Alpine - PWV-SB12 12" BassRev™ Powered Subwoofer Enclosure - Black/Gray

Alpine's Halo Series subwoofer enclosures make it easy to add more bass to your system. The pre-loaded R-Series 12" dual voice coil subwoofer provides plenty of bass on its own, but when you want even more, the optional linking kit can connect two together for double the impact.

Bring your music to life with the Alpine PWV-SB10, a high-performance 10" powered subwoofer built for deep, impactful bass. With a powerful built-in amplifier delivering 400W RMS (200W x 2) and a dual 4-ohm voice coil design, this subwoofer delivers strong, controlled low frequencies with impressive clarity. Engineered with a sealed enclosure and a wide frequency response of 31–200 Hz, the PWV-SB10 ensures tight, distortion-free bass that enhances any genre of music. Fine-tune your sound with a variable low-pass filter (50–200 Hz), phase selector (0°/180°), and a remote level control for on-the-fly adjustments. Whether you're upgrading a factory system or building a custom setup, the PWV-SB10 offers clean, powerful bass and flexible tuning in one sleek package—the perfect blend of Alpine quality and low-end performance. Specifications: Performance Amplifier Power Output RMS Per Channel, Ref.: 4 ohm, 14.4V: 400 W (200 W x 2) Speaker Diaphragm size nominal 10 inch (25 cm) Speaker Impedance Dual Voice Coil 4 Ohm + 4 Ohm Speaker Power Handling RMS/Peak: 200W + 200W/400W + 400W Frequency Response +0/-3dB: 31-200 Hz Enclosure Type: Sealed Control Input Impedance: >10 kOhms Input Sensitivity RCA Input Ref.: Rated Power into 4 Ohms: Hi Level: 0.5 - 10V. Lo level: 0.2 - 2.0V Phase Selector 2 position: 0°/180° Crossover Variable LPF: 50 - 200 Hz (-24 dB/oct.) Remote Level Linear Attenuation 0 to -20dB General Dimensions Width: 470mm (18 1/2") Height: 282 mm (11") Depth without grille: 126 mm (5") Depth including grille: 170 mm (6 3/4") Weight: 9.7 kg (21 lb 6.4 oz)

With an ultra-shallow enclosure design and powerful sound output, the R-Series Shallow Preloaded Subwoofer Enclosures give you the best of both worlds in size and sound. Features: Optimal sealed cabinet quality Aluminum Dust Cap Neodymium Magnet Alpine Gen2 DD Linear Magnetic Circuit CARB compliant ¾” MDF construction Premium Alpine embroidered black carpet Alpine-branded terminal cup Pre-installed steel mesh grille Includes a 12” R-Shallow Subwoofer (RS-W12D4) Rubber, modular stackable foot design What's in the Box: Sealed Cabinet with (1) 12” R-Series Shallow Subwoofer Mounting Brackets Owner’s Manual Warranty Information Online product registration information Tech Specs: Dimensions: 26.5” W x 5.25” H x 17” D 600W RMS Power Handling Frequency response: 26Hz – 200Hz Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M) Nominal Impedance: 2Ω Voice Coil: 4”(101.6mm) Designed for Tight Spaces Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow Preloaded Subwoofer Enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors. Extreme Output Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series Subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series Shallow Subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.
