Boss - Elite BE830.5D 830W RMS 5 Channel Class D Full Range Amplifier with LED Illuminated End Panels - Black/Gray
Specifications
- Amplifier ClassDNumber Of Channels5Bass BoostVariable
- Key Specs
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Number Of Channels: 5
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- General
- Brand: Boss
- Model Number: BE830.5D
- Product Name: Boss Elite BE830.5D 830W RMS 5 Channel Class D Full Range Amplifier with LED Illuminated End Panels
- Color: Black/Gray
- Audio Power
- Total Power Handling RMS: 830 watts
- Total Power Handling Maximum: 1660 watts
- Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Audio
- Number Of Channels: 5
- Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Features
- Bluetooth Enabled: false (The device is capable of communicating with another device via Bluetooth, provided they are within the required range of each other. A Bluetooth-enabled device must also be the same Bluetooth version or higher than the accessory it is intended to pair with.)
- Marine: false
- Dimensions
- Product Height: 18.000 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 8.000 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 14.000 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 10.0 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 1-Year Manufacturer Warranty
- Warranty - Labor: None
- Other
- UPC: 791489134361
• Full Range 5 Channel Class D Amplifier • High Pass and Low Pass Filters • Bass Boost • RCA & Speaker Level Inputs • Bridgeable • PWM MOSFET Power Supply • Remote Subwoofer Control • LED Illuminated End Panels • Thermal, Short and Overload Protection Circuits • Full Range 5-Channel Class D Amplifier • High Pass and Low Pass Filters 50Hz-250Hz • Bass Boost 0dB- +12dB • Bridgeable • PWM MOSFET Power Supply • Remote Subwoofer Level Control • Thermal, Short and Overload Protection Circuits • RCA or Speaker Level Inputs • Low Level Input Voltage 400mV-4V • High Level Input Voltage 4V-40V • 60W RMS X 4 CH @ 4Ω • 95W RMS X 4 CH @ 2Ω • 190W RMS x 2 CH @ 4Ω Bridged • 250W RMS x CH5 @ 4Ω • 450W RMS x CH5 @ 2Ω Product Specs Key Features General Specs Amp Topology: Full Range, Class D Power Supply Type: MOSFET Power Supply Performance Specs Total Power Output: 2200 Watts Peak Power @ 2 Ω: 300 Watts Peak Power @ 4 Ω: 150 Watts Bridged Power @ 4 Ω: 600 Watts RMS Power @ 2 Ω: 225 Watts RMS Power @ 4 Ω: 113 Watts Bridged RMS Power @ 4 Ω: 450 Watts Speaker Impedance: 2 to 8 Ω T.H.D. (Total Harmonic Distortion): 0.01 % Channel Separation ≥: 90 dB Frequency Response: 9 Hz to 50 kHz ±1 dB Connections, Controls, and Processing RCA Inputs: 6 Channel High Level Inputs: YES Low Pass Filter: 50Hz-250Hz High-Pass Filter: 50Hz-250Hz Subwoofer Level Control: YES Input Sensitivity Switch: YES Thermal/Overload/Short Protection: ES Extra Features: External fuse and fuse holder not included. Measurement Length: 4.57" Width: 11.34"
- Key Feature: Full Range 5 Channel Class D Amplifier
- Key Feature: High Pass and Low Pass Filters
- Key Feature: RCA & Speaker Level Inputs
- Key Feature: PWM MOSFET Power Supply
- Key Feature: Remote Subwoofer Control
- Key Feature: Full Range 5 Channel Class D Amplifier
- Key Feature: High Pass and Low Pass Filters
- Key Feature: RCA & Speaker Level Inputs
- Key Feature: PWM MOSFET Power Supply
- Key Feature: Remote Subwoofer Control
- Key Feature: Full Range 5 Channel Class D Amplifier
- Key Feature: High Pass and Low Pass Filters
- Key Feature: RCA & Speaker Level Inputs
- Key Feature: PWM MOSFET Power Supply
- Key Feature: Remote Subwoofer Control
Whats Included
- Boss Elite BE830.5D 830W RMS 5 Channel Class D Full Range Amplifier with LED Illuminated End Panels
- Boss Elite BE830.5D 830W RMS 5 Channel Class D Full Range Amplifier with LED Illuminated End Panels
- Boss Elite BE830.5D 830W RMS 5 Channel Class D Full Range Amplifier with LED Illuminated End Panels
Compare similar products
• Full Range 5 Channel Class D Amplifier • High Pass and Low Pass Filters • Bass Boost • RCA & Speaker Level Inputs • Bridgeable • PWM MOSFET Power Supply • Remote Subwoofer Control • LED Illuminated End Panels • Thermal, Short and Overload Protection Circuits • Full Range 5-Channel Class D Amplifier • High Pass and Low Pass Filters 50Hz-250Hz • Bass Boost 0dB- +12dB • Bridgeable • PWM MOSFET Power Supply • Remote Subwoofer Level Control • Thermal, Short and Overload Protection Circuits • RCA or Speaker Level Inputs • Low Level Input Voltage 400mV-4V • High Level Input Voltage 4V-40V • 60W RMS X 4 CH @ 4Ω • 95W RMS X 4 CH @ 2Ω • 190W RMS x 2 CH @ 4Ω Bridged • 250W RMS x CH5 @ 4Ω • 450W RMS x CH5 @ 2Ω Product Specs Key Features General Specs Amp Topology: Full Range, Class D Power Supply Type: MOSFET Power Supply Performance Specs Total Power Output: 2200 Watts Peak Power @ 2 Ω: 300 Watts Peak Power @ 4 Ω: 150 Watts Bridged Power @ 4 Ω: 600 Watts RMS Power @ 2 Ω: 225 Watts RMS Power @ 4 Ω: 113 Watts Bridged RMS Power @ 4 Ω: 450 Watts Speaker Impedance: 2 to 8 Ω T.H.D. (Total Harmonic Distortion): 0.01 % Channel Separation ≥: 90 dB Frequency Response: 9 Hz to 50 kHz ±1 dB Connections, Controls, and Processing RCA Inputs: 6 Channel High Level Inputs: YES Low Pass Filter: 50Hz-250Hz High-Pass Filter: 50Hz-250Hz Subwoofer Level Control: YES Input Sensitivity Switch: YES Thermal/Overload/Short Protection: ES Extra Features: External fuse and fuse holder not included. Measurement Length: 4.57" Width: 11.34"
The KENWOOD KAC-835 is a 1600 watts high-performance 5-Channel Amplifier designed to deliver powerful, clear, and dynamic sound. Engineered for audio enthusiasts who seek both precision and versatility in their car audio systems. The KAC-835 provides the perfect blend of power, flexibility, and ease of installation. The 5-channel design allows the KAC-835 to power both front and rear speakers as well as a dedicated subwoofer channel, offering a complete audio solution in a single unit. Despite its powerful performance, the KENWOOD KAC-835 is designed to be compact and easy to install. The KAC-835 amplifier fits into tight spaces, making it ideal for vehicles where space is at a premium. The KENWOOD KAC-835 is equipped with both high-pass and low-pass filters. The high-pass filter is adjustable and allows users to set the crossover frequency for the full-range speakers, ensuring that only the appropriate frequencies are sent to the speakers, preventing distortion, and maximizing clarity. The low-pass filter, dedicated to the subwoofer channel, ensures that the subwoofer receives only the low-end frequencies, delivering tight, punchy bass. For those who crave deep, powerful bass, the KAC-835 features a variable bass boost function that allows you to adjust the low-frequency output to your preference.
Bring the sound inside your car to a higher level with the Kenwood KAC-334 Class D bridgeable multichannel amplifier, capable of 600 watts maximum power for crystal-clear and powerful sound, enhancing your drive. Its compact design allows versatile installation, and variable crossovers let you fine-tune your audio settings for optimal sound quality. The amplifier's Class D efficiency means plentiful power output without generating a lot of heat. It powers your speakers or subwoofer for dynamic and distortion-free performance.
Pump up the audio in your ride with this Alpine Next Generation S-Series five-channel car amplifier. Delivering 40W per channel plus 300W to a subwoofer, this amplifier is extremely versatile. The compact size provides mounting versatility. A variable bass boost on the sub channel allows you to dial in some extra kick and impact to your system's low-frequency sound.
