ARC Audio - X2 1100.1 Mono-Block Amplifier (Single Channel) - Black/Gray

Arc Audio X2 600.4 Multi-Channel Amplifier (Four-Channels) Multi-Channel Amplifier (Four-Channels) Microprocessor-Controlled Class-D Design Designed And Engineered By Robert Zeff High-Frequency Power Supply Design For Improved Signal Transparency And Overall Sound Quality Remote Bass Boost Control (Included) Extruded Aluminum CNC Chassis Design (Level 2 X2 Cosmetics) Start-Stop Vehicle Compatible Signal Sense and DC Detect Single Side Connection Design Nickel Plated RCA Terminals Quick Disconnect Speaker Terminal Plugs Audiophile Class-D Output Filter Networks Detailed Microprocessor Controlled Protection Large, High-Frequency Switching Power Supplies RCA Inputs Are Compatible With Speaker-Level Inputs Fault Codes Storage Of The Last Protection Code Detected Hi Signal To Noise Ratio Without Compromising Power Output Fully Balanced Input Stage Significantly Increases Flexibility Ultra Low ESR, High-Capacity Power Supply Storage Capacitors Flexible Mounting Orientation For Vertical Or Horizontal Installations Next Generation High Speed Class-D Technology Powering All X2 Amplifiers Bridged Mode Auto Detect Turn-On Works With Most Chip Based OEM Headunits Precision Filtering Isolates The Power Supply Reducing Unwanted Interference In Radio Reception Quick Disconnect Type Terminal Connections Specifications - 4- Channels @ 4 Ohms - 150 Watts 4-Channels @ 2 Ohms - 150 Watts 2-Channel @ 4 Ohms (Bridged) - 300 Watts 2-Channel @ 2-Ohms (Bridge) - Not Recommended Frequency Response - 20Hz - 20kHz Crossover Range - 50Hz - 550Hz Crossover Types - HP/LP on all channels Bandpass Crossovers - Yes Ch 3/4 Only Remote Level Control - Yes Remote Level Control Included - Yes - LP Front Channel only Input Sensitivity (Low) - 200mV - 3.5V Fuse - 2 x 30 Amp Dimensions - 9.020"(L) x 6.268"(W) x 2.162"(H)

The link1500.1plus is the result of extensive engineering and development. The goal was an amplifier with the same power output at either 2 or 1 ohm. This amp makes 1500 watts RMS @ 2 or 1 ohm. This is achieved with our new dual rail voltage power supply. When setting up the amp, simply select the impedance of your subwoofer with the 4/2 or 1 ohm switch and the amp does the rest. At 13.11”x6.5”x1.65”, it is incredible small for a 1500 watt RMS amp. The link1500.1plus features our bassFREQ preamp, with a 24dB per octave crossover, an adjustable parametric EQ and a 24dB per octave subsonic filter. Like all Wāvtech amplifiers, the speaker level inputs of the link1500.1plus can handle up to 40V and have our adaptive loading technology. The optional linkRC remote allows for control of the subwoofer system from the vehicles front seat. The link1500.1plus is also compatible with OEM start/stop systems. link1500.1plus Features 1500 Watt Mono Amplifier 900 watts x 1 @ 4 ohms 1500 watts x 1 @ 2 ohms 1500 watts x 1 @ 1 ohm Only 13.11”x6.5”x1.65” Dual Rail Voltage Power Supply Fully Adjustable Parametric EQ Variable Low-Pass Crossover (-24dB/oct) Variable Subsonic Filter (-24dB/oct) Remote Level Control (RLC) w/Optional linkRC bassFREQ Bass Processor w/Parametic EQ Active Thermal Management Start/Stop System Compatible Adaptive OEM Load Technology 40V Input Capability Differential Balanced Inputs Variable Gain Adjustment w/Clip LED Auto Turn-On via DC-Offset or Audio Signal Detect Locking Detachable Hi-Level Speaker Terminals 0 Gauge Power/Ground Terminals Professional Grade Panel Mount RCA’s Compact Aluminum Chassis w/Detachable Mounting tabs link1500.1plus Specifications Input Sensitivity: SPK: 1-20Vrms, 2-40Vrms, RCA: 0.2V-5Vrms, 0.4V-10Vrms Max Input Voltage (SPK): 40Vrms Frequency Response: 500Hz (=0/-3dB) THD+N: 77dBA (1W, 4Ω)

The Alpine “R-Series” line of speakers, subwoofers and amplifiers have a heritage of sound quality you can hear from a block away, and the newly added R-Series amplifiers are no exception. Aside from their best-in-class performance, these amplifiers are tuned to emphasize the characteristics of the R-Series speakers and subwoofers, giving you that legendary R-Series experience. They have a 15% reduced footprint compared to the previous models and are easier to install. FEATURES Install Terminal Layout: One side Small footprint for easy installation Screw terminals (for speaker and power cables) General Class-D Amplification (Digital) Channel Design: Mono Channel Top panel controls Thermal Management Control Top Mounted LED Power/Status Indicator Speaker Level Input with remote turn on Crossover: Adjustable Low-pass (LPF) and Variable Subsonic filter Adjustable Gain Control Bass EQ Remote Bass Control (RUX-KNOB2) Ready SPECIFICATIONS Max Power Output Ratings Total Max Power: 2300W RMS Power Ratings Per Channel into 1 Ohms, 14.4V (≤1%THD+N): 1 x 1500W Per Channel into 2 Ohms, 14.4V (≤1%THD+N): 1 x 1200W Per Channel into 4 Ohms, 14.4V (≤1%THD+N): 1 x 700W Sound Tuning Crossover: Variable LPF: 50-400Hz (-24dB/oct) Crossover: Variable Subsonic: 8Hz-40Hz (-24dB/oct) General Power Requirements: 14.4 V.DC (9 - 16 V allowable) Input Sensitivity (RCA Input): Hi: 0.4V - 10V / Low: 0.1V - 4.0V High Level Input with automatic power on Cable size: Power Cable AWG 4, SPK Cable AWG 8 Frequency Response: 10Hz – 400Hz THD+N (@ 10W into 4 Ohms): 250 Weight: 5kg Dimensions Heat Sink (WxHxD) mm: 341 x 65 x 185
