GIGABYTE - B850M EAGLE WIFI6E (Socket AM5) AMD B850 Micro-ATX DDR5 Wi-Fi 6E Motherboard - Black
Intel - Core i7-14700 14th Gen 20-Core 28-Thread (5.4GHz Turbo) Socket LGA1700 Unlocked Desktop Processor - Multi$418.91
More Buying Options
Related Item
Specifications
- ChipsetAMD B850Form FactormicroATXProcessor SocketSocket AM5 (LGA 1718)Wireless Networking StandardWi-Fi 6ENumber Of Memory Slots4Maximum Memory Supported128 gigabytes
- Key Specs
- Chipset: AMD B850
- Form Factor: microATX (The size, arrangement, and physical configuration of the product.)
- Processor Socket: Socket AM5 (LGA 1718) (Type of pin configuration that connects a CPU to a computer’s motherboard.)
- Wireless Networking Standard: Wi-Fi 6E (The wireless networking standard used by the device. Each iteration of the standard developed by the Wi-Fi Alliance corresponds to an existing IEEE 802.11 protocol; for example, standard 802.11ac (or AC) is termed Wi-Fi 5. Refers specifically to the standard the device is designed to use, but ultimately determines product interoperability and backward compatibility including previous versions.)
- Number Of Memory Slots: 4
- Maximum Memory Supported: 128 gigabytes
- Memory Type Supported: DDR5
- General
- Brand: GIGABYTE
- Model Number: B850M EAGLE WIFI6E
- Product Name: B850M EAGLE WIFI6E (Socket AM5) AMD B850 Micro-ATX DDR5 Wi-Fi 6E Motherboard
- Color: Black
- Year of Release: 2025
- Compatibility
- Chipset: AMD B850
- Chipset Compatibility: AMD
- Form Factor: microATX (The size, arrangement, and physical configuration of the product.)
- Processor Socket: Socket AM5 (LGA 1718) (Type of pin configuration that connects a CPU to a computer’s motherboard.)
- Processor Compatibility: AMD Ryzen 9 9000 Series, AMD Ryzen 9 8000 Series, AMD Ryzen 9 7000 Series
- Operating System Compatibility: Windows 11 Home
- Slot
- Number of M.2 Slots: 2 (This interface is most commonly used for high-speed solid state drives (SSDs), and is often used in laptops due to its small size.)
- Number Of PCI-E x16 Slots: 2
- Number Of Memory Slots: 4
- Connectivity
- Wireless Connectivity: Wi-Fi, Bluetooth (The manner in which a device sends data to another device over a short distance without the use of wires or cables.)
- Wireless Networking Standard: Wi-Fi 6E (The wireless networking standard used by the device. Each iteration of the standard developed by the Wi-Fi Alliance corresponds to an existing IEEE 802.11 protocol; for example, standard 802.11ac (or AC) is termed Wi-Fi 5. Refers specifically to the standard the device is designed to use, but ultimately determines product interoperability and backward compatibility including previous versions.)
- Ports
- USB Ports: 8 x USB-A 2.0, 5 x USB-A 3.2, 2 x USB-C 3.1 (The number and type of USB ports the product has.)
- Number of Audio Channels: 2, 4, 5.1, 7.1 (The number of discrete channels of sound output. This can be a single number or multiple numbers separated by decimal(s). The first number is the primary, horizontally directed audio channels. The number after the first decimal, if applicable, is the number of subwoofer outputs or channels. The number after the second decimal, if applicable, is the number of height or atmospheric channels designed to immerse the listener by producing overhead sound effects.)
- Dimensions
- Product Length: 244 millimeters (The out of box length of the item. Length is measured as the longest dimension of the item.)
- Product Width: 244 millimeters (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Weight: 51.52 ounces (The out of box weight of the item.)
- Memory
- Maximum Memory Supported: 128 gigabytes
- Memory Type Supported: DDR5
- Memory Format Supported: UDIMM (Memory module size that will fit with the device.)
- Memory Speeds Supported: 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)of system memory (The RAM's bandwidth rating supported by the device. The number refers to transfer speed. For example, 12800 would indicate that the memory has a theoretical bandwidth of 12,800 megabytes per second (MBs). The higher the number, the faster the speed.)
- Memory Slot Type: 288-pin DIMM
- Features
- RAID Support: RAID 0, RAID 5, RAID 10 (RAID 1+0) (A Redundant Array of Independent Disks (RAID) includes a collection of separate disks that your computer recognizes as one disk unit. Each configuration offers a different level of mirroring, striping and read/write speeds.)
- Warranty
- Warranty - Parts: 3 years
- Warranty - Labor: 3 years
- Other
- UPC: 889523049693
The B850M EAGLE WF6E supports AM5 Processors and features unparalleled performance. GIGABYTE B850 motherboards come with upgraded power design, high grade storage standards, and outstanding connectivity that enables you to optimize your performance.
- Processor Compatibility: Supports AMD Ryzen 9000 / Ryzen 8000 / Ryzen 7000 Series Processors
- DDR5 Compatible: 4*DIMMs
- Next Gen Connectivity: PCIe 5.0, 2x M.2 Slots, USB-C
- Sturdy Power Design: 8+2+2 Twin Digital VRM Design
- Fast Networking: 2.5GbE LAN
- Processor Compatibility: Supports AMD Ryzen 9000 / Ryzen 8000 / Ryzen 7000 Series Processors
- DDR5 Compatible: 4*DIMMs
- Next Gen Connectivity: PCIe 5.0, 2x M.2 Slots, USB-C
- Sturdy Power Design: 8+2+2 Twin Digital VRM Design
- Fast Networking: 2.5GbE LAN
Whats Included
- B850M EAGLE WIFI6E
- B850M EAGLE WIFI6E
A: Dear Customer, Thank you for reaching out. Please note that the B850M EAGLE WIFI6E supports DDR5 memory, with 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB per DIMM) of system memory. Support for DDR5 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400(O.C) / 6200(O.C) / 6000(O.C) / 5800(O.C) / 5600(O.C) / 5200 / 4800 / 4400 MT/s memory modules. We sincerely apologize for the inconvenience this may have caused.
Compare similar products
The B850M EAGLE WF6E supports AM5 Processors and features unparalleled performance. GIGABYTE B850 motherboards come with upgraded power design, high grade storage standards, and outstanding connectivity that enables you to optimize your performance.
A new era is here. The B650 EAGLE AX supports AM5 Processors and features unparalleled performance. GIGABYTE B650 motherboards come with upgraded power design, high grade storage standards, and outstanding connectivity that enables you to optimize your performance.
The B850M GAMING X WIFI6E supports AM5 Processors and features unparalleled performance. GIGABYTE B850 motherboards come with upgraded power design, high grade storage standards, and outstanding connectivity that enables you to optimize your performance.
The B850M EAGLE WF6E ICE supports AM5 Processors and features unparalleled performance. GIGABYTE B850 motherboards come with upgraded power design, high grade storage standards, and outstanding connectivity that enables you to optimize your performance.
| Pros for GIGABYTE - B850M EAGLE WIFI6E (Socket AM5) AMD B850 Micro-ATX DDR5 Wi-Fi 6E Motherboard - Black | |||
|---|---|---|---|
| There were no pros for this product— | Overall Performance, Wi-Fi, M.2 Slots, Ease of use, Price | There were no pros for this product— | There were no pros for this product— |
| Cons for GIGABYTE - B850M EAGLE WIFI6E (Socket AM5) AMD B850 Micro-ATX DDR5 Wi-Fi 6E Motherboard - Black | |||
| There were no cons for this product— | USB 2.0 | There were no cons for this product— | There were no cons for this product— |
Specs
Reviews
This product doesn't have any reviews yet.
