KitchenAid - 36 inches - Externally Vented - Wall Range Hood - Black Stainless Steel
KitchenAid - 36 inches - Externally Vented - Wall Range Hood - Black Stainless Steel
Related Item
Specifications
- Color FinishBlack stainless steelProduct Height24 9/16 inchesProduct Width36 inchesProduct Depth19 3/4 inchesVent TypeDuctedVent StyleExternal
- Key Specs
- Color Finish: Black stainless steel
- Product Height: 24 9/16 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Product Width: 36 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 19 3/4 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- General
- Brand: KitchenAid
- Model Number: KVWB606HBS
- Product Name: 36" Externally Vented Range Hood
- Color: Black Stainless Steel
- Color Finish: Black stainless steel
- Dimensions
- Product Height: 24 9/16 inches (The out of box height of the item. Height is measured as the vertical distance from the bottom of the item to the top as it would be primarily used or placed.)
- Minimum Installation Height Above Cooktop: 24 inches
- Product Width: 36 inches (The out of box width of the item. Width is measured as the horizontal distance from one side of the item to the other as it would be primarily used or placed.)
- Product Depth: 19 3/4 inches (The out of box depth of the item. Depth is measured as the distance from the front of the item to the back as it would be primarily used or placed.)
- Standardized Width: 36 inches (An approximated measurement (exact width may differ slightly) determined by the manufacturer in accordance with industry standards. Standardized sizes are intended to assist consumers when purchasing appliances and planning for installation.)
- Product Weight: 55 pounds (The out of box weight of the item.)
- Duct Shape: Round
- Features
- Vent Type: Ducted
- Vent Style: External (External vents pull air from the room and move it directly outside through a dedicated duct system. Recirculating vents pull the air through a filter so that it can be cleaned before being recycled back into the room. Convertible vents can be reconfigured from external ventilation to recirculating via installation of certain parts.)
- Range Hood Type: Wall
- Number of Fan Speeds: 3
- Control Type: Touch pad
- Display Type: None
- Remote Control: false
- Damper Included: true
- Integrated Light(s): true
- Number of Lights: 3
- Number of Light Levels: 2
- Bulb Type Required: Halogen, LED
- Bulb(s) Included: true
- Performance
- Maximum Air Flow Capacity: 585 cubic feet per minute (Maximum amount of air that the appliance can ventilate at its highest setting.)
- Maximum Operating Sound Level: 5.4 sones (The perceived intensity of the operating sound produced by the product at its highest setting. The higher the sone rating, the louder the noise level.)
- Filter Info
- Filter Material: Metal
- Dishwasher-Safe Filter: true
- Removable Grease Filter: true
- Electrical
- Amperage: 15 amperes (Strength of electrical current.)
- Voltage: 120 volts (Amount of power needed to support an electrical current.)
- Certifications Listings & Approvals
- Product Safety Certifications and Standard(s): UL Listed (Lists the applicable certifications and/or standards, as stated by the manufacturer, in which the product has met the requirements for the assurance of quality and safety.)
- Warranty
- Warranty - Parts: 1 year limited
- Warranty - Labor: 1 year limited
- Other
- UPC: 883049484099
Remove smoke from your kitchen as you cook with the help of this KitchenAid wall mount canopy hood. LED lighting makes it easy to see meals while preparing food, and three fan speeds provide the optimal amount of ventilation required for every meal. This KitchenAid wall mount canopy hood features digital touch controls for an integrated, seamless design that's easy to clean.
How to Measure for a New Appliance
A little measuring now can help you avoid delivery headaches later.
Watch the video ›
- 585 cfm/65K BTU threshold: Allows installation over any KitchenAid regular 36- or 30-inch range or cooktop, and some commercial-style cooking surfaces with outputs up to 65K BTU.
- Three fan speeds with auto-speed setting: Takes the guesswork out of protecting cabinets from steam, grease, and moisture by automatically adjusting fan speed to ventilation needs depending on the heat being produced.
- Boost function (10 minutes): Enhances performance when using high-temperature cooking techniques by providing a timed, short burst of high-speed ventilation to effectively filter steam, grease, and odors from the air.
- Whisper Quite System @ 49 dBA at low speed: Ensures that the ventilation system operates at a quiet level so it can be used while entertaining. At maximum speed, sound level is 65 dBA (5.4 sones).
- Perimeter ventilation: Increases ventilation system efficiency by pulling air from the edges of the hood and speeding up the movement of air at the center, allowing it to efficiently handle up to a 65K BTU total output.
- Electronic glass touch control: Provides electronic operation with visual feedback on settings and selections.
- LED task lights: Provide extra lighting over the cooking surface to help in the cooking process.
- Halogen night lights: Enhances the style of the ventilation system by providing soft, accent lighting in the kitchen.
- Dishwasher safe grease filters: Reduce steam, grease, and odor to help avoid contact with ceilings and countertops. The design increases filtration by obstructing the path of vented air to help capture more steam, grease, and odors as they are drawn through the vent.
- Easy in-line conversion: Converts from a traditional set-up to an in-line blower installation for an even more quiet operation. Metal box purchase required.
- Black stainless finish: Offers a sleek, stylish look.
- Need more information?: See what's included with home delivery and installation.
Whats Included
- KitchenAid hood canopy assembly with ventilator and LED and halogen lights installed
- Vent transition with back draft dampers installed
- Metal grease filters
- Vent cover support bracket
- Mounting template
- 2-Piece vent cover
- Assembly hardware
- Owner's Manual
Product Manuals
A: Hello Liz, this model does offer a Recirculating Kit. The part number of that is W11430925. We hope this helps
A: Hello PJORainier. This KitchenAid® Range Hood has a motor with a 600 CFM and you are not able to change the motor for a lower CFM. We hope this helps!
A: Hello Greg! Yes, there is an extension kit. It is EXTKIT12HS. We hope this helps.
A: Hi, For this model per the installation instruction 6" (15.2 cm) diameter round metal vent duct - length required is determined by ceiling height. We hope this helps.
A: The outside dimensions are 13"wide x 10.5" deep x 34" tall. It fit in our kitchen with 9' ceiling and didn't need the extension that you have to/ can order separately. We bought this model because the hole in our drywall ceiling was large for the vent and this was one of the widest column models we could find. We love it and would recommend.
Q: Does KitchenAid make a trim piece to go around the top at the ceiling?
A: We currently do not have a trim piece available for the top. We greatly apologize and will pass this feedback along. Thank you for your inquiry about our KitchenAid appliances.
Q: Where is the serial number of the unit. Have been looking all over the unit.
A: Hello, on model KVWB606DSS, per the Installation Instructions: The model/serial/rating plate is located behind the left filter on the rear wall of the vent hood. Thank you for your inquiry on our KitchenAid appliances.
A: Hello! Please see the link to the Installation Instruction's for this model. bit.ly/49UZ5IU This will advise what is included with this model along with the dimensions. We hope this helps.
