Alpine - S-Series Class D Bridgeable Multichannel Amplifier with Variable Crossovers - Black
More Buying Options
Related Item
Specifications
- Continuous Watts x Channel @ Ohms60W x4 @ 4 ohmsMaximum Watts x Channel @ Ohms90 watts RMS x4 @ 2 ohmsAmplifier ClassDNumber Of Channels4Bass BoostVariableBridgeableYes
- Key Specs
- Continuous Watts x Channel @ Ohms: 60W x4 @ 4 ohms
- Maximum Watts x Channel @ Ohms: 90 watts RMS x4 @ 2 ohms (This is the maximum load the speaker, subwoofer or amp can drive.)
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Number Of Channels: 4
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Bridgeable: true (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Low-Pass Crossover: Variable (Devices with this function allow only audio frequencies below a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- High-Pass Crossover: Variable (Devices with this function allow only audio frequencies above a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- Speaker-Level Inputs: true (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- General
- Brand: Alpine
- Model Number: S2-A36F
- Product Name: S-Series Class D Bridgeable Multichannel Amplifier with Variable Crossovers
- Color: Black
- Audio Power
- Continuous Watts x Channel @ Ohms: 60W x4 @ 4 ohms
- Total Power Handling RMS: 60 watts
- Watts Per Channel RMS: 60 watts
- Maximum Watts x Channel @ Ohms: 90 watts RMS x4 @ 2 ohms (This is the maximum load the speaker, subwoofer or amp can drive.)
- Total Power Handling Maximum: 320 watts
- Watts Per Channel Maximum: 90 watts
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Audio
- Number Of Channels: 4
- Minimum Frequency Response: 10 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 40 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Signal-to-Noise Ratio (SNR): 83 decibels (The ratio of the desired signal's strength to the level of background noise. A ratio higher than 1:1, which equates to greater than 0 decibels, indicates more signal than noise.)
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Features
- Bridgeable: true (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Low-Pass Crossover: Variable (Devices with this function allow only audio frequencies below a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- High-Pass Crossover: Variable (Devices with this function allow only audio frequencies above a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- Remote Control Included: No
- Input
- Speaker-Level Inputs: true (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- Output
- Preamp Outputs: false
- Dimensions
- Product Height: 2.25 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 8.7 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 8.25 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 4.8125 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1 year
- Warranty - Labor: 1 year
- Other
- UPC: 793276085177
Pump up the audio in your ride with this Alpine Next Generation S-Series four-channel car amplifier. Delivering 60W per channel, or 180W to a subwoofer and 60W to two channels, this amplifier is extremely versatile. The compact size provides mounting versatility. This Alpine S-Series four-channel car amplifier automatically reduces output when it senses overheating risks.
- Robust power output: 60 watts RMS x 4 at 4 ohms, 90 watts RMS x 4 at 2 ohms
- Variable high- and low-pass filters: Ensure flexible operation to get just the right bass tone
- 4 ohms impedance: Conducts power evenly to keep the speaker at an appropriate level.
- Preamp- and speaker-level inputs: Allows installation in almost any vehicle, even one with a factory radio
- New mid-bass EQ circuit: Dial in to the mid-bass impact as desired for a more dynamic audio experience (0-12 dB at 100 Hz on channel 3/4)
- Class D circuitry: Ensures reliable power handling and it is small enough to fit in almost any location
- Hi-res capable: Frequency response: 20-40k Hz
- Flexible application: Selectable remote turn-on circuit, a three-position switch that ensures the amplifier turns on and off at the proper times
- Easy control access: Sound controls are now located on the side panes for easier acccess to gain and crossover controls
- New mid-bass EQ circuit: Dial in to the mid-bass impact as desired for a more dynamic audio experience
- Optional remote: RUX-KNOB.2 or RUX-H01 wired remote available for rear channels
- Robust power output: 60 watts RMS x 4 at 4 ohms, 90 watts RMS x 4 at 2 ohms
- Variable high- and low-pass filters: Ensure flexible operation to get just the right bass tone
- 4 ohms impedance: Conducts power evenly to keep the speaker at an appropriate level.
- Preamp- and speaker-level inputs: Allows installation in almost any vehicle, even one with a factory radio
- New mid-bass EQ circuit: Dial in to the mid-bass impact as desired for a more dynamic audio experience (0-12 dB at 100 Hz on channel 3/4)
- Class D circuitry: Ensures reliable power handling and it is small enough to fit in almost any location
- Hi-res capable: Frequency response: 20-40k Hz
- Flexible application: Selectable remote turn-on circuit, a three-position switch that ensures the amplifier turns on and off at the proper times
- Easy control access: Sound controls are now located on the side panes for easier acccess to gain and crossover controls
- New mid-bass EQ circuit: Dial in to the mid-bass impact as desired for a more dynamic audio experience
- Optional remote: RUX-KNOB.2 or RUX-H01 wired remote available for rear channels
Whats Included
- Alpine S2-A36F 4-channel amplifier
- Owners manual, “Birth Sheet” that certifies the actual power of the amplifier, Alpine Registration Card, Warranty sheet, Installation guide
- (x4) Screws for amplifier mounting to the vehicle, (x3) Allen wrench for amplifier connection and installation (2mm, 2.5mm, 3mm)
- Alpine S2-A36F 4-channel amplifier
- Owners manual, “Birth Sheet” that certifies the actual power of the amplifier, Alpine Registration Card, Warranty sheet, Installation guide
- (x4) Screws for amplifier mounting to the vehicle, (x3) Allen wrench for amplifier connection and installation (2mm, 2.5mm, 3mm)
Product Manuals
Q: What kind of circuitry does this Alpine amplifier use?
A: This amplifier utilizes Class D circuitry for efficient and reliable power handling.
Q: How does this amplifier handle potential overheating?
A: This Alpine amplifier is designed to automatically reduce output if it senses overheating risks, ensuring safe and reliable operation.
Q: Can I use this amplifier with my factory radio?
A: Yes, you can install this amplifier in a vehicle with a factory radio because it has preamp- and speaker-level inputs.
Q: Does this amplifier have a variable low-pass crossover?
A: Yes, the amplifier features a variable low-pass crossover for customized audio tuning.
Q: What is the RMS power output of this Alpine amplifier?
A: This Alpine amplifier has a robust power output of 60 watts RMS x 4 at 4 ohms.
Q: Is there an optional remote control available for this amplifier?
A: Yes, you can purchase the RUX-KNOB.2 or RUX-H01 wired remote separately for controlling the rear channels.
