Alpine - R-Series 6x9" 2-Way Hi-Resolution Coax Car Speakers with Glass Fiber Reinforced Cone (Pair) - Black
Specifications
- RMS Power100 wattsPeak Power Handling300 wattsMinimum Frequency Response40 hertzMaximum Frequency Response60 kilohertzSensitivity88 decibelsSpeaker Size6" x 9"
- Key Specs
- RMS Power: 100 watts (The maximum amount of continuous power the device is able to handle.)
- Peak Power Handling: 300 watts (The maximum amount of power an electronic device, like a speaker, can handle without damage. This refers to short bursts of power, while root mean square (RMS) power handling indicates the amount of continuous power a device can sustain. Higher levels of distortion can also occur at peak power levels when the device is powered beyond its recommended usage.)
- Minimum Frequency Response: 40 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 60 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Sensitivity: 88 decibels
- Speaker Size: 6" x 9"
- Speaker Type: 2-way, Coaxial
- Tweeter Composition: Magnesium Hard Dome
- Woofer Composition: Glass Fiber Reinforced Cone
- Woofer Surround Material: High Amplitude Multi Roll (HAMR)
- General
- Brand: Alpine
- Model Number: R2-S69
- Product Name: R-Series 6x9" 2-Way Hi-Resolution Coax Car Speakers with Glass Fiber Reinforced Cone (Pair)
- Color: Black
- Number Of Speakers: 2
- Audio
- RMS Power: 100 watts (The maximum amount of continuous power the device is able to handle.)
- Peak Power Handling: 300 watts (The maximum amount of power an electronic device, like a speaker, can handle without damage. This refers to short bursts of power, while root mean square (RMS) power handling indicates the amount of continuous power a device can sustain. Higher levels of distortion can also occur at peak power levels when the device is powered beyond its recommended usage.)
- Minimum Frequency Response: 40 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 60 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Impedance: 4 ohms (Describes the resistance of an electric signal throughout the system. Devices with low impedance require less power to deliver optimal signals but are more at risk for damage from overloading. Higher impedance requires more power but is more protected from overload damage.)
- Sensitivity: 88 decibels
- Features
- Grille Included: true
- Design
- Speaker Size: 6" x 9"
- Speaker Type: 2-way, Coaxial
- Tweeter Composition: Magnesium Hard Dome
- Woofer Composition: Glass Fiber Reinforced Cone
- Woofer Surround Material: High Amplitude Multi Roll (HAMR)
- Dimensions
- Cutout Diameter: 8.66 inches
- Mount Depth: 2.99 inches
- Product Height: 2.99 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 6 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 9 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 5.75 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: 1 year
- Other
- UPC: 793276084897
R-Series speakers are engineered to deliver prodigious power while maintaining extreme sound clarity for a totally exciting sound. They provide high power output and handling, wide frequency response, and powerful bass. The R-Series line includes component and coaxial speakers, subwoofers and for the first time, amplifiers.
- 6x9” 2-way coaxial speaker: The R2-S69 is the 6x9” 2-Way Coax model of the new 3rd generation R-Series speaker line-up. It features a 6x9" door woofer as well as an integrated tweeter with up to 40kHz frequency response.
- Hi-res audio certified hard dome tweeter: The all-new magnesium hard-dome tweeters deliver clear, detailed music reproduction and play up to 40kHz (Hi-Res Audio). You have the option to flush-mount them in their threaded housing or use the included on-dash mounts.
- Composite basket and large magnets: The standard models feature composite baskets (in comparison to the Aluminum die-cast baskets of the PRO models) – which makes them more affordable. They fit larger magnets than in previous generations (while maintaining the same mounting depth).
- Glass-fiber reinforced cone: The door woofer and the mid-range speaker feature all-new glass-fiber reinforced cones. This material is very stiff and extremely light-weight, resulting in a super-fast response and highly accurate music reproduction.
- Easy-fit tweeter in OEM locations: You can simply remove the installation frame and the trim ring of the R-Series tweeter to minimize its overall size and diameter. The tweeter itself is then small enough to fit it in many OEM tweeter locations for a stealthy installation.
- High-pass X-over network: This small X-Over networks are very easy to install – in may cases you can keep the original wiring in the vehicle’s doors by simply putting this network in, saving lots of time during installation. You can adjust the tweeter level by -3dB / 0dB / +3dB.
- HAMR surround: Alpine’s HAMR Surround (High-Amplitude Multi-Roll) allows for a maximum cone excursion, while maintaining excellent control. This results in strong bass at high volumes without distortion.
- New speaker grills: The new speakers grills in hexagon design look very aggressive and do not increase the overall speaker installation diameter.
Whats Included
- 6x9" Mid-Bass Speakers w/1" Coaxial Tweeters (x2)
- Grilles (x2)
- Mounting Hardware
- Warranty/registration card
- Owners Manual & Installation Guide
Product Manuals
Q: What is the frequency response range of the speakers?
A: The minimum frequency response is 40 hertz and the maximum frequency response is 60 kilohertz.
Q: What is the mounting depth of the speakers?
A: The mount depth of the speakers is 2.99 inches.
Q: Is the warranty the same for parts and labor?
A: The parts and labor are covered under the warranty for the same length of time.
Q: What is the power handling of the speakers?
A: The peak power handling of the speakers is 300 watts.
Q: What material is the woofer cone made of?
A: The woofer cone is made of glass fiber reinforced cone.
Q: Do the speakers come with a grille?
A: The speakers do include a grille.
