Cerwin Vega - XED3001D XED Series 1-Channel Monoblock Class-D Amplifier - Black

Model: XED3001D
SKU: 12157308

Not yet reviewed

$103.99
or
Availability
FREE shipping to
Sold & shipped by
Creative Car Audio Inc
(10)

More Buying Options

New
$103.99 - $129.99
Specifications
  • Amplifier Class
    D
    Number Of Channels
    1
    Bass Boost
    Variable
  • Key Specs
    • Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
    • Number Of Channels: 1
    • Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
  • General
    • Brand: Cerwin Vega
    • Model Number: XED3001D
    • Product Name: Cerwin Vega - XED3001D XED Series 1-Channel Monoblock Class-D Amplifier
    • Color: Black
  • Audio Power
    • Total Power Handling RMS: 300 watts
    • Total Power Handling Maximum: 600 watts
    • Amplifier Class: D (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
  • Audio
    • Number Of Channels: 1
    • Bass Boost: Variable (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
  • Features
    • Bluetooth Enabled: false (The device is capable of communicating with another device via Bluetooth, provided they are within the required range of each other. A Bluetooth-enabled device must also be the same Bluetooth version or higher than the accessory it is intended to pair with.)
    • Marine: false
  • Dimensions
    • Product Height: 1.8 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
    • Product Width: 4.7 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
    • Product Depth: 6.3 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
    • Product Weight: 0.01 pounds (The out of box weight of the item.)
  • Warranty
    • Warranty - Parts: 1 year
    • Warranty - Labor: 1 year
  • Other
    • UPC: 847169054068

Cerwin-Vega XED Series Amplifiers – Xtreme Energy, UnleashedThe Cerwin-Vega XED Series Amplifiers are your ticket to high-performance car audio with power, precision, and reliability. Designed with Xtreme Energy Design, these amplifiers are engineered to take your sound system to the next level,delivering exceptional power and efficiency for every beat.The XED Series Amplifiers are built for those who crave deep bass, crisp highs, and seamless mids. With their cutting-edge technology and meticulous craftsmanship, they deliver the power and clarity needed to make every drive an immersive audio experience.Unleash the full potential of your car audio system with Cerwin-Vega XED Series Amplifiers—where Xtreme Energy meets extreme performance.

  • Precision Engineering for Superior Performance: Class D Amplifier Technology: High-efficiency design ensures massive power output with minimal heat generation. Lightweight Aluminum Chassis: Enhances heat dissipation while reducing weight for efficient, long-lasting performance.
  • Why Choose the XED Series?: Unrivaled Efficiency: Advanced Class D technology provides unmatched power-to-heat performance. Durable & Lightweight: Aluminum construction ensures cool operation and lasting reliability. High-Energy Output: Perfect for audiophiles seeking powerful and dynamic sound reproduction.
  • Power Rating (RMS): 300W x 1 @ 2Ω 200W x 1 @ 4Ω Power Supply Power Supply: Full WPM Power Supply Threshold: 10.0V-16.0V (DC) Idle Current: (0.7A) Distortion THD 4 (100HZ @4Ω): 0.1% S/N RATIO (A WEIGHTED @1W): -85dBA S/N RATIO (A WEIGHTED @FP): -101.1dBA
  • Input Sensitivity: Low Level Input: 250mV-6.0V High Level Input: 1.1V~>20.0V Input Impedance Low Level Input: 20KΩ High Level Input: 100KΩ Output Stage Output Impedance: 2Ω Damping Factor (50Hz@4Ω): >70 Bandwidth (-3db): 10Hz-250Hz
  • Crossover (1-12dB/Oct): Variable High-Pass: Variable low-Pass: 35Hz-250Hz Fuse Rating ATC: 20A x 2 (Inside) Dimensions Length x Width x Height: 6.3”x4.7”x1.8” (160mm x 120mm x 46.5mm) FEATURES Bass Boost: 0dB-12dB LED Power/Protect Light Indicator Bass Control Included
Whats Included
  • amp
