ASUS - ROG Strix NVIDIA GeForce RTX 5070 OC Edition 12GB GDDR7 PCI Express 5.0 Graphics Card - Black
ASUS - ROG Strix NVIDIA GeForce RTX 5070 OC Edition 12GB GDDR7 PCI Express 5.0 Graphics Card - Black
Related Item
Specifications
- GPU Base Clock Frequency2.655 gigahertzGPU Boost Clock Frequency2.685 gigahertzDisplayPort Ports3 x DisplayPort 2.1HDMI Ports2 x HDMI 2.1Maximum Resolution8K (4320p)Maximum Number of Displays Supported4
- Key Specs
- GPU Base Clock Frequency: 2.655 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.685 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 2 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- GPU Video Memory (RAM): 12 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- Slot Size: 3.25-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 5.0
- Product Height: 64 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 147.3 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 332 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5070 (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- General
- Brand: ASUS
- Model Number: ROG-STRIX-RTX5070-O12G-GAMING
- Product Name: ROG Strix NVIDIA GeForce RTX 5070 OC Edition 12GB GDDR7 PCI Express 5.0 Graphics Card
- Color: Black
- GPU Chipset Manufacturer: NVIDIA
- Graphics Processing Unit (GPU): NVIDIA GeForce RTX 5070 (Often referred to as a graphics card, a graphics processing unit (GPU) is the electronic circuitry responsible for manipulating and processing computer graphics/images and accelerating video decoding. Ultimately, a powerful GPU will provide a boost for anything involving visuals, including games, graphic design, and video editing.)
- Year of Release: 2025
- Performance
- GPU Base Clock Frequency: 2.655 gigahertz (The minimum rate at which the graphics controller is guaranteed to operate.)
- GPU Boost Clock Frequency: 2.685 gigahertz (The maximum ideal rate at which the graphics controller is able to operate, typically only for a short period of time.)
- Cooling System: Fan (A computer's CPU generates heat while operating and requires a cooling system to keep internal components functioning properly. Air cooling uses fans to draw in cool air and exhaust hot air, while liquid cooling uses coolant-filled tubes and water blocks to regulate internal temperature more efficiently.)
- Connectivity
- DisplayPort Ports: 3 x DisplayPort 2.1 (The number and type of DisplayPort outputs the product has.)
- HDMI Ports: 2 x HDMI 2.1 (The number and type of HDMI outputs the product has.)
- Power Connector: 1 x 12-pin (The configuration of the connector as it connects the motherboard to a power supply unit.)
- Display
- Maximum Resolution: 8K (4320p) (The highest display resolution that the graphics card(s) can support.)
- Maximum Number of Displays Supported: 4
- Advanced Graphics Rendering Technique(s): DLSS 4 (Deep Learning Super Sampling), Ray tracing (Imaging technology designed to improve graphics rendering.)
- Memory
- GPU Video Memory (RAM): 12 gigabytes (Random-access memory (RAM) is a GPU’s, or graphics cards, short-term data storage, which allows active information to be accessed quickly. The size and type of RAM determines how efficiently the GPU can handle large amounts of information at one time. For example, larger amounts of RAM for gaming or video editing increases performance.)
- GPU Video Memory Type (RAM): GDDR7 (Each type of RAM delivers a different level of speed, bandwidth, energy efficiency and performance.)
- GPU Video Memory Base Clock Frequency (RAM): 14 gigahertz
- Compatibility
- Slot Size: 3.25-slot (A graphics card only requires one PCIe/PCI slot for connection to the motherboard but, depending on size, may block other slots. The slot size listed by the manufacturer is therefore not an exact measurement of the card's size but an indication of how much clearance will be available after it is installed.)
- PCI Express Version: PCI Express 5.0
- Operating System Compatibility: Windows
- Power
- Total Graphics Power: 250 watts
- Recommended Power Supply: 750 watts
- Dimensions
- Product Height: 64 millimeters (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 147.3 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Length: 332 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Weight: 3.51 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 3 years
- Other
- UPC: 197105970342
The premium performance ASUS ROG Strix GeForce RTX 5070, featuring advanced cooling system with axial-tech fan, phase-change GPU thermal pad and MaxContact design, lowering GPU temperature to reach higher performance. Aura sync provides endless possibilities for personalization with color or functional effects.
- AI Performance: 1044 AI TOPS.
- OC Edition: 2685 MHz OC mode, 2655 MHz default mode.
- 3.2-Slot Design: Massive fin array optimized for airflow from the three Axial-tech fans.
- Axial-Tech Fans: Have been scaled up to propel more air through the card to reach higher performance.
- 0dB Technology: Lets you enjoy light gaming in relative silence.
- MaxContact Design With Vapor Chamber: Ensures efficient heat transfer, providing a premium performance.
- Phase-Change GPU Thermal Pad: Helps ensure optimal heat transfer, lowering GPU temperatures for enhanced performance and reliability.
- Premium Power Delivery: With digital power control and 15K caps ensure high performance.
- Protective PCB Coating: Envelops the circuit board to help protect against short-circuits caused by moisture, dust, or debris.
- Aura Sync: Features Aura-compatible ARGB lighting on the shroud and perimeter allows endless personalization.
- GPU Tweak III: Software provides intuitive performance tweaking, advanced thermal control, and system monitoring.
Compare similar products
The premium performance ASUS ROG Strix GeForce RTX 5070, featuring advanced cooling system with axial-tech fan, phase-change GPU thermal pad and MaxContact design, lowering GPU temperature to reach higher performance. Aura sync provides endless possibilities for personalization with color or functional effects.
Fearless and bold, GeForce RTX 5070 Ti 16G GAMING TRIO OC delivers strong performance to both gaming and content creation. It blends a fierce look with advanced cooling technologies, making it an unwavering ally on the gaming battlefield. GeForce RTX 5070 Ti 16G GAMING TRIO OC is the ideal choice for gamers who strive to give their all.
The ASUS ROG Astral GeForce RTX 5080 introduces ROG's first quad-fan graphics card, coupled with a patented vapor chamber, increased heatsink fin density, a phase-change GPU thermal pad, towering default clock speeds, boosted power delivery, and more. These premium innovations – amplified by an eye-catching die-cast frame and metal GPU bracket – combine to deliver absolute performance that can handle even the most demanding gaming scenarios.
MSI GeForce RTX 5070 12G GAMING TRIO OC: Bold and powerful, GAMING TRIO delivers top-tier performance for gaming and content creation. With advanced cooling and a fierce design, it's the ultimate ally for gamers who give their all.
| Pros for ASUS - ROG Strix NVIDIA GeForce RTX 5070 OC Edition 12GB GDDR7 PCI Express 5.0 Graphics Card - Black | |||
|---|---|---|---|
| Graphics Performance | Noise Level, Overall Performance, Heat Dissipation, Design, Installation Ease | Graphics Performance, Cooling System, Noise Level, Build Quality, Appearance | Cooling System, Noise Level, Build Quality, Performance, Aesthetics |
| Cons for ASUS - ROG Strix NVIDIA GeForce RTX 5070 OC Edition 12GB GDDR7 PCI Express 5.0 Graphics Card - Black | |||
| There were no cons for this product— | Size | Size, Weight | Size, VRAM |
Specs
Reviews
Customer Images
The vast majority of our reviews come from verified purchases. Reviews from customers may include My Best Buy members, employees, and Tech Insider Network members (as tagged). Select reviewers may receive discounted products, promotional considerations or entries into drawings for honest, helpful reviews.
- Rated 5 out of 5 stars
3060 and 5070 comparison
Went from a 3060 to a 5070 and it was worth it every thing look better
AngelO Posted
- Rated 5 out of 5 stars
Ricka655
Very large and Heavy needs support that comes with it Very fast and excellent color and graphic
Ricka655 Posted
- Rated 5 out of 5 stars
Don’t believe the critics
This GPU has worked flawlessly since ive had out the box and it works beautiful. High performance and speed plus AI powerd works great! I upgraded from the MSI Suprim X 3080 and I can definitely see a huge difference. Yeah 12GB might not be the best choise for future proof graphics card but overall the speed it has and performance youre getting out if it will make you look otherwise. I run my games on high end settings and I have yet to have an issue with it. Also I’m using intel I7 14700k plus an asus maximus hero MB z790. If youre in the market in looking for a good looking GPU with great performance and well also trying to be budget friendly I would look no further but definitely try giving this one a try. Cooling is great and keeps quiet.
Victor Posted
