JCPower Audio Systems - JC-Series 360w 4-Channel Amplifier - Black
JCPower Audio Systems - JC-Series 360w 4-Channel Amplifier - Black
FREE shipping to
Related Item
Specifications
- Continuous Watts x Channel @ Ohms60 Watts x 4 @ 4 ohms, 90 Watts x 4 @ 2 ohms, 180W x 2 @ 4 ohms bridgedAmplifier ClassABNumber Of Channels4Bass BoostNoneBridgeableYesLow-Pass CrossoverVariable
- Key Specs
- Continuous Watts x Channel @ Ohms: 60 Watts x 4 @ 4 ohms, 90 Watts x 4 @ 2 ohms, 180W x 2 @ 4 ohms bridged
- Amplifier Class: AB (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Number Of Channels: 4
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Bridgeable: true (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Low-Pass Crossover: Variable (Devices with this function allow only audio frequencies below a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- High-Pass Crossover: Variable (Devices with this function allow only audio frequencies above a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- Speaker-Level Inputs: false (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- General
- Brand: JCPower Audio Systems
- Model Number: JC360.4
- Product Name: JC-Series 360w 4-Channel Amplifier
- Color: Black
- Mounting Hardware Included: true
- Audio Power
- Continuous Watts x Channel @ Ohms: 60 Watts x 4 @ 4 ohms, 90 Watts x 4 @ 2 ohms, 180W x 2 @ 4 ohms bridged
- Total Power Handling Maximum: 360 watts
- Amplifier Class: AB (An amplifier's mode of operation, specifically the conditions in which its electrical current flows for the duration of an audio signal, determines its class. Each class has its strengths and weaknesses when it comes to power efficiency, levels of crossover distortion, and overall sound quality.)
- Audio
- Number Of Channels: 4
- Minimum Frequency Response: 20 hertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The minimum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Maximum Frequency Response: 20 kilohertz (Describes the maximum range of frequencies or musical tones a product can reproduce, from very low tones to very high treble tones. The maximum frequency or musical tone the speaker can reproduce. High treble tones have higher frequencies while low tones and deep bass have lower frequencies.)
- Total Harmonic Distortion: 0.2 percent (Measurement of the harmonic sound distortion. The lower the percentage, the cleaner the sound.)
- Signal-to-Noise Ratio (SNR): 90 decibels (The ratio of the desired signal's strength to the level of background noise. A ratio higher than 1:1, which equates to greater than 0 decibels, indicates more signal than noise.)
- Bass Boost: None (Circuitry that boosts the bass response of the amplifier, improving audio reproduction enhancing the sound of low frequencies. Fixed boost means the level of bass response is preset, whereas variable boost allows the user to make adjustments.)
- Features
- Bridgeable: true (Bridging an amplifier increases the power it supplies to the speaker(s).)
- Low-Pass Crossover: Variable (Devices with this function allow only audio frequencies below a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- High-Pass Crossover: Variable (Devices with this function allow only audio frequencies above a chosen cut-off frequency to pass through to a speaker or sound system. A device may have a cut-off frequency predetermined by its manufacturer (fixed), multiple cut-off frequency options to choose from (selectable), or have the capability for the frequency to be configured by the user (variable).)
- MOSFET Power Supply: true (A specific type of power supply with the advantages of high switching speed and efficiency at low voltages.)
- Bluetooth Enabled: false (The device is capable of communicating with another device via Bluetooth, provided they are within the required range of each other. A Bluetooth-enabled device must also be the same Bluetooth version or higher than the accessory it is intended to pair with.)
- Remote Control Included: No
- Marine: false
- Input
- Line-Level Inputs: true (Also referred to as low-level inputs. Enables the amplifier to receive a sound signal from another device via RCA cables.)
- Speaker-Level Inputs: false (Also referred to as high-level inputs. Enables the amplifier to receive a sound signal from another device that does not have RCA, or low-level, inputs.)
- Dimensions
- Product Height: 2 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 10.4 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 5.8 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Product Weight: 4 pounds (The out of box weight of the item.)
- Warranty
- Warranty - Parts: 2 years
- Other
- UPC: 618528023397
The JCPower JC360.4 is an affordable amplifier that delivers impressive sound quality and versatility without breaking the bank. This Class AB 4 channel amp is designed to power a wide range of car speakers, providing clean, accurate sound reproduction for a truly enjoyable listening experience.
- Efficient and Powerful Performance: The JC360.4 delivers strong output for its price, providing up to 90W RMS per channel at 2 ohms and 180W RMS x 2 when bridged, making it suitable for a wide range of car speaker setups.
- Designed for Sound Quality: The JC360.4 uses a Class AB design that delivers clean, low-distortion sound with a strong balance of power and efficiency. While less efficient than Class D, it maintains manageable heat levels and reliable performance, making it a versatile choice for a wide range of car audio systems.
- Enhance Your Car Audio on a Budget: The JCPower JC360.4 is the perfect choice for budget-conscious car audio enthusiasts who demand clean, powerful sound and versatile performance. Upgrade your car audio system today and experience the difference that a dedicated 4-channel amplifier can make without overspending.
Whats Included
- JC360.4 4-Channel Amplifier, Fuse(s), mounting screws
