Eaton - 20 amps Arc Fault/Ground Fault Single Pole Circuit Breaker

QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 20A at 120VAC. This unit provides 10kA breaking capacity and is plug in mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a dual function feature with pigtail. This provides combination arc fault and ground fault protection. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555. This product is in clam packaging.

Square D by Schneider Electric homeline 20 amp 1-pole plug-on neutral dual function circuit breaker is a space and labor saving device, engineered to meet prevailing national electric code requirements. This device combines two critical technologies; combination arc fault protection and ground fault protection (class a), in a single, easy-to-install device. The national electric code now requires both combination arc fault and ground fault protection on all 1-pole, 15 amp and 20 amp kitchen and laundry circuits. Prior to the release of this new device, a contractor or homeowner's only choice would have been to use a combination arc fault circuit breaker in conjunction with an expensive, bulky ground fault receptacle. The new dual function circuit breakers help reduce cost and eliminate the hassle of using two separate devices to provide this essential protection. It's a win for contractors and homeowners alike. Designed for reliability, the homeline plug-on neutral dual function circuit breaker connects directly to the neutral bar, providing a time and labor-saving installation. Several advantages from the plug-on neutral design are fewer connections which lead to faster installation and an innovative neutral clip eliminates pigtails which in turn frees gutter space. Like all square d cafi circuit breakers, it is integrated with time saver diagnostics, a unique feature that provides additional circuit information and minimizes troubleshooting at the touch of a button.Manufacturer Contact InformationSANDY, UT, 84070 US

Plug In Circuit Breaker, Amps 20, Number of Poles 1, Circuit Breaker Type Combination Arc Fault Circuit Interrupter, AC Voltage Rating 120VAC, DC Voltage Rating Not Rated, For Use With QO Load Centers, Series QO, Terminal Connection Screw Clamp, Min. Wire Size 14 AWG, Max. Wire Size 8 AWG, Length 4.75 In., Width 0.75 In., Depth 2.98 In., Standards UL Listed, CSA Certified, NEC, Max. AIR Rating 10kA 'Manufacturer Contact InformationHAUPPAUGE, NY, 11788 US
