The perceived intensity of the operating sound produced by the product at its highest setting. The higher the sone rating, the louder the noise level.)
- Minimum Operating Sound Level: 1.7 sones (The perceived intensity of the operating sound produced by the product at its lowest setting. The higher the sone rating, the louder the noise level.)
- Filter Info
- Filter Material: Aluminum Mesh
- Removable Grease Filter: true
- Number of Filters: 2
- Electrical Specification
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Warranty
- Warranty - Parts: 3 Years
- Warranty - Labor: 1 Year
- Other
- UPC: 646328009662
Tucked neatly out of sight within your cabinetry, Pisa is a minimal alternative to your typical under-cabinet range hood. Adorned with LumiLight LED Lighting and powered by the strength of a 500-CFM or 290-CFM blower, Pisa’s low-profile body delivers stunning design and quality performance. Its retractable visor helps with the capture of air and puts control at your fingertips. Pisa is ideal for kitchens that require a more discreet, sophisticated look.
- Quiet and efficient, three speed levels allow you to control proper airflow depending on your cooking needs.: 3-speed mechanical slide controls move along a track to adjust the range hood blower and dual-level LED lighting.
- 3 Speed Levels: Quiet and efficient, three speed levels allow you to control proper airflow depending on your cooking needs.
- LumiLight LED Lighting: LumiLight LED lights are eco-friendly and built to last with a lifetime of more than 25,000 hours. The tri-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
- Dual-Level Lighting: The dual-level dimmable LEDs require less energy than traditional halogen lights, are cool to the touch, and provide uniform light distribution.
- Dishwasher Safe Aluminum Mesh Filters: High-quality, dishwasher-safe aluminum mesh filters for improved capture and performance.
- Recirculating Option: Part # ZRC-00PI
- Low Profile Body: Low-profile body for a minimalist appearance.
Q: Is the Pisa range hood suitable for use over a gas or electric cooktop?
A: The Pisa range hood is suitable for use over both gas and electric cooktops. The product description states that it is "ideal for kitchens that require a more discreet, sophisticated look" and does not specify any limitations on the type of cooktop it can be used with.
Q: What is the maximum airflow capacity of the Pisa range hood?
A: The maximum airflow capacity of the Zephyr Pisa range hood is 500 cubic feet per minute (CFM). This information can be found in the product specifications section of the provided context.
Q: What is the expected lifespan of the Pisa range hood?
A: The Pisa range hood is equipped with LumiLight LED lights that have a lifespan of more than 25,000 hours. This translates to approximately 28 years if the range hood is used for 3 hours per day. However, the overall lifespan of the range hood may also depend on other factors such as usage, maintenance, and environmental conditions.
Q: What is the brand name and model number of the Pisa range hood?
A: The brand name of the Pisa range hood is Zephyr. The model number of the Pisa range hood is ZPI-E30BW.
Q: What is the recommended duct size for the Pisa range hood?
A: The recommended duct size for the Pisa range hood is 6 inches, and it can be installed either vertically or horizontally.
A: The Pisa range hood offers a maximum airflow capacity of 500 cubic feet per minute (CFM), which is higher compared to many other under-cabinet range hoods. In terms of noise level, it operates at a maximum of 5 sones, which is relatively quiet compared to other models in its class.
Q: What type of lighting does the Pisa range hood use, and how many light levels does it have?
A: The Pisa range hood uses LumiLight LED lighting, which is eco-friendly and built to last with a lifetime of more than 25,000 hours. It has two light levels.
Q: What is the noise level of the Pisa range hood at its lowest and highest operating speeds?
A: The noise level of the Pisa range hood at its lowest operating speed is 1 sone, while at its highest operating speed, it is 5 sones.
Zephyr - 30 inches - Convertible - Range Hood Insert - Stainless Steel
Color
Stainless SteelCompare similar products
$759.99
Tucked neatly out of sight within your cabinetry, Pisa is a minimal alternative to your typical under-cabinet range hood. Adorned with LumiLight LED Lighting and powered by the strength of a 500-CFM or 290-CFM blower, Pisa’s low-profile body delivers stunning design and quality performance. Its retractable visor helps with the capture of air and puts control at your fingertips. Pisa is ideal for kitchens that require a more discreet, sophisticated look.
$949.99
Enjoy the benefits this Bosch under-cabinet ventilation hood provides. Two halogen lights make it easy to see your food as it cooks, and the powerful fan clears the air of smoke, steam and odors. Removable dishwasher-safe mesh filters make it easy to maintain this Bosch under-cabinet ventilation hood, which you can install with or without ductwork.
$599.99
Quiet, discreet, and efficient, the Valina Under-Cabinet is your kitchens most clever secret weapon. This hardworking hood features a retractable stainless-steel visor that only appears when needed, and ambient LED lighting to let you focus on the tasks at hand. All in all, this hood is everything you need in one dynamic package.
$1199.99
If you’d like professional-grade punch with all the amenities, Tornado II will be your best-kept secret, with powerful blower combinations and an optional adjustable-depth liner for more flexible installations. A stylish and discreet wireless remote puts you in control while tri-level LumiLight LED Lighting illuminates the surface below. Choose the ventilation level that’s right for you along with an optional, easy-to-install stainless steel liner to complement your kitchen’s style.
| Pros for Zephyr - 30 inches - Convertible - Range Hood Insert - Stainless Steel | |||
|---|---|---|---|
| Powerful, Small space | There were no pros for this product— | There were no pros for this product— | There were no pros for this product— |
